Aluminum Electrolytic Capacitors/ FK
Radial Lead Type
Series:
FK
Type:
A
■
Features
●
Low impedance (10 % to 30 % less than FC Series)
Miniaturization (30 % to 40 % less than FC Series)
●
Endurance : 3000 h to 5000 h at +105 °C
●
RoHS directive compliant
■
Specifications
Category Temp. Range
Rated W.V. Range
Nominal Cap. Range
Capacitance Tolerance
DC Leakage Current
tan
δ
–55 °C to +105 °C
6.3 V.DC to 35 V.DC
180 µF to 12000 µF
±20 % (120 Hz/+20 °C)
I
<
0.01 CV (µA) After 2 minutes
W.V.
6.3
10
16
25
35
tan
δ
0.22
0.19
0.16
0.14
0.12
Add 0.02 per 1000 µF for products of 1000 µF or more.
(120 Hz/+20 °C)
Endurance
After following life test with DC voltage and +105 °C±2 °C ripple current value applied (The sum
of DC and ripple peak voltage shall not exceed the rated working voltage), when the capacitors
are restored to 20 °C, the capacitors shall meet the limits specified bellow.
Duration :
φ8:
3000 hours ,
φ10:
4000 hours ,
φ12.5
to
φ18:
5000 hours
Capacitance change ±20 % of initial measured value
tan
δ
<
200 % of initial specified value
DC leakage current
<
initial specified value
Shelf Life
After storage for 1000 hours at +105 °C±2 °C with no voltage applied and then being stabilized
at +20 °C, capacitors shall meet the limits specified in Endurance. (With voltage treatment)
■
Frequency correction factor for ripple current
W.V.(V.DC)
180
6.3 to 35
390
1200
Cap (µF)
to
to
330
1000
Frequency (Hz)
60
0.60
0.65
0.75
120
0.70
0.75
0.80
1k
0.85
0.90
0.95
10 k
0.95
0.98
1.00
100 k
1.00
1.00
1.00
to 12000
■
Dimensions in mm (not to scale)
[mm]
Sleeve
Pressure relief
φd±0.05
φ8
φ10<
+
–
F±0.5
L
½
½
L<16 : L±1.5
L>20 : L±2.0
14 min.
3 min.
φD±0.5
φD±0.5
(mm)
Body Dia.
φD
Body Length L
Lead Dia.
φd
Lead space F
8
—
0.6
3.5
10
—
0.6
5.0
12.5 to 25
0.6
5.0
12.5
30 to 40
0.8
5.0
16
—
0.8
7.5
18
—
0.8
7.5
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
