ECWU2124C9

Description
Stacked Metallized PEN Film Chip Capacitor
File Size717KB,13 Pages
ManufacturerPanasonic
Websitehttp://www.panasonic.co.jp/semicon/e-index.html
Download Datasheet View All

ECWU2124C9 Overview

Stacked Metallized PEN Film Chip Capacitor

Plastic Film Capacitors
Stacked Metallized PEN Film Chip Capacitor
Type:
ECWU(C)
Stacked metallized PEN film as dielectric with simple
mold-less construction
■Features
Small in size
For reflow soldering
RoHS directive compliant
■Recommended
Applications
General purpose (Coupling, By-pass)
■Explanation
of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
C
W
U
Rated voltage
1
2
100 VDC
250 VDC
6
7
8
9
C
Nominal capacitance
Cap. Tol. Suffix
J ±5 %
K ±10 %
10
11
Product code
Dielectric &
construction
Suffix
Tape width
9 12 mm
V 16 mm
1
2
3
4
5
E
C
W
U
1
1
0
4
V
3
Suffix
3
Product code
Dielectric & Rated voltage
capacitance
construction
1 100 VDC
3
4
5
6
7
8
Small in sizu, Cap. Tol.:±5 %, Tape width:12 mm
9
10
11
12
1
2
E
C
W
U
C
Suffix
2
2
J
capacitance
J
J
V
Product code
Dielectric &
construction
Rated voltage
630 VDC
Cap. Tol. Suffix
±5 %
Tape width
V 16 mm
■Specifications
Category temp.range
(Including temperature-rise on unit surface)
Rated voltage
-55 ˚C to +125 ˚C
100 VDC, 250 VDC, 630 VDC
(Derating of rated voltage by 1.25 %/˚C more than 85 ˚C)
0.012 µF to 1.0 µF (E12)
100 VDC
250 VDC
630 VDC
100 VDC
Capacitance tolerance
Withstand voltage
Dissipation factor (tan )
Insulation resistance (IR)
250 VDC
0.0010 µF to 0.12 µF (E12)
Capacitance range
0.022 µF, 0.027 µF, 0.033 µF
>
±5 %(J), ±10 %(K) (C
=
0.18 µF : ±10 %(K)only)
±5 %(J), ±10 %(K)
±5 %(J)
630 VDC
Between terminals: Rated volt. (VDC)✕150 % 60 s
tan
<
1.0 %(20 ˚C, 1 kHz)
=
C
<
0.33 µF
=
C>0.33 µF
100 VDC
250 VDC
630 VDC
>
100 VDC, 250 VDC, 630 VDC : IR=3000 MΩ · (20 ˚C,100 VDC, 60 s)
>
100 VDC : IR=1000 MΩ · µF (20 ˚C,100 VDC, 60 s)
Reflow soldering : 240 ˚C max. and 60 s max. at more than 220 ˚C (Temp. at cap. surface)
(Please consult us for Reflow 250 ˚C max. product.)
Reflow soldering : 250 ˚C max. and 60 s to 150s. at more than 217 ˚C
(Temp. at cap. surface)
Soldering conditions
In case of applying voltage in alternating current (50 Hz or 60 Hz sine wave) to a capacitor with DC rated voltage, please
refer to the page of “Permissible voltage (R.M.S) in alternating current corresponding to DC rated voltage”.
Please consult us for capacitance range between 0.15 µF and 1.0 µF. ( 250 VDC)
Design, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
− FC22 −
