C U I Stack, Inc.,
1997
3-M4
15
Ø103
7
ORDERING INSTRUCTIONS
MES80-_ _ _ _ _-_ _
Resolution
Output Format:
'blank =TTL voltage
C = Open Coll
E = Line Driver
Input Voltage:
1 = 5VDC
±10%
3 = 5~12VDC
±10%
4 = 24VDC
±10%*
*
Open-collector only
SPECIFICATIONS
TYPE
Supply Voltage
Current
Output
Voltage
Sink Current
Signal Risetime
Freq. Response
MECHANICAL
1. Max Shaft Load, radial: 2.0 kgf
axial: 1.0 kgf
2. Moment of Inertia: 40 g•cm
2
3. Angular Acceleration: 1x10
5
rad/S
2
4. Max Slewing Speed: 1000 RPM
5. Starting Torque: 200 gf•cm max.
6. Rotational Life: 1 x 10
7
rpm•hrs
120˚
30˚
PCD80
38
7.5
20
STANDARD RESOLUTIONS
MES80-XXXXX
600 600 P/R
*10800 10800 P/R
800 800 P/R
18000 18000 P/R
1000 1000 P/R
*21600 21600 P/R
*A/B only; no index channel
(Clockwise rotation viewed from front)
TYPE D
OUTPUT CIRCUITS
TYPE ' ' (Voltage)
Vcc
Signal
20mA
max
0V
CABLE SHIELD
OUTPUT WAVEFORM
' '
C
5.0 VDC ±10%
12.0 VDC ±10%
E
TYPE R,C
P
P
Sig A
TYPE C (Open Coll)
Vcc
Signal
30mA
max
Signal A
a b c d
60mA max.
Sig A
Sig B
h
Sig B
H
L
Vcc - 1V
≤
0.5V
20mA max.
≤
2µS
100kHz
Signal B
Signal Z
1
P=
PPR
P P
a,b,c,d = ±
4 8
h min
h max
a b c d
0V
CABLE SHIELD
TYPE E (Line Driver)
Vcc
Signal
h
Inv. Sig.
0V
Sig Z
Sig Z
h = P ± 0.75P
Wave Duty Ratio: 50% ± 25%
ENVIRONMENTAL
1.
2.
3.
4.
5.
Operating Temp: 0° to +60° C
Storage Temp: -20° to +80° C
Humidity: 90% RH, no condensation
Vibration: 10~55 Hz, 1.5 mm, 2 hrs
Shock: 50G, 11ms, 3 axes, 3 reps
C U I Stack, Inc.
9615 SW Allen Blvd. #103
Beaverton, OR 97005
Tel: 503/643-4899 FAX: 503/643-6129
DRAWN BY
UPDATED
CHECKED
RELEASED
JAS
PART NO.
02/28/01
02/28/01
REV.
MES80-XXXXX-XX
A
