NETWORKING SOCKETS
LEDs within socket
Shielded and Unshielded RJ45 available
Bi Colours available
Wide range of colours
LED LIGHT JACKS
SPECIFICATION
Current Rating
Contact Resistance
Dielectric withstanding Voltage
Insulation Resistance
Plating
Housing
Contact
Operating Temperature
3A
30mΩ max at DC 100mA
AC 500V for 1 minute
1000mΩ min at DC 500V
Gold plating over Nickel Tin plate over nickel in solder area
Thermoplastic (UL94V-0)
0.35mm Phosphor Bronze
-55˚C to +105˚C
OUTLINE DRAWING
A±0.25
LED2
LED1
TYPICAL FOR SINGLE
COLOR LED
(RED, GREEN, YELLOW)
3.68
1.70
13.46±0.25
12
11
10
9
TYPICAL FOR
BI-COLOUR LED
2.62
D
5.46
3.20
B
C±0.15
LED SCHEMATIC
0.51
2.29
13.72
2.29
0.51
4-Ø1.57
3-Ø3.25
12
11
8
1
2.78
1.02
2.04
1.78
C
E
10 9
9.14
CODE
0
1
2
3
4
5
6
7
8
No of
Positions
LED2 (Left)
NO LED
YELLOW
NO LED
GREEN
GREEN
YELLOW
YELLOW/GREEN
GREEN/RED
YELLOW/GREEN
LED1 (Right)
NO LED
GREEN
GREEN
YELLOW
GREEN
YELLOW
YELLOW/GREEN
GREEN/RED
YELLOW
9.14
15.75
48-Ø0.89
B
3.43
2.54
4.32
SECTION 16
Dimensions
A
B
15.75
47.25
78.75
110.25
C
12.70
28.45
59.94
91.45
122.94
D
2.25
2.37
2.37
2.37
2.37
8
1
8
1
8
1
10.16
1
2
4
6
8
15.91
31.66
63.16
94.66
126.16
ORDERING INFORMATION
DBC
Dubilier
Connectors
RJ
Series
S
Contact Type
S = Socket
2
No. of Ports
1 =1 port
2 = 2 ports
4 = 4 ports
8 = 8 ports
4
LED Colour
See table above
1
Contact Plating
1 = 6µ"
2 = 50µ"
2
Shielding
1 = Unshielded
2 = Shielded
358
