Green
ZVP2110G
SOT223 P-CHANNEL ENHANCEMENT MODE VERTICAL DMOS FET
Product Summary
V
(BR)DSS
-100V
8
Max R
DS(on)
@ V
GS
= 10V
Max I
D
T
A
= +25°C
°
-310mA
Mechanical Data
•
•
•
•
•
•
Case: SOT223
Case Material: Molded Plastic, “Green” Molding Compound;
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals Connections: See Diagram Below
Terminals: Finish - Matte Tin Annealed over Copper Leadframe;
Solderable per MIL-STD-202, Method 208
Weight: 0.112 grams (Approximate)
NEW PRODUCT
Features and Benefits
•
•
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
SOT223
D
G
S
Top View
Pin Out Top-View
Equivalent Circuit
Ordering Information
(Note 4)
Part Number
ZVP2110GTA
Notes:
Compliance
Standard
Case
SOT223
Packaging
1,000
1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
SOT223
ZVP
2110
ZVP 2110 = Product Type Marking Code
YWW = Date Code Marking
Y or Y = Last Digit of Year (ex: 5= 2015)
WW or WW = Week Code (01~53)
YWW
ZVP2110G
Datasheet Number: DS33395 Rev. 3 - 2
1 of 5
www.diodes.com
March 2015
© Diodes Incorporated
ZVP2110G
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current
Pulsed Drain Current
Symbol
V
DS
V
GS
I
D
I
DM
Value
-100
±20
-310
-3
Unit
V
V
mA
A
NEW PRODUCT
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Power Dissipation at T
A
= +25°
C
Operating and Storage Temperature Range
Symbol
P
tot
T
J
, T
STG
Value
2
-55 to +150
Unit
W
°
C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
OFF CHARACTERISTICS
Drain-Source Breakdown Voltage
Zero Gate Voltage Drain Current
Gate-Body Leakage
Gate-Source Threshold Voltage
ON CHARACTERISTICS
On-State Drain Current (Note 5)
Static Drain-Source On-State Resistance (Note 5)
Forward Transconductance (Notes 5 & 6)
DYNAMIC CHARACTERISTICS
Input Capacitance (Note 6)
Output Capacitance (Note 6)
Reverse Transfer Capacitance (Note 6)
Turn-On Delay Time (Notes 6 & 7)
Turn-On Rise Time (Notes 6 & 7)
Turn-Off Delay Time (Notes 6 & 7)
Turn-Off Fall Time (Notes 6 & 7)
Notes:
Symbol
BV
DSS
I
DSS
I
GSS
V
GS(th)
I
D(on)
R
DS (ON)
g
fs
C
iss
C
oss
C
rss
t
d(on)
t
r
t
d(off)
t
f
Min
-100
—
—
-1.5
-750
—
125
—
—
—
—
—
—
—
Typ
—
—
—
—
—
—
—
—
—
—
—
—
—
—
Max
—
-1
-100
-20
-3.5
—
8
—
100
35
10
7
15
12
15
Unit
V
µA
nA
V
mA
mS
pF
pF
pF
ns
ns
Ns
Ns
Test Condition
I
D
= -1mA, V
GS
= 0V
V
DS
= -100V, V
GS
= 0V
V
DS
= -80V, V
GS
= 0V ,
T = +125°
C
(Notes 6)
V
GS
=
±20V,
V
DS
= 0V
I
D
= -1mA, V
DS
= V
GS
V
DS
= -25V, V
GS
= -10V
V
GS
= -10V, I
D
= -375mA
V
DS
= -25V, I
D
= -375mA
V
DS
= -25 V, V
GS
= 0V
f = 1MHz
V
DD
≈
-25V, I
D
= -375mA
5. Measured under pulsed conditions. Width = 300µs. Duty cycle
≤
2%.
6. Sample Test.
7. Switching times measured with 50 source impedance and <5ns rise time on a pulse generator.
ZVP2110G
Datasheet Number: DS33395 Rev. 3 - 2
2 of 5
www.diodes.com
March 2015
© Diodes Incorporated
ZVP2110G
