15KP SERIES
Transient Voltage Supperssor
V
R
: 12 - 240 Volts
P
PK
: 15,000 Watts
Features
Excellent Clamping Capability
Fast Response Time
Low Zener Impedance
Low Leakage Current
AR - L
0.053 (1.35)
0.050 (1.27)
Mechani Data
cal
Case : Molded plastic
Epoxy : UL94V-O rate flame retardant
Lead : Axial lead solderable per MIL-STD-202,
Method 208 guaranteed
Polarity : Cathode polarity band
Mounting position : Any
Weight : 2.73 grams
0.410 (10.4)
0.380 (9.7)
0.250 (6.4)
0.235 (6.0)
1.00 (25.4)
MIN.
Dimensions in inches and ( millimeter )
MAXIMUM RATINGS
Rating at 25
°
C ambient temperature unless otherwise specified.
Rating
Peak Pulse Power Dissipation (10X1000µs, see Fig.1 )
Steady State Power Dissipation
Peak Forward Surge Current, 8.3ms Single Half Sine Wave
Symbol
P
PK
P
D
I
FSM
Value
15,000
7.0
200
- 55 to + 150
Unit
Watts
Watts
Amps.
°C
(Uni-directional devices only)
Operating and Storage Temperature Range
T
J
, T
STG
This pulse is a standard test waveform used for protection devices.
Fig. 1
I
PP
0.9 I
PP
Current
(Peak Value)
0.5 I
PP
0.1 I
PP
Time
T1 x 1.25 = 10µs
1000µs
http://www.luguang.cn
mail:lge@luguang.cn
15KP SERIES
Transient Voltage Supperssor
ELECTRICAL CHARACTERISTICS
Rating at 25
°
C ambient temperature unless otherwise specified
Part
Number
(Uni-directional)
Part
Number
(Bi-directional)
Reverse
Stand Off
Voltage
V
R
(V)
12
12
13
13
14
14
15
15
16
16
17
17
18
18
20
20
22
22
24
24
26
26
28
28
30
30
33
33
36
36
40
40
43
43
45
45
48
48
51
51
54
54
58
58
60
60
64
64
70
70
Breakdown
Voltage @ I
T
V
BR
(V)
Min.
13.3
13.3
14.4
14.4
15.6
15.6
16.7
16.7
17.8
17.8
18.9
18.9
20.0
20.0
22.2
22.2
24.4
24.4
26.7
26.7
28.9
28.9
31.1
31.1
33.3
33.3
36.7
36.7
40.0
40.0
44.4
44.4
47.8
47.8
50.0
50.0
53.3
53.3
56.7
56.7
60.0
60.0
64.4
64.4
66.7
66.7
71.1
71.1
77.8
77.8
I
T
(mA)
50.0
50.0
50.0
50.0
50.0
50.0
50.0
50.0
50.0
50.0
50.0
50.0
50.0
50.0
20.0
20.0
10.0
10.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
Maximum
Reverse Leakage
@ V
R
I
R
(µA)
10,000
10,000
10,000
10,000
8,000
8,000
8,000
8,000
8,000
8,000
5,000
5,000
5,000
5,000
1,500
1,500
500
500
150
150
50
50
25
25
15
15
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Maximum
Clamping
Voltage @ I
PP
V
C
(V)
22.0
19.9
23.8
21.5
25.8
23.2
26.9
24.4
28.8
26.0
32.2
29.3
34.2
30.9
37.9
34.3
41.1
37.1
45.0
40.7
48.7
44.0
52.4
47.5
56.2
50.7
60.6
54.8
66.0
59.7
72.8
65.8
77.1
69.7
80.7
73.0
85.9
77.7
91.5
82.5
96.8
87.5
104
94
107
97.3
115
104
126
114
Maximum
Peak Pulse
Current
I
PP
(A)
658
725
607
669
564
622
526
580
493
544
464
512
439
485
396
437
365
404
333
369
308
341
286
316
267
296
248
274
227
251
206
228
195
215
186
205
175
193
164
181
155
171
144
160
140
154
130
144
119
132
Max. Voltage
Temperature
Variation
of V
BR
(mV/
°
C)
12
12
13
13
14
14
16
16
19
17
19
17
20
18
24
21
27
24
30
27
32
29
35
31
37
33
42
38
46
41
51
46
55
50
57
52
62
56
66
60
70
63
76
68
78
70
84
76
92
83
15KP12
15KP12A
15KP13
15KP13A
15KP14
15KP14A
15KP15
15KP15A
15KP16
15KP16A
15KP17
15KP17A
15KP18
15KP18A
15KP20
15KP20A
15KP22
15KP22A
15KP24
15KP24A
15KP26
15KP26A
15KP28
15KP28A
15KP30
15KP30A
15KP33*
15KP33A*
15KP36*
15KP36A*
15KP40*
15KP40A*
15KP43
15KP43A
15KP45
15KP45A
15KP48*
15KP48A*
15KP51
15KP51A
15KP54
15KP54A
15KP58
15KP58A
15KP60
15KP60A
15KP64
15KP64A
15KP70
15KP70A
15KP12C
15KP12CA
15KP13C
15KP13CA
15KP14C
15KP14CA
15KP15C
15KP15CA
15KP16C
15KP16CA
15KP17C
15KP17CA
15KP18C
15KP18CA
15KP20C
15KP20CA
15KP22C
15KP22CA
15KP24C
15KP24CA
15KP26C
15KP26CA
15KP28C
15KP28CA
15KP30C
15KP30CA
15KP33C
15KP33CA
15KP36C*
15KP36CA*
15KP40C
15KP40CA
15KP43C
15KP43CA
15KP45C
15KP45CA
15KP48C*
15KP48CA*
15KP51C
15KP51CA
15KP54C
15KP54CA
15KP58C
15KP58CA
15KP60C
15KP60CA
15KP64C
15KP64CA
15KP70C*
15KP70CA*
http://www.luguang.cn
mail:lge@luguang.cn
15KP SERIES
Transient Voltage Supperssor
ELECTRICAL CHARACTERISTICS
Rating at 25
°
C ambient temperature unless otherwise specified
Reverse
Breakdown
Stand Off
Voltage @ I
T
Part
Part
Voltage
Number
Number
V
R
V
BR
(V)
I
T
(Uni-directional)
(Bi-directional)
(V)
Min.
(mA)
15KP75
15KP75A
15KP78
15KP78A
15KP85
15KP85A
15KP90
15KP90A
15KP100
15KP100A
15KP110
15KP110A
15KP120
15KP120A
15KP130
15KP130A
15KP150
15KP150A
15KP160
15KP160A
15KP170
15KP170A
15KP180
15KP180A
15KP200
15KP200A
15KP220
15KP220A
15KP240
15KP240A
15KP75C
15KP75CA
15KP78C
15KP78CA
15KP85C
15KP85CA
15KP90C
15KP90CA
15KP100C
15KP100CA
15KP110C
15KP110CA
15KP120C
15KP120CA
15KP130C
15KP130CA
15KP150C
15KP150CA
15KP160C
15KP160CA
15KP170C
15KP170CA
15KP180C
15KP180CA
15KP200C
15KP200CA
15KP220C
15KP220CA
15KP240C
15KP240CA
75
75
78
78
85
85
90
90
100
100
110
110
120
120
130
130
150
150
160
160
170
170
180
180
200
200
220
220
240
240
83.3
83.3
86.7
86.7
94.4
94.4
100
100
111
111
122
122
133
133
144
144
167
167
178
178
189
189
200
200
222
222
245
245
267
267
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
Maximum
Reverse Leakage
@ V
R
I
R
(µA)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Maximum
Clamping
Voltage @ I
PP
V
C
(V)
135
122
140
126
152
137
160
146
179
162
196
178
214
193
231
209
268
243
287
259
304
275
321
287
356
325
393
347
428
387
Maximum
Peak Pulse
Current
I
PP
(A)
111
123
107
119
99
109
94
103
84
93
77
84
70
78
65
72
56
62
52
58
49
55
47
52
42
46
38
43
35
39
Max. Voltage
Temperature
Variation
of V
BR
(mV/
°
C)
100
89
104
93
113
102
120
110
134
123
147
133
161
146
174
158
202
184
216
196
229
208
242
220
296
274
297
273
324
300
Note:
Suffix " A " denotes 5% tolerance device , no suffix denotes a 10% tolerance device.
* Prefered Voltages.
Fig. 2 - Peak Pulse Power vs. Pulse Time
1,000
Fig. 3 - Typical Capacitance vs. Breakdown Voltage
10,000
Pp Peak Pulse Power - kW
C - capacitance (pF)
100
1,000
10
10
Measued at
Stad-off Voltage
1.0
100ns
1µs
10µs
100µs
1ms
10ms
1
1V
10V
100V
1,000V
td Pulse Time - sec
V
BR
- Breakdown Voltage - Volts
http://www.luguang.cn
mail:lge@luguang.cn
