SMT POWER INDUCTORS
Unshielded Drum Core - PG0015NL Series
Height:
5.55mm Max
Footprint:
10.15mm x 9.15mm Max
Current Rating:
up to 2.6A
Inductance Range:
10µH to 820µH
260°C reflow peak temperature qualified
Electrical Specifications @ 25°C — Operating Temperature -40°C to +125°C
5
Part
4
Number
PG0015.103NL
PG0015.123NL
PG0015.153NL
PG0015.183NL
PG0015.223NL
PG0015.273NL
PG0015.333NL
PG0015.393NL
PG0015.473NL
PG0015.563NL
PG0015.683NL
PG0015.823NL
PG0015.104NL
PG0015.124NL
PG0015.154NL
PG0015.184NL
PG0015.224NL
PG0015.274NL
PG0015.334NL
PG0015.394NL
PG0015.474NL
PG0015.564NL
PG0015.684NL
PG0015.824NL
Inductance
@0Adc
(μH ±20%)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
Irated
1
(A)
2.6
2.45
2.27
2.15
1.95
1.76
1.50
1.37
1.28
1.17
1.11
1.00
0.97
0.89
0.78
0.72
0.66
0.57
0.52
0.48
0.42
0.32
0.28
0.24
DCR
(m
Ω
MAX)
60
70
80
90
100
110
120
140
170
190
220
250
350
400
470
630
730
970
1150
1300
1480
1900
2250
2550
Saturation
2
Current Isat
(A)
2.6
2.45
2.27
2.15
1.95
1.76
1.50
1.37
1.28
1.17
1.11
1.00
0.97
0.89
0.78
0.72
0.66
0.57
0.52
0.48
0.42
0.32
0.28
0.24
Heating
3
Current I
D C
(A)
4.8
4.5
4.3
4.1
4.0
3.7
3.4
3.2
3.1
3.0
2.7
2.4
2.2
1.9
1.8
1.5
1.3
1.2
1.1
1.1
1.0
0.9
0.9
0.5
SRF
(MHz TYP)
20
19
18
16
14
12
12
10
9.0
8.1
7.6
6.8
6.2
5.0
4.5
4.5
4.0
3.6
3.1
2.8
2.6
2.2
2.2
2.0
Mechanical
.360 MAX
9,15
.079 MIN
2,00
SUGGESTED PAD LAYOUT
.070
1,78
.402
10,20
Schematic
1
2
Date Code
Country of
XXXNL
.400
10,15
MAX
.219
5,55
MAX
.421
10,70
Weight
....................1.5 grams
Tape & Reel...............600/reel
.453
11,50
.217 .413
5,50 10,50
.945
± .012
24,00
± 0,30
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .004
0,10
.630
16,00
USER DIRECTION OF FEED
TAPE & REEL LAYOUT
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
13
SPM2007 (11/07)
SMT POWER INDUCTORS
Unshielded Drum Core - PG0015NL Series
Notes from Tables
1. The rated current as listed is either the saturation current
@ 25°C or the heating current depending on which value is lower.
2. The saturation current Isat is the current which causes the
inductance to drop by 10% Max at an ambient temperature of
25°C. This current is determined by placing the component in the
specified ambient environment and applying a short duration
pulse current (to eliminate self-heating effects) to the component.
3. The heating current Idc is the dc current which causes the tem-
perature rise of the part to increase approximately 40°C. This cur-
rent is determined by mounting the component on a typical appli-
cation PCB and applying the current to the device for 30 minutes.
4. Optional Tape and Reel packaging can be ordered by adding a
"T" suffix to the part number (i.e. PG0015.103NL becomes
PG0015.103NLT). Pulse complies to industry standard tape and
reel specification EIA481.
5. The temperature of the component (ambient plus temperature
rise) must be within the stated operating temperature range.
Typical Inductance vs Current Characteristics
120%
Percentage of the initial inductance
100%
80%
60%
40%
20%
0%
0,0
0,1
0,2
0,3
0,4
0,5
0,6
0,7
0,8
0,9
1,0
1,1
1,2
1,3
1,4
Normalized Irated
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
14
SPM2007 (11/07)
