DATA SHEET
NEC's BROADBAND
GaAs MMIC DPDT SWITCH UPG2035T5F
FOR 2.4 GHz AND 5 GHz WLAN
FEATURES
•
OPERATING FREQUENCY:
2.4 to 2.5 GHz and 4.9 to 6.0 GHz (specified)
2.0 to 6.0 GHz Broadband Operation (unspecified)
•
LOW INSERTION LOSS:
0.8 dB TYP. @ 2.4 to 2.5 GHz
1.2 dB TYP. @ 4.9 to 6.0 GHz
•
POWER HANDLING:
P
in (1 dB)
= +31 dBm TYP. @ 2.4 to 2.5 GHz
+30 dBm TYP. @ 4.9 to 6.0 GHz
•
•
CONTROL VOLTAGE:
+3.0 V / 0 V (Dual control)
HIGH ISOLATION:
INPUT to OUTPUT = 34 dB TYP. @ 2.4 to 2.5 GHz
INPUT to OUTPUT = 33 dB TYP. @ 4.9 to 6.0 GHz
TX to RX, ANT1 to ANT2 = 24 dB TYP. @ 2.4 to 2.5 GHz
TX to RX, ANT1 to ANT2 = 22 dB TYP. @ 4.9 to 6.0 GHz
•
•
•
•
INPUT/OUTPUT RETURN LOSS:
15 dB TYP.
SWITCHING SPEED:
50 ns @ t
RISE
/t
FALL
(10/90% RF)
12-PIN PLASTIC QFN PACKAGE:
(3.0 × 3.0 × 0.75 mm)
Pb FREE
NEC's UPG2035T5F is a GaAs MMIC DPDT switch
for 2.4 GHz and 5 GHz dualband Wireless LAN.
The UPG2035T5F features low insertion loss, high
isolation, and dualband operation.
DESCRIPTION
APPLICATIONS
•
802.11a+b/g WIRELESS LAN
•
2.0 TO 6.0 GHz T/R SWITCHING
•
2.0 TO 6.0 GHz ANTENNA DIVERSITY SWITCHING
ORDERING INFORMATION
PART NUMBER
UPG2035T5F-E2
ORDER NUMBER
UPG2035T5F-E2-A
PACKAGE
12-pin plastic QFN
(Pb-Free)
MARKING
2035
SUPPLYING FORM
•
Embossed tape 8 mm wide
•
Pin 1 indicates roll-in direction of tape
•
Qty 3 kpcs/reel
Remark
To order evaluation samples, contact your nearby sales office.
Part number for sample order: UPG2035T5F-A
California Eastern Laboratories
UPG2035T5F
PIN CONNECTIONS AND INTERNAL BLOCK DIAGRAM
PIN NO.
(Top View)
12
11
10
1
2
3
4
5
6
1
2
3
9
8
7
7
8
9
10
11
12
EXPOSED PAD
4
5
6
PIN NAME
NC
NC
V
cont1
ANT1
NC
ANT2
V
cont2
NC
NC
RX
NC
TX
GND
DESCRIPTION
Ground
Ground
Control 1
Antenna Port 1
Ground
Antenna Port 2
Control 2
Ground
Ground
Receive Port
Ground
Transmit Port
Ground
Remark
NC indicates functionally non-connected pins, but actual grounding is recommended.
TRUTH TABLE
V
cont1
2.7 to 5.0 V
0
±
0.2 V
V
cont2
0
±
0.2 V
2.7 to 5.0 V
ANT1-RX
ON
OFF
ANT1-TX
OFF
ON
ANT2-TX
ON
OFF
ANT2-RX
OFF
ON
ABSOLUTE MAXIMUM RATINGS
(T
A
=+25ºC, unless otherwise specified)
PARAMETER
Switch Control Voltage
Input Power
Total Power Dissipation
Operating Ambient Temperature
Storage Temperature
SYMBOL
V
cont
P
in
P
tot
T
A
T
stg
RATINGS
−6.0
to +6.0
Note 1
+36
0.15
Note 2
−45
to +85
−55
to +150
UNIT
V
dBm
W
°C
°C
Notes 1.
|
V
cont1
−
V
cont2
| ≤
6.0 V
2.
Mounted on double-sided copper-clad 50
×
50
×
1.6 mm epoxy glass PWB, T
A
= +85°C
UPG2035T5F
RECOMMENDED OPERATING RANGE
(T
A
=+25ºC)
PARAMETER
Operating Frequency 1
Operating Frequency 2
Switch Control Voltage (H)
Switch Control Voltage (L)
SYMBOL
f1
f2
V
cont (H)
V
cont (L)
MIN.
2.4
4.9
2.7
−0.2
TYP.
−
−
3.0
0
MAX.
2.5
6.0
5.0
0.2
UNIT
GHz
GHz
V
V
ELECTRICAL CHARACTERISTICS
(T
A
= +25°C, V
cont
= 3.0 V/0 V, Z
O
= 50
Ω,
DC blocking capacitors value: 4 pF,
Each port, unless otherwise specified)
PARAMETER
Insertion Loss 1
Insertion Loss 2
Isolation 1 (INPUT to OUTPUT)
Isolation 2 (INPUT to OUTPUT)
Isolation 3 (TX to RX, ANT1 to ANT2)
Isolation 4 (TX to RX, ANT1 to ANT2)
Input and Output Return Loss 1
Input and Output Return Loss 2
Switch Control Current 1
Switch Control Current 2
1 dB Gain Compression
Input Power
3rd Order Distortion Input Intercept
Point 1
3rd Order Distortion Input Intercept
Point 2
Switch Control Speed 1
Switch Control Speed 2
IIP
3
2
t
SW
1
t
SW
2
f = 4.9 to 6.0 GHz
f = 2.4 to 2.5 GHz,
t
RISE
/t
FALL
(10/90% RF)
f = 4.9 to 6.0 GHz,
t
RISE
/t
FALL
(10/90% RF)
−
−
−
45
50
50
−
−
−
dBm
ns
ns
SYMBOL
L
INS
1
L
INS
2
ISL1
ISL2
ISL3
ISL4
RL1
RL2
I
cont
1
I
cont
2
P
in (1 dB)
IIP
3
1
TEST CONDITIONS
f = 2.4 to 2.5 GHz
f = 4.9 to 6.0 GHz
f = 2.4 to 2.5 GHz
f = 4.9 to 6.0 GHz
f = 2.4 to 2.5 GHz
f = 4.9 to 6.0 GHz
f = 2.4 to 2.5 GHz
f = 4.9 to 6.0 GHz
f = 2.4 to 2.5 GHz
f = 4.9 to 6.0 GHz
f = 2.4 to 2.5 GHz
f = 4.9 to 6.0 GHz
f = 2.4 to 2.5 GHz
MIN.
−
−
25
25
17
17
−
−
−
−
−
−
−
TYP.
0.8
1.2
34
33
24
22
15
15
0.7
0.7
31
30
45
MAX.
1.0
1.4
−
−
−
−
−
−
1.5
1.5
−
−
−
dBm
UNIT
dB
dB
dB
dB
dB
dB
dB
dB
μA
μA
dBm
