Amplifier
50Ω
Medium Power
10 to 1000 MHz
Features
• wideband, 10 to 1000 MHz
• low noise, 5 dB typ.
• high IP3, +33 dBm typ.
• protected by US Patent, 6,943,629
Coaxial
ZFL-1000H
Applications
• cellular
• VHF/UHF
• test equipment
CASE STYLE: SS98
Connectors
Model
SMA
ZFL-1000H
BRACKET (OPTION “B”)
Price
$219.00
$2.50
Qty.
(1-9)
(1+)
Amplifier Electrical Specifications
MODEL
NO.
FREQUENCY
(MHz)
GAIN
(dB)
Flatness
Max.
±1.0
MAXIMUM
POWER
(dBm)
Output
(1 dB Compr.)
+20
Input
(no damage)
+5
DYNAMIC
RANGE
NF
(dB)
Typ.
5.0
IP3
(dBm)
Typ.
+33
VSWR
(:1)
Typ.
In
2.0
Out
2.0
Volt
(V)
Nom.
15
DC
POWER
Current
(mA)
Max.
160
f
L
ZFL-1000H
10
f
U
1000
Min.
28
Open load is not recommended, potentially can cause damage.
With no load derate max input power by 20 dB
Maximum Ratings
Operating Temperature
Storage Temperature
DC Voltage
-20°C to 71°C
-55°C to 100°C
+17V Max.
Outline Drawing
Outline Dimensions (
inch
)
mm
A
B
C
D
1.25
1.56
.75
.63
31.75 39.62 19.05 16.00
M
K
L
.46
2.18 1.688
11.68 55.37 42.88
E
F
G
.39
1.50 1.000
9.91 38.10 25.40
H
--
--
J
.125
3.18
T
.29
7.37
wt
grams
85.0
N
P
R
Q
S
.07
.750
.50
.80
.45
1.78 19.05 12.70 20.32 11.43
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Mini-Circuits
ISO 9001 & ISO 14001
Certified
REV. OR
M98088
ZFL-1000H
051228
Page 1 of 2
Typical Performance Data/Curves
FREQUENCY
(MHz)
12V
10.00
17.20
38.80
87.60
197.60
365.40
441.50
517.70
568.50
619.20
695.40
771.50
847.70
923.80
1000.00
32.70
32.46
32.18
32.17
32.28
32.49
32.61
32.69
32.68
32.75
32.79
32.88
33.02
33.21
33.21
ZFL-1000H
VSWR
(:1)
IN
1.21
1.22
1.22
1.21
1.18
1.08
1.07
1.08
1.09
1.11
1.12
1.11
1.10
1.15
1.34
GAIN
(dB)
15V
34.40
34.18
33.91
33.88
33.94
34.04
34.13
34.21
34.20
34.24
34.27
34.30
34.35
34.43
34.36
DIRECTIVITY
(dB)
16V
34.71
34.49
34.21
34.20
34.24
34.32
34.40
34.46
34.45
34.50
34.52
34.50
34.58
34.63
34.52
NOISE
FIGURE
(dB)
15V
4.82
4.77
4.63
4.63
4.58
4.67
4.72
4.74
4.75
4.74
4.75
4.79
4.81
4.85
4.90
POUT at
1 dB COMPR.
(dBm)
15V
21.35
21.44
21.13
21.14
21.07
20.84
20.57
20.37
20.24
20.38
20.63
20.95
21.49
21.95
22.42
12V
16.10
16.40
16.30
16.80
16.40
15.40
15.50
14.40
14.10
14.20
13.90
13.30
12.50
11.50
11.10
15V
15.30
15.40
16.60
15.80
14.90
14.80
14.10
14.80
13.70
13.30
14.20
11.90
11.90
11.50
11.70
16V
15.40
15.60
15.50
16.30
14.80
15.60
15.30
13.90
14.30
13.50
13.00
12.70
12.90
11.70
11.30
OUT
1.69
1.54
1.51
1.46
1.45
1.37
1.33
1.32
1.29
1.28
1.28
1.34
1.41
1.47
1.65
ZFL-1000H
GAIN
40
DIRECTIVITY (dB)
38
GAIN (dB)
36
34
32
30
0
200
400
600
FREQUENCY (MHz)
800
1000
12V
15V
16V
ZFL-1000GH
DIRECTIVITY
70
60
50
40
30
20
10
0
240
480
720
960
1200
FREQUENCY (MHz)
12V
15V
16V
2.0
1.8
VSWR
1.6
1.4
1.2
1.0
0
240
ZFL-1000GH
VSWR
IN
OUT
480
720
960
1200
FREQUENCY (MHz)
ZFL-1000H
OUTPUT POWER AT 1-dB COMPRESSION
25
OUTPUT POWER(dBm)
NOISE FIGURE (dB)
24
23
22
21
20
0
200
400
600
FREQUENCY (MHz)
800
1000
6.0
5.4
4.8
4.2
3.6
3.0
at
15V
ZFL-1000H
NOISE FIGURE
0
200
400
600
FREQUENCY (MHz)
800
1000
Page 2 of 2
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Mini-Circuits
ISO 9001 & ISO 14001
Certified
