Low Noise Amplifier
50
Ω
10 to 500 MHz
Features
• low noise, 3.8 dB typ.
• high IP3, +30 dBm typ.
Coaxial
ZFL-500HLN+
Applications
• VHF/UHF
• small signal amplifier
• communications system
CASE STYLE: Y460
Connectors
Model
Price
SMA
ZFL-500HLN+
$99.95
BRACKET (OPTION “B”)
$5.00
Qty.
(1-9)
(1+)
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
Low Noise Amplifier Electrical Specifications
MODEL
NO.
FREQUENCY
(MHz)
NOISE
FIGURE
(dB)
GAIN
(dB)
Flatness Max.
Total
Range
±0.4
Output
(1 dB Compr.)
+16
Input
(no damage)
+15
IP3
Typ.
+30
Volt
(V)
Nom.
15
Current
(mA)
Max.
110
MAXIMUM
POWER
(dBm)
INTERCEPT
POINT
(dBm)
VSWR (:1)
Typ.
DC
POWER
f
L
ZFL-500HLN+
10
f
U
500
Typ.
3.8
Min.
19
In
2.0
Out
2.0
m = mid range [2 fL to fU/2]
Open load is not recommended, potentially can cause damage.
With no load derate max input power by 20 dB
Maximum Ratings
Operating Temperature
Storage Temperature
DC Voltage
-20°C to 71°C
-55°C to 100°C
+17V Max.
Permanent damage may occur if any of these limits are exceeded.
Outline Drawing
Outline Dimensions (
inch
)
mm
A
B
C
D
1.25
1.25
.75
.63
31.75 31.75 19.05 16.00
E
F
G
.36 1.000 1.000
9.14 25.40 25.40
H
.125
3.18
J
K
L
M
.125
.46
2.18 1.688
3.18 11.68 55.37 42.88
N
P
Q
R
S
.06
.750
.50
.80
.45
1.52 19.05 12.70 20.32 11.43
T
wt.
.29 grams
7.37
38
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
www.minicircuits.com
P.O. Box 35166, Brooklyn, NY 11235-0003 (718) 934-4500 sales@minicircuits.com
Mini-Circuits
®
REV. B
M108294
ZFL-500HLN+
131015
Page 1 of 2
Typical Performance Data/Curves
FREQUENCY
(MHz)
12V
10.00
19.30
46.50
111.80
198.50
248.70
311.50
374.40
437.20
500.00
20.50
20.37
20.21
20.31
20.22
20.35
20.22
20.46
20.32
20.36
ZFL-500HLN+
VSWR
(:1)
IN
1.24
1.12
1.05
1.02
1.02
1.04
1.07
1.10
1.13
1.17
GAIN
(dB)
15V
20.97
20.82
20.68
20.78
20.66
20.82
20.69
20.96
20.79
20.87
DIRECTIVITY
(dB)
16V
21.05
20.92
20.76
20.87
20.77
20.90
20.77
21.03
20.90
20.96
NOISE
FIGURE
(dB)
15V
3.83
3.84
3.83
3.89
3.88
3.92
3.95
3.96
3.97
3.97
POUT at
1 dB COMPR.
(dBm)
15V
16.78
17.09
17.14
17.19
17.17
17.13
16.97
16.95
16.91
16.91
12V
16.70
17.10
17.50
16.20
15.60
15.80
15.80
14.30
14.20
13.80
15V
16.20
17.00
15.30
15.20
16.20
15.10
15.20
15.10
13.90
13.20
16V
16.30
16.00
15.90
16.50
15.30
14.90
15.00
14.20
13.60
12.30
OUT
1.17
1.13
1.11
1.11
1.06
1.07
1.06
1.10
1.17
1.25
ZFL-500HLN+
GAIN
22.0
ZFL-500HLN+
DIRECTIVITY
20
16V
1.5
1.4
VSWR
1.3
1.2
1.1
ZFL-500HLN+
VSWR
IN
OUT
DIRECTIVITY (dB)
21.6
GAIN (dB)
21.2
20.8
20.4
20.0
0
100
12V
15V
18
16
14
12
10
12V
0
100
15V
200
16V
300
400
500
1.0
0
100
200
300
400
500
FREQUENCY (MHz)
200
300
FREQUENCY (MHz)
400
500
FREQUENCY (MHz)
ZFL-500HLN+
OUTPUT POWER AT 1-dB COMPRESSION
18.0
OUTPUT POWER (dBm)
NOISE FIGURE (dB)
4.5
4.3
4.1
3.9
3.7
3.5
at 15V
ZFL-500HLN+
NOISE FIGURE
17.6
17.2
16.8
16.4
16.0
0
100
200
300
FREQUENCY (MHz)
400
500
0
100
200
300
400
500
FREQUENCY (MHz)
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
www.minicircuits.com
P.O. Box 35166, Brooklyn, NY 11235-0003 (718) 934-4500 sales@minicircuits.com
Mini-Circuits
®
Page 2 of 2
