ZLW-11HB: DescriptionDouble Balanced Mixer, 10MHz Min, 3000MHz Max, 12dB Conversion Loss-Max, CASE M21; CategoryWireless rf/communication Radio frequency and microwave; File Size152KB，2 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com

Download Datasheet Parametric Compare View All

ZLW-11HB Overview

Double Balanced Mixer, 10MHz Min, 3000MHz Max, 12dB Conversion Loss-Max, CASE M21

ZLW-11HB Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Mini-Circuits
Reach Compliance Code	unknown
Other features	SMA
structure	COAXIAL
Maximum frequency conversion loss	12 dB
Maximum input power (CW)	23 dBm
JESD-609 code	e0
Maximum operating frequency	3000 MHz
Minimum operating frequency	10 MHz
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
RF/Microwave Device Types	DOUBLE BALANCED
Terminal surface	Tin/Lead (Sn/Pb)
Maximum voltage standing wave ratio	2.47

Preview

Download Datasheet

View All

Coaxial

Frequency Mixer

Level 17 (LO Power +17 dBm) 10 to 3000 MHz

Maximum Ratings

Operating Temperature

Storage Temperature

RF Power

IF Current

-55°C to 100°C

200mW

40mA

ZLW-11H

Features

• low conversion loss, 6.83 dB typ.

• wideband, 10 to 3000 MHz

• rugged shielded case

CASE STYLE: M21

Connectors Model

BNC

ZLW-11H

BRACKET (OPTION “B”)

BRACKET (OPTION “BR”)

Price

$99.95 ea.

$5.00

$2.50

Qty.

(1-9)

(1+)

Applications

Coaxial Connections

LO

RF

IF

1

3

2

• cellular

• GPS

• MMDS

• PCS

• instrumentation

• terrestrial radio

FREQUENCY

(MHz)

LO/RF

f

L

-f

U

10-3000

10-1000

IF

—

X

6.83

Electrical Speciﬁcations

Outline Drawing

CONVERSION LOSS

(dB)

Mid-Band

m

σ

0.09

L

Typ.

27

Min.

20

Typ.

25

LO-RF ISOLATION

(dB)

M

Min.

18

Typ.

23

U

Min.

16

Typ.

27

L

LO-IF ISOLATION

(dB)

M

Min.

20

Typ.

25

Min.

18

Typ.

23

U

Min.

16

Total

Range

Max. Max.

10.0

12.0

1 dB COMP.: +10 dBm typ.

L = low range [f

L

to 10 f

L

]

m= mid band [2f

L

to f

U

/2]

M = mid range [10 f

L

to f

U

/2]

U = upper range [f

U

/2 to f

U

]

Typical Performance Data

Frequency

(MHz)

Conversion

Loss

(dB)

LO

40.00

50.00

73.44

170.00

260.31

470.00

540.69

727.50

913.91

1007.40

1288.00

1474.90

1568.30

1755.00

1942.10

2035.10

2222.10

2408.60

2596.00

2969.30

LO

+17dBm

6.43

6.58

6.60

6.78

6.75

6.94

6.81

7.00

7.05

7.37

6.81

6.68

6.65

6.71

6.57

6.76

6.61

6.63

6.95

8.58

Isolation

L-R

(dB)

LO

+17dBm

32.26

33.52

32.25

30.89

29.76

28.74

28.80

28.06

28.00

28.67

27.69

27.57

27.30

27.75

29.51

28.94

30.22

31.19

30.21

32.46

Isolation

L-I

(dB)

LO

+17dBm

35.01

36.23

33.97

32.03

30.61

29.28

29.04

28.08

26.87

26.49

26.66

27.97

28.78

28.96

31.44

33.79

36.80

37.00

30.13

26.88

VSWR RF

Port

(:1)

LO

+17dBm

1.13

1.07

1.08

1.13

1.18

1.29

1.34

1.48

1.66

1.72

1.92

1.99

1.75

1.89

1.76

1.68

1.69

1.49

1.90

VSWR LO

Port

(:1)

LO

+17dBm

2.07

2.19

2.01

1.96

1.91

1.83

1.81

1.80

1.74

1.69

1.65

1.91

1.75

1.66

1.49

1.14

1.26

2.47

RF

10.00

20.00

103.44

200.00

290.31

Outline Dimensions (

inch

)

mm

A

1.50

38.10

J

2.50

63.50

B

1.13

28.70

K

.10

2.54

C

1.00

25.40

L

.31

7.87

D

.50

12.70

M

.75

19.05

E

.155

3.94

N

1.19

30.23

F

2.345

59.56

P

.66

16.76

G

.138

3.51

H

.987

25.07

500.00

570.63

757.50

944.38

1037.80

1318.10

1505.00

1598.40

1785.30

1972.20

2065.60

2252.50

2439.40

2626.30

3000.00

S

wt

.150 grams

3.81

40.0

Electrical Schematic

LO

RF

IF

Mini-Circuits

®

INTERNET

http://www.minicircuits.com

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661

Distribution Centers

NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010

Mini-Circuits

ISO 9001 & ISO 14001

Certified

REV. OR

M93710

ZLW-11H

DJ/TD/CP

060628

Page 1 of 2
