Coaxial
Frequency Mixer
Level 10 (LO Power +10 dBm)
Maximum Ratings
Operating Temperature
Storage Temperature
RF Power
IF Current
-55°C to 100°C
-55°C to 100°C
50mW
40mA
ZP-5LH+
ZP-5LH
20 to 1500 MHz
Features
• low conversion loss, 6.9 dB typ.
• excellent L-R isolation, 42 dB typ.
• wideband, 20 to 1500 MHz
• rugged shielded case
BNC version shown
Permanent damage may occur if any of these limits are exceeded.
Applications
Coaxial Connections
LO
RF
IF
L
R
X
• VHF/UHF
• satellite distribution
• instrumentation
CASE STYLE: GG60
Connectors Model
Price
Qty.
BNC
ZP-5LH-(+)
$45.95 ea. (1-9)
SMA
ZP-5LH-S+
$50.95 ea. (1-9)
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Electrical Specifications
Outline Drawing
FREQUENCY
(MHz)
LO/RF
f
L
-f
U
20-1500
DC-1000
1 dB COMP.: +5 dBm typ.
IF
—
X
6.9
CONVERSION LOSS
(dB)
Mid-Band
m
σ
0.27
Total
Range
Max. Max.
8.5
9.0
L
Typ.
53
LO-RF ISOLATION
(dB)
M
Min.
40
Typ.
42
Min.
30
Typ.
38
U
Min.
25
Typ.
40
L
LO-IF ISOLATION
(dB)
M
Min.
25
Typ.
30
Min.
18
Typ.
22
U
Min.
8
L = low range [f
L
to 10 f
L
]
m= mid band [2f
L
to f
U
/2]
M = mid range [10 f
L
to f
U
/2]
U = upper range [f
U
/2 to f
U
]
Typical Performance Data
Frequency
(MHz)
Conversion
Loss
(dB)
LO
50.00
80.00
70.00
128.75
170.00
267.50
406.25
470.00
545.00
683.75
720.00
730.00
822.50
961.25
970.00
1100.00
1192.50
1331.25
1423.75
1470.00
LO
+10dBm
5.60
5.38
5.25
5.20
5.25
5.37
5.54
5.74
5.89
6.61
6.80
6.83
7.07
6.99
7.07
7.19
7.02
6.88
6.78
6.66
Isolation
L-R
(dB)
LO
+10dBm
62.84
57.81
52.60
49.11
47.45
44.43
42.14
41.47
40.90
40.16
39.71
39.62
39.30
38.97
38.98
35.93
38.98
39.21
38.09
37.95
Isolation
L-I
(dB)
LO
+10dBm
53.91
46.30
40.86
38.29
36.98
34.13
31.89
30.68
30.02
28.61
28.48
28.42
28.00
26.26
26.16
24.11
22.14
19.23
16.51
16.08
VSWR
RF Port
(:1)
LO
+10dBm
1.43
1.32
1.31
1.34
1.48
1.59
1.91
2.36
2.49
2.97
3.40
3.53
3.80
3.86
3.95
3.91
3.77
3.65
3.54
3.47
VSWR
LO Port
(:1)
LO
+10dBm
2.57
2.51
2.50
2.38
2.28
2.36
2.34
2.36
2.36
2.45
2.46
2.48
2.56
2.67
2.70
2.73
2.73
2.77
2.78
2.77
RF
20.00
50.00
100.00
158.75
200.00
Outline Dimensions (
inch
)
mm
A
B
C
2.31 1.20
.60
58.67 30.48 15.24
D
E
.125 2.062
3.18 52.37
F
G
H
wt
.30
.53
.63 grams
7.62 13.46 16.00
75.0
297.50
436.25
500.00
575.00
713.75
750.00
760.00
852.50
991.25
1000.00
1130.00
1222.50
1361.25
1453.75
1500.00
Electrical Schematic
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. A
M98898
ZP-5LH
DJ/TD/CP/AM
100205
Page 1 of 2
Performance Charts
10.0
CONVERSION LOSS (dB)
9.0
8.0
7.0
6.0
5.0
4.0
0
300
600
900
FREQUENCY (MHz)
ZP-5LH
L-I ISOLATION
70
60
ISOLATION (dB)
50
LO=+7 dBm
LO=+10 dBm
LO=+13 dBm
1200
1500
at IF Freq of 30 MHz
ZP-5LH+
ZP-5LH
LO=+13 dBm
ZP-5LH
CONVERSION LOSS
LO=+10 dBm
LO=+7 dBm
80
70
ISOLATION (dB)
60
50
40
30
20
0
300
LO=+7 dBm
ZP-5LH
L-R ISOLATION
LO=+10 dBm
LO=+13 dBm
600
900
FREQUENCY (MHz)
ZP-5LH
RF VSWR
1200
1500
5.0
4.0
VSWR
3.0
2.0
1.0
0
300
600
900
FREQUENCY (MHz)
1200
1500
LO=+7 dBm
LO=+10 dBm
LO=+13 dBm
40
30
20
10
0
300
600
900
FREQUENCY (MHz)
ZP-5LH
IF VSWR
1200
1500
ZP-5LH
LO VSWR
5.0
4.5
4.0
VSWR
3.0
2.5
2.0
1.5
1.0
0
300
600
900
FREQUENCY (MHz)
1200
1500
1.0
0
200
VSWR
LO=+7 dBm
LO=+10 dBm
LO=+13 dBm
1.6
LO=+7 dBm
1.4
LO=+10 dBm
LO=+13 dBm
3.5
1.2
400
600
FREQUENCY (MHz)
800
1000
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
Page 2 of 2
