Coaxial
50
Ω
Features
Amplifier
High Power
5W
5 to 500 MHz
• wideband, 5 to 500 MHz
• high power output, +37 dBm min.
• high gain, 40 dB min.
• low noise, 4 dB typ.
• high IP3, +49 dBm typ.
ZHL-5W-1
Applications
ZHL-5W-1X
ZHL-5W-1
• VHF/UHF
• instrumentation
• laboratory
CASE STYLE: DDD131
Connectors Model
Price
SMA
ZHL-5W-1
$995.00
SMA
ZHL-5W-1X
$970.00
Qty.
(1-9)
(1-9)
Electrical Specifications
MODEL
NO.
FREQ.
(MHz)
GAIN
(dB)
MAXIMUM POWER
OUTPUT
(dBm)
DYNAMIC
RANGE
VSWR
(:1)
Typ.
DC
POWER
Flatness
f
L
ZHL-5W-1
ZHL-5W-1X*
*
Heat sink not included
Open load is not recommended, potentially can cause damage
With no load derate max input power by 20 dB
5
5
f
U
500
500
Min.
40
40
Max.
±1.7
±1.7
(1 dB Compr.)
Min.
+37
+37
Input
(no damage)
0
0
NF
(dB)
Typ.
4.0
4.0
IP3
(dBm)
Typ.
+49
+49
In
2.0
2.0
Out
2.5
2.5
Volt
(V)
Nom.
24
24
Current
(A)
Max.
3.3
3.3
To order without heat sink, add suffix X to model number. Alternative heat sinking and heat
removal must be provided by the user to limit maximum temperature to 65°C, in order to
ensure proper performance. For reference, this requires thermal resistance of user’s external
heat sink to be 0.3°C/W Max.
Maximum Ratings
Operating Temperature
Storage Temperature
DC Voltage
-20°C to 65°C
-55°C to 100°C
+25V Max.
Outline Drawing
Outline Dimensions (
inch
)
mm
A
B
C
7.00
3.25
3.13
177.80 82.55 79.50
D
E
.25 6.500
6.35 165.10
F
G
.38 2.500
9.65 63.50
H
J
K
L
M
N
.156
.88
.43
.62
1.00
2.63
3.96 22.35 10.92 15.75 25.40 66.80
P
Q
R
S
T
wt
.125
.50
6.00
2.23
8.35 grams*
3.18 12.70 152.40 56.64 212.09
1780
*510 grams without heatsink
®
Mini-Circuits
TM
minicircuits.com
REV. A
M121602
ZHL-5W-1
090219
Page 1 of 2
ISO 9001 ISO 14001
AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
IF/RF MICROWAVE COMPONENTS
Typical Performance Data/Curves
ZHL-5W-1
FREQUENCY
(MHz)
GAIN
(dB)
VSWR
(:1)
POUT
at 1 dB
COMPR.
(dBm)
OUT
2.24
2.22
2.22
2.30
2.23
2.15
2.16
2.14
2.09
2.01
2.07
2.08
1.88
1.68
1.71
FREQUENCY
(MHz)
NOISE
FIGURE
(dB)
24V
22V
5.00
10.00
50.00
100.00
140.00
180.00
200.00
240.00
260.00
300.00
360.00
400.00
440.00
480.00
500.00
44.82
45.77
45.99
46.37
46.26
46.13
46.12
45.76
45.32
44.40
44.72
46.08
45.69
43.67
42.93
24V
44.80
45.76
45.96
46.40
46.32
46.22
46.16
45.80
45.43
44.48
44.82
46.18
45.81
43.80
43.03
25V
44.79
45.71
45.93
46.40
46.35
46.27
46.23
45.87
45.47
44.50
44.87
46.23
45.93
43.92
43.15
IN
1.41
1.18
1.12
1.09
1.19
1.26
1.26
1.17
1.14
1.27
1.50
1.48
1.43
1.51
1.51
24V
38.75
39.69
39.68
39.68
39.71
39.59
39.54
39.58
39.64
39.56
39.49
39.23
39.01
38.11
37.42
10.00
100.00
200.00
300.00
500.00
4.67
3.79
3.87
3.96
3.91
ZHL-5W-1
GAIN
50
23V
24V
25V
ZHL-5W-1
VSWR
3.5
3.0
VSWR
2.5
2.0
1.5
1.0
OUTPUT POWER (dBm)
ZHL-5W-1
OUTPUT POWER AT 1-dB COMPRESSION
48
GAIN (dB)
46
44
42
40
0
100
200
300
400
500
FREQUENCY (MHz)
IN
OUT
45
43
41
39
37
35
0
100
200
300
400
500
0
100
200
300
400
500
FREQUENCY (MHz)
FREQUENCY (MHz)
ZHL-5W-1
NOISE FIGURE
7.0
NOISE FIGURE (dB)
6.0
5.0
4.0
3.0
2.0
at 24V
0
100
200
300
FREQUENCY (MHz)
400
500
Mini-Circuits
TM
®
minicircuits.com
ISO 9001 ISO 14001
AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
IF/RF MICROWAVE COMPONENTS
Page 2 of 2
