Amplifier
50
Ω
Features
• wideband, 2 to 8 GHz
• low noise, 4 dB typ.
• high IP3, +40 dBm typ.
• high dynamic range
• high gain, 30 dB min
• laser sealed case
Coaxial
ZVE-8G+
2000 to 8000 MHz
Medium High Power
ZVE-8GX+
CASE STYLE: BN333
Model
ZVE-8G+
ZVE-8GX+
ZVE-8G+
Applications
•
•
•
•
satellite communications
line-of-sight transmitters
signal generators
spread-spectrum communication
Connectors
SMA
SMA
Price
$1095.00 ea.
$1020.00 ea.
Qty.
(1-9)
(1-9)
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
Electrical Specifications
MODEL
NO.
FREQUENCY
(MHz)
GAIN
(dB)
Flatness
Max.
±2.0
±2.0
MAXIMUM
POWER
(dBm)
Output
(1 dB Compr.
Min.)
+30**
+30**
Input
(no damage)
+20
+20
DYNAMIC
RANGE
NF
(dB)
Typ.
4
4
IP3
(dBm)
Typ.
+40
+40
VSWR
(:1)
Max.
In
2.0
2.0
Out
2.0
2.0
DC
POWER
Volt
(V)
Nom.
12
12
Current
(A)
Max.
1.2
1.2
f
L
ZVE-8G+
ZVE-8GX+*
2000
2000
f
U
8000
8000
Min.
30
30
* Heat sink not included
** At 25°C; +30 dBm typ. at 54°C ambient.
Open load is not recommended, potentially can cause damage.
With no load derate max input power by 20 dB
To order without heat sink, add suffix X to model number. Alternative heat sinking and heat
removal must be provided by the user to limit maximum base-plate temperature to 85°C, in
order to ensure proper performance. For reference, this requires thermal resistance of user’s
external heat sink to be 1.3°C/W Max.
Maximum Ratings
Operating Temperature
Storage Temperature
DC Voltage
-55°C to 54°C
-65°C to 150°C
+18V Max.
Permanent damage may occur if any of these limits are exceeded.
Outline
Dimensions
Drawing
Outline
Outline Dimensions (
inch
)
mm
A
B
C
D
E
F
G
1.680 2.130
3.6
7.5
.74
.42
.81
42.67 54.10 91.44 190.50 18.80 10.67 20.57
H
J
K
.30
.55
1.80
7.62 13.97 45.72
L
M
N
P
wt
.34 1.000
.30 6.900 grams*
8.64 25.40
7.62 175.26
700
*100 grams without heatsink
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
www.minicircuits.com
P.O. Box 35166, Brooklyn, NY 11235-0003 (718) 934-4500 sales@minicircuits.com
Mini-Circuits
®
REV. E
M124323
ZVE-8G+
131007
Page 1 of 2
Typical Performance Data/Curves
FREQUENCY
(MHz)
GAIN
(dB)
12V
2000.00
2300.00
2600.00
3200.00
3500.00
3800.00
4100.00
4400.00
4700.00
5000.00
5300.00
5600.00
5900.00
6200.00
6500.00
6800.00
7100.00
7400.00
7700.00
8000.00
35.04
35.84
36.02
35.54
35.33
35.25
35.30
35.08
34.96
34.86
34.78
34.74
34.85
35.03
35.07
35.37
35.63
35.95
35.84
35.41
ZVE-8G+
VSWR
(:1)
IN
1.28
1.36
1.41
1.32
1.27
1.25
1.21
1.17
1.13
1.10
1.09
1.18
1.29
1.43
1.47
1.41
1.40
1.42
1.42
1.27
DIRECTIVITY
(dB)
12V
13.10
14.00
21.60
22.60
43.10
24.80
21.00
25.00
17.30
15.60
17.40
21.30
19.00
16.40
25.70
13.50
18.80
20.10
11.80
18.50
NOISE
FIGURE
(dB)
12V
5.23
4.89
4.44
4.16
4.11
4.05
4.05
4.09
4.10
4.08
4.15
4.16
4.23
4.37
4.33
4.26
4.34
4.36
4.22
4.20
POUT at
1 dB COMPR.
(dBm)
12V
31.11
32.06
32.27
32.63
32.74
32.72
32.13
32.36
32.37
32.56
31.74
32.04
32.01
32.08
31.98
31.97
31.50
31.59
31.48
31.57
OUT
1.36
1.16
1.13
1.30
1.30
1.35
1.44
1.51
1.52
1.51
1.48
1.41
1.28
1.17
1.19
1.32
1.42
1.33
1.29
1.34
40
38
GAIN (dB)
36
34
32
30
2000
at 12V
ZVE-8G+
GAIN
50
DIRECTIVITY (dB)
42
at 12V
ZVE-8G+
DIRECTIVITY
2.5
at 12V
ZVE-8G+
VSWR
IN
OUT
26
18
10
2000
VSWR
34
2.0
1.5
3200
4400
5600
FREQUENCY (MHz)
6800
8000
3200
4400
5600
6800
8000
1.0
2000
3200
4400
5600
6800
8000
FREQUENCY (MHz)
FREQUENCY (MHz)
35
OUTPUT POWER (dBm)
34
33
32
31
ZVE-8G+
OUTPUT POWER AT 1-dB COMPRESSION
at 12V
NOISE FIGURE (dB)
ZVE-8G+
NOISE FIGURE
10
8
6
4
2
0
2000
at 12V
30
2000
3200
4400
5600
FREQUENCY (MHz)
6800
8000
3200
4400
5600
FREQUENCY (MHz)
6800
8000
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
