Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation (as a combiner)
-40°C to 85°C
-55°C to 100°C
1.0W max.
0.1W max.
Coaxial
ZX10-2-42+
50Ω
1900 to 4200 MHz
Features
• low insertion loss, 0.2 dB typ.
• excellent amplitude unbalance
• very good phase unbalance
• small size
• low cost
• protected under U.S. Patent 6,790,049 & 6,963,255
CASE STYLE: FL905
Connectors Model
SMA
ZX10-2-42-S+
Price
$34.95
Qty.
(1-24)
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
3
1
2
Applications
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
• communications
• defense
• PCS/DCS
• DECT
Electrical Specifications (T
AMB
=25°C)
Outline Drawing
FREQ.
RANGE
(MHz)
f
L
-f
U
1900-4200
2600-3400
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 3.0 dB
PHASE
UNBALANCE
(Degrees)
Max.
5.0
4.0
AMPLITUDE
UNBALANCE
(dB)
Max.
0.3
0.3
Typ.
23
23
Min
10
17
Typ. Max.
0.2
0.2
1.2
0.6
Typical Performance Data
Frequency
(MHz)
Total Loss
(dB)
S-1
1900.00
2040.00
2180.00
2460.00
2600.00
3.45
3.42
3.37
3.26
3.19
3.19
3.10
3.11
3.13
3.23
3.26
3.31
3.48
3.54
3.52
ZX10-2-42+
TOTAL LOSS
4.0
1
S-2
3.45
3.44
3.36
3.26
3.19
3.18
3.12
3.11
3.16
3.27
3.29
3.36
3.52
3.58
3.55
Amplitude
Unbalance
(dB)
0.00
0.02
0.01
0.01
0.00
0.01
0.02
0.00
0.03
0.04
0.03
0.05
0.03
0.04
0.03
Isolation
(dB)
Phase
Unbalance
(deg.)
0.70
0.71
0.74
0.91
1.05
1.02
1.18
1.50
1.54
1.30
1.55
1.52
1.48
1.37
1.50
VSWR
S
VSWR
1
VSWR
2
12.33
13.42
14.64
17.92
20.16
23.66
27.75
23.53
20.10
17.91
16.12
14.58
12.21
11.90
11.51
1.79
1.71
1.62
1.47
1.39
1.26
1.14
1.07
1.19
1.31
1.40
1.51
1.78
1.83
1.87
ZX10-2-42+
ISOLATION
1.08
1.09
1.10
1.09
1.08
1.05
1.02
1.03
1.05
1.07
1.07
1.09
1.15
1.16
1.17
1.07
1.08
1.09
1.08
1.08
1.05
1.03
1.02
1.10
1.05
1.06
1.08
1.15
1.16
1.18
Outline Dimensions (
A
.74
18.80
H
.37
9.40
B
.90
22.86
J
--
--
C
.54
13.72
K
.122
3.10
D
.50
12.70
L
.496
12.60
E
.04
1.02
M
.106
2.69
inch
mm
)
G
.29
7.37
F
.16
4.06
2760.00
2920.00
3240.00
3400.00
3540.00
3680.00
3820.00
4100.00
4150.00
4200.00
N
wt
.122 grams
3.10
20.0
1. Total Loss = Insertion Loss + 3dB splitter loss.
35
S-1
S-2
TOTAL LOSS (dB)
ISOLATION (dB)
3.8
3.6
3.4
3.2
3.0
1900
30
25
20
15
10
1900
2360
2820
3280
3740
4200
2360
2820
3280
3740
4200
FREQUENCY (MHz)
FREQUENCY (MHz)
2.0
ZX10-2-42+
VSWR
#S-VSWR
#1-VSWR
#2-VSWR
1.8
VSWR
1.6
1.4
1.2
1.0
1900
electrical schematic
2360
2820
3280
3740
4200
FREQUENCY (MHz)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. J
M142278
ZX10-2-42+
ED-10281/2
HY/RS/CP/AM
130626
