ZX30-17-5-S+

Description
Directional Coupler, 5MHz Min, 2000MHz Max, 1.7dB Insertion Loss-Max, ROHS COMPLIANT, CASE FL905
CategoryWireless rf/communication    Radio frequency and microwave
File Size328KB,1 Pages
ManufacturerMini-Circuits
Websitehttps://www.minicircuits.com
Environmental Compliance
Download Datasheet Parametric Compare View All

ZX30-17-5-S+ Overview

Directional Coupler, 5MHz Min, 2000MHz Max, 1.7dB Insertion Loss-Max, ROHS COMPLIANT, CASE FL905

ZX30-17-5-S+ Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerMini-Circuits
package instructionROHS COMPLIANT, CASE FL905
Reach Compliance Codenot_compliant
ECCN codeEAR99
Other featuresSMA
Characteristic impedance50 Ω
structureCOAXIAL
Maximum input power (CW)30 dBm
Maximum insertion loss1.7 dB
Maximum operating frequency2000 MHz
Minimum operating frequency5 MHz
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
RF/Microwave Device TypesDIRECTIONAL COUPLER
Terminal surfaceNickel (Ni)
Maximum voltage standing wave ratio1.3
Directional Coupler
50Ω
5 to 2000 MHz
-40°C to 85°C
-55°C to 100°C
Coaxial
ZX30-17-5+
Maximum Ratings
Operating Temperature
Storage Temperature
Features
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
INPUT
OUTPUT
COUPLED
1
2
3
• very flat coupling
• very broad, multi-octave
• all welded construction
• protected by U.S Patents 6,140,887 & 6,784,521
& 6,790,049
• cable tv
• instrumentation
• communications receivers & transmitters
• GPS
FREQ.
(MHz)
f
L
-f
U
CASE STYLE: FL905
Connectors Model
SMA
ZX30-17-5-S+
Price
Qty.
$29.95 ea. (1-24)
Applications
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
Directional Coupler Electrical Specifications (T
AMB
= 25°C)
Outline Drawing
COUPLING
(dB)
Nom.
Typ.
Flatness
±0.4
±0.4
±0.3
MAINLINE LOSS
1
(dB)
Typ.
0.7
0.85
1.1
Max.
1.1
1.4
1.7
DIRECTIVITY
(dB)
Typ.
16
18
14
Min.
14
12
-
VSWR POWER
(:1)
INPUT, W
L
Typ.
1.30
1.30
1.30
0.5
0.5
0.5
MU
1.0
1.0
1.0
Max. Max.
5-1000 16.8±0.7
1000-1500 17.5±0.9
1500-2000 18.5±1.0
1. Mainline loss includes theoretical power loss at coupled port.
Typical Performance Data
Frequency
(MHz)
5.00
100.00
400.00
600.00
800.00
1200.00
1400.00
1600.00
1800.00
2000.00
Mainline Loss
(dB)
In-Out
0.66
0.62
0.66
0.71
0.77
0.94
1.05
1.14
1.25
1.36
ZX30-17-5+
MAINLINE LOSS
1.6
MAINLINE LOSS (dB)
1.2
0.8
0.4
0.0
0
400
800
1200
FREQUENCY (MHz)
1600
2000
at RF level of -10 dBm
Coupling
(dB)
In-Cpl
16.40
16.33
16.48
16.64
16.87
17.49
17.83
18.17
18.51
18.83
Directivity
(dB)
16.11
16.24
18.15
21.05
26.80
25.48
19.73
16.19
13.87
11.92
In
22.56
24.38
26.25
27.95
29.39
27.49
27.10
27.06
27.50
26.79
Return Loss
(dB)
Out
26.16
29.66
31.68
31.19
29.15
26.06
26.30
26.48
27.35
29.50
Cpl
17.43
18.91
19.58
19.46
18.78
16.25
14.93
13.79
12.86
12.12
Outline Dimensions (
inch
)
mm
A
.74
18.80
H
.37
9.40
B
.90
22.86
J
--
--
C
.54
13.72
K
.122
3.10
D
.50
12.70
L
.496
12.60
E
.04
1.02
M
.106
2.69
F
.16
4.06
G
.29
7.37
ZX30-17-5+
COUPLING & DIRECTIVITY
60
COUPLING & DIRECTIVITY
(dB)
50
40
30
20
10
0
0
400
800
1200
FREQUENCY (MHz)
1600
2000
at RF level of -10 dBm
COUPLING
DIRECTIVITY
N
wt
.122 grams
3.10
20.0
ZX30-17-5+
RETURN LOSS
50
RETURN LOSS (dB)
40
30
20
10
0
400
800
1200
FREQUENCY (MHz)
1600
2000
at RF level of -10 dBm
Electrical Schematic
CPL
IN
OUT
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
www.minicircuits.com
P.O. Box 35166, Brooklyn, NY 11235-0003 (718) 934-4500 sales@minicircuits.com
Mini-Circuits
®
REV. H
M121747
ED-10213A/3
ZX30-17-5+
WZ/TD/CP/AM
131015
Page 1 of 1

ZX30-17-5-S+ Related Products

ZX30-17-5-S+ ZX30-17-5+
Description Directional Coupler, 5MHz Min, 2000MHz Max, 1.7dB Insertion Loss-Max, ROHS COMPLIANT, CASE FL905 Directional Coupler, 5MHz Min, 2000MHz Max, 1.7dB Insertion Loss-Max, ROHS COMPLIANT, CASE FL905
Is it lead-free? Lead free Lead free
Is it Rohs certified? conform to conform to
Maker Mini-Circuits Mini-Circuits
Reach Compliance Code not_compliant unknown
Other features SMA SMA
Characteristic impedance 50 Ω 50 Ω
structure COAXIAL COAXIAL
Maximum input power (CW) 30 dBm 30 dBm
Maximum insertion loss 1.7 dB 1.7 dB
Maximum operating frequency 2000 MHz 2000 MHz
Minimum operating frequency 5 MHz 5 MHz
Maximum operating temperature 85 °C 85 °C
Minimum operating temperature -40 °C -40 °C
RF/Microwave Device Types DIRECTIONAL COUPLER DIRECTIONAL COUPLER
Terminal surface Nickel (Ni) Nickel (Ni)
Maximum voltage standing wave ratio 1.3 1.3
