Quick Reference Guide
SFP Solutions
TE Connectivity offers a complete SFP product line, including single port and higher density multi-port
SFP cages in single row and stacked configurations. As the market’s demand for increased functionality
and higher data rates continued to grow, we introduced new options, including integrated lightpipes
for port indicators, connectors with improved signal integrity, enhanced EMI springs for increased EMI
suppression, and riding heat sink technology for thermal management.
As a founding member and innovator for the Small Form-factor Pluggable (SFP) Multi-Source
Agreement (MSA), we support the market with a full range of SFP products. From the original 20
position pluggable transceiver (PT) connector and single port cage, the product line has expanded
rapidly to include many other options to increase functionality.
Other options include integrated lightpipes for port indicators and riding heat sinks for improved
thermal management.
FEATURES AND BENEFITS
•
Supports applications up to 4 Gb/s
•
Cages available in single port, ganged, and stacked
•
•
•
•
•
•
•
PRODUCT APPLICATIONS
•
•
•
•
•
•
•
configurations
Stacked cages have integrated connectors, press-fit in
one process step
Uses 20 position PT (Pluggable Transceiver) connector
Direct attach copper cable assemblies for lower cost
with short reach
Integrated lightpipes for port indicators
Enhanced EMI springs for increased EMI suppression
Riding heat sink technology for thermal management
RoHS compliant
Switches
Routers
Servers
Hubs
Storage
Controllers
Network Interface Cards (NICs)
te.com/products/sfp
TE Connectivity
SFP Solutions
20 Pin SMT Connector
PN
1367073-1
1367073-2
1658197-1
1888247-1
1888247-2
Dust Cap
Description
15 µin Au
30 µin Au
PN
1367147-1
1367147-3
1761394-1
Description
Dust Cap w/ AMP logo
Dust Cap w/o AMP logo
Dust Cap (Narrow for Multiport cages)
30 µin Au w/ contact surface treatment
30 µin Au SFP+ Compliant
15 µin Au SFP+ Compliant
Cages
PN
6367034-1
6367035-1
1489669-1
1489779-1
1489962-1
1489962-3
1367629-1
1932002-1
1761014-1
1761007-1
1658744-1
1658723-1
1761008-1
1761015-1
1658939-1
1658391-1
1658628-1
1658859-1
1658390-1
1658629-1
1658758-1
1761327-1
1658894-1
1658895-1
1932068-1
1932069-1
1761967-1
1761896-1
1761497-1
1888424-1
1888425-1
1367643-1
1367645-1
1367645-2
1367645-3
Ports
1x1
1x1
1x1
1x1
1x1
1x1
1x1
1x1
1x2
1x2
1x4
1x4
1x4
1x6
1x6
2x1
2x1
2x1
2x4
2x4
2x4
2x6
2x6
2x6
1x1
1x4
1x6
1x1
1x1
1x2
1x4
1x1
1x1
1x1
1x1
PCB
Termination
Solder
Solder
Press Fit, 8 Pins
Press Fit, 20 Pins
Solder
Solder
Press Fit
Solder
Press Fit
Press Fit
Press Fit
Solder
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit, 8 Pins
Press Fit, 20 Pins
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Press Fit
Requires
Connector
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Lightpipes
Included
No
No
No
No
No
No
Yes
No
No
Yes
No
No
Yes
No
Yes
No
No
Yes
No
No
Yes
No
No
Yes
No
No
No
No
No
No
No
No
No
No
No
Mating
Dust Cap
1367147-x
1367147-x
1367147-x
1367147-x
1367147-x
1367147-x
1367147-x
1367147-x
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1761394-1
1367147-x
1761394-1
1761394-1
1367147-x
1367147-x
1761394-1
1761394-1
1367147-x
1367147-x
1367147-x
1367147-x
Belly-to-Belly
Applications
Yes
Yes
Yes
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Other
Bottom
Top
3.5mm Tail
1.8mm Tail
Preassembled Cages
Standard Profile
Low Profile
Low Profile
Standard Profile
Low Profile
Low Profile
Standard Profile
Low Profile
Low Profile
See Heatsink Options
PCI Heat Sink
SAN Heat Sink
Networking Heat Sink
Note :
Cages that are equipped with with heat sinks also include clips.
te.com/products/sfp
TE Connectivity
SFP Solutions
Heatsinks
PN
1367646-1
1829903-2
1829903-2
1829905-2
Description
Heat Sink Clip
PCI Heat Sink (4.2mm)
SAN Heat Sink (6.5mm)
Networking Heat Sink (13.5mm)
Note :
Only for use with cage PN 1367643-1
Direct Attach Copper Cable Assemblies
PN
1902495
1948134
1948135
Description
2.5 Gbps Passive
4.25 Gbps Passive
4.25 Gbps Active
Dash to Length (meters)
0.5
-1
-1
-1
1
-2
-2
-2
2
-3
-3
-3
3
-4
-4
-4
4
-5
-5
-5
5
-6
-4
-6
6
-7
-5
Cable Assembly Features and Benefits
•
20 Position PCB interface
•
Data rates from 2.5 to 4.25Gbps
•
Robust pull to release latch mechanism
•
Breakout cables to CX4 and HSSDC2 are available
•
Compatible with MSA compliant SFP cages
•
Uses MADISON CABLE brand TURBOTWIN copper cable
Frequently asked questions
What is belly-to-belly mounting?
•
Belly-to-belly mounting allows a customer to install
connectors and cages on both sides of a PCB. This design
reduces board space and is an alternative solution to
stacked connectors.
If I am currently using SFP cabling, can I use
SFP+ host board configurations?
•
Yes. SFP+ configurations support higher rates. You can
design SFP+ products in the host board for future
upgrades.
What data rate does SFP support?
•
SFP supports up to 4Gb/s.
What are the PCB termination options?
•
Cages are offered in press-fit and solder PCB termination
styles.
Is TE’s footprint compatible with other suppliers?
•
It depends. The single port cages are designed to industry
standards. The ganged versions are not compatible with all
other sources.
Are heat sinks available?
•
Yes. Riding heat sink technology is available for
thermal management.
Is application tooling required?
•
Single port assemblies do not require application tooling,
yet ganged assemblies do require application tooling.
te.com/products/sfp
FOR MORE INFORMATION
TE Technical Support Center
USA:
+1 (800) 522-6752
Canada:
+1 (905) 475-6222
Mexico
+52 (0) 55-1106-0800
Latin/S. America:
+54 (0) 11-4733-2200
Germany:
+49 (0) 6251-133-1999
UK:
+44 (0) 800-267666
France:
+33 (0) 1-3420-8686
Netherlands:
+31 (0) 73-6246-999
China:
+86 (0) 400-820-6015
Part numbers in this brochure are RoHS Compliant*, unless marked otherwise.
*as defined www.te.com/leadfree
te.com
© 2012 Tyco Electronics Corporation, a TE Connectivity Ltd. company. All Rights Reserved.
4-1773455-4 CIS LUG PDF 4/2012
MADISON CABLE, TurboTwin, TE Connectivity and the TE connectivity (logo) are trademarks. Other logos,
product and company names mentioned herein may be trademarks of their respective owners.
While TE has made every reasonable effort to ensure the accuracy of the information in this brochure, TE does not guarantee that it is
error-free, nor does TE make any other representation, warranty or guarantee that the information is accurate, correct, reliable or current.
TE reserves the right to make any adjustments to the information contained herein at any time without notice. TE expressly disclaims all
implied warranties regarding the information contained herein, including, but not limited to, any implied warranties of merchantability or
fitness for a particular purpose. The dimensions in this brochure are for reference purposes only and are subject to change without notice.
Specifications are subject to change without notice. Consult TE for the latest dimensions and design specifications.
