F2 Type
2 3
11
2 3 5.5
Ø7
- 0.00
120˚
Ø14
30˚
+0.02
3-M3
Ø45
Ø7
Ø14
Ø42
ØW
- 0.00
+0.015
3-M3
Ø13.6
30˚
ØW
Ø13.6
2-M2
6
RELEASED
REV.
120˚
PCD36
6
30
31
PCD36
Ø46
Electrical Specifications
Supply Voltage
Current
Output Code
Output Mode
Freq. Response
Resolution
3:
5.0 - 12.0VDC ±10%
4:
24.0 VDC ±10%
70mA max
G
N
Gray Code
Pure Binary
Negative Logic (H = 0, L = 1)
10kHz max.
256 (2
8
)
Mechanical
1. Max Shaft Load, radial: 2.0 kgf
axial: 1.0 kgf
2. Moment of Inertia: 2.0 g•cm
2
3. Angular Acceleration: 1x10
5
rad/S
2
4. Max Slewing Speed: 6000 RPM
5. Starting Torque: 10 gf•cm max.
6. Rotational Life: 1 x 10
8
rpm•hrs
Environmental
1. Operating Temp: -10° to +60° C
2. Storage Temp: -20° to +80° C
3. Humidity: -85% RH, no condensation
4. Vibration: 10 - 55 Hz, 1.5 mm, 2 hrs
5. Shock: 50G, 11ms, 3 axes, 3 reps
6. Protection: IP65
Output Circuit
Vcc
Signal
30mA
max
0V
CABLE SHIELD
Ordering Information
MAH36-256_ _ - _
G:
Grey Code
N:
Natural Binary
Bore Diameter:
3: DC5-12V Blank = Ø7mm
8 = Ø8mm (F2 only)
4: DC24V
9525 = Ø0.375" (F2 only)
10 = Ø10mm (F2 only)
Output Waveform
MAH-36-256G
2
2
2
2
2
2
2
2
0
1
2
3
4
5
6
7
8
C U I Stack, Inc.
9615 SW Allen Blvd. #103
Beaverton, OR 97005
Tel: 503/643-4899 FAX: 503/643-6129
DRAWN BY
UPDATED
CHECKED
MAH-36-256N
2
2
2
2
2
2
2
0
1
2
3
4
2
JAS
PART NO.
05/15/99
05/15/99
5
6
7
MAH36-256-XX-X
Ø42
30
A
