The MINMAX MPW1000 series is a range of isolated 30W DC/DC converter modules featuring fully regulated output voltages and wide 2:1 input voltage
ranges.The product comes in a 2”x 1.6”x 0.37” metal package with industry standard pinout. An excellent efficiency allows an operating temperature range
of –40° to +80°C (with derating).
Typical applications for these converters are battery operated equipment and instrumentation, distributed power systems, data communication and general
industrial electronics.
Model Selection Guide
Model
Number
Input
Voltage
(Range)
VDC
MPW1021
MPW1022
MPW1023
MPW1024
MPW1026
MPW1027
MPW1031
MPW1032
MPW1033
MPW1034
MPW1036
MPW1037
MPW1041
MPW1042
MPW1043
MPW1044
MPW1046
MPW1047
VDC
3.3
5
12
15
±12
±15
3.3
5
12
15
±12
±15
3.3
5
12
15
±12
±15
Output
Voltage
Max.
mA
5500
5000
2500
2000
±1250
±1100
5500
5000
2500
2000
±1250
±1100
5500
5000
2500
2000
±1250
±1100
Min.
mA
400
350
166
133
±83
±65
400
350
166
133
±83
±65
400
350
166
133
±83
±65
@Max. Load
mA(typ.)
1867
2480
2841
2841
2841
2841
922
1225
1404
1404
1404
1404
461
613
702
702
702
702
@No Load
mA(typ.)
Output Current
Input Current
Reflected
Ripple
Current
mA (typ.)
Over
Voltage
Protection
VDC
3.9
6.8
15
18
±15
±18
3.9
6.8
15
18
±15
±18
3.9
6.8
15
18
±15
±18
μF
470
Max. capacitive
Load
Efficiency
(typ.)
@Max. Load
%
81
84
88
88
88
88
82
85
89
89
89
89
82
85
89
89
89
89
12
(9 ~ 18)
40
100
220#
24
(18 ~ 36)
470
20
50
220#
48
(36 ~ 75)
470
10
25
220#
# For each output
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2012/03/19 REV:2
Page 1 of 6
®
MPW1000 SERIES
DC/DC CONVERTER 30W
Input Specifications
Parameter
Input Surge Voltage (1 sec. max.)
Model
12V Input Models
24V Input Models
48V Input Models
12V Input Models
24V Input Models
48V Input Models
12V Input Models
24V Input Models
48V Input Models
All Models
Typ.
Max.
Unit
25
---
50
---
100
---
8.6
8.8
9
VDC
17
17.5
18
34
35
36
8.1
8.3
8.5
16
16.5
17
32
33
34
---
---
4500
mW
---
---
5500
mW
Compliance to EN 55022,class A and FCC part 15,class A
Operating Ambient Temperature Range (See Power Derating Curve)
Case Temperature
Storage Temperature Range
Humidity (non condensing)
Cooling
Lead Temperature (1.5mm from case for 10Sec.)
Conditions
Natural Convection
Min.
-40
---
-50
---
Free-Air convection
---
MPW1000 SERIES
DC/DC CONVERTER 30W
Max.
+80
+105
+125
95
260
Unit
℃
℃
℃
% rel. H
℃
Power Derating Curve
100
80
Output Power (%)
Natural
convection
100LFM
200LFM
60
40
400LFM
20
0
-40
~
0
20
40
60
80
100 110
Ambient Temperature
C
Derating Curve without Heatsink
Derating Curve with Heatsink
Notes
1
2
3
4
5
6
7
8
Specifications typical at Ta=+25℃, resistive load, nominal input voltage and rated output current unless otherwise noted.
Transient recovery time is measured to within 1% error band for a step change in output load of 75% to 100%.
Ripple & Noise measurement bandwidth is 0-20 MHz.
All DC/DC converters should be externally fused at the front end for protection.
Other input and output voltage may be available, please contact factory.
To order the converter with heatsink, please add a
suffix H
(e.g.MPW1021H) to order code.
That “natural convection” is about 20LFM but is not equal to still air (0 LFM).
Specifications subject to change without notice.
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2012/03/19 REV:2
Page 3 of 6
®
Package Specifications
Mechanical Dimensions
10.16
[0.40]
10.16
[0.40]
10.16
[0.40]
5.08
[0.20]
MPW1000 SERIES
DC/DC CONVERTER 30W
Pin Connections
Pin
1
1.00
[
0.04
]
Single Output
+Vin
-Vin
Remote On/Off
No Pin
+Vout
-Vout
Trim
Dual Output
+Vin
-Vin
Remote On/Off
+Vout
Common
-Vout
Trim
5
6
7
8
2
4
5
6
7
8
45.72 [1.80]
4
Bottom View
1.1 [0.04]
1
2
50.8 [2.00]
►
All
3.6 [0.14]
dimensions in mm (inches)
(X.XX±0.01)
X.XX±0.13 ( X.XXX±0.005)
5.08
[0.20]
40.6 [1.60]
10.16
[0.40]
7.60
[0.30]
6.0
[0.24]
9.3
[0.37]
►
Tolerance: X.X±0.25
►
Pin
diameter
1.0 ±0.05 (0.04±0.002)
Physical Characteristics
Case Size
Case Material
Base Material
Pin Material
Weight
:
:
:
:
:
50.8x40.6x9.3mm (2.0x1.6x0.37 Inches)
Metal With Non-Conductive Baseplate
FR4 PCB (flammability to UL 94V-0 rated)
Copper Alloy with Gold Plate Over Nickel Underplate
48g
Physical Characteristics
Heatsink Material
Finish
23.0[0.91]
Heatsink (Option H)
:
:
:
Aluminum
Black Anodized Coating
15g
Weight
16.3[0.64]Max
55.32[2.18]Max
Heat-sink
Thermal pad
Clamp
Converter
►
The
advantages of adding a heatsink are:
1. To help heat dissipation and increase the stability
and reliability of DC/DC converters at high
operating temperature atmosphere.
2. To upgrade the operating temperature of DC/DC
converters, please refer to Derating Curve.
E-mail:sales@minmax.com.tw
Tel:886-6-2923150
2012/03/19 REV:2
Page 4 of 6
®
MPW1000 SERIES
DC/DC CONVERTER 30W
Test Setup
Input Reflected-Ripple Current Test Setup
Input reflected-ripple current is measured with a inductor Lin (4.7μH) and Cin (220μF, ESR < 1.0Ω at 100 KHz) to simulate source impedance. Capacitor Cin, offsets
possible battery impedance. Current ripple is measured at the input terminals of the module, measurement bandwidth is 0-500 KHz.
To Oscilloscope
+
Battery
+
Lin
+Vin
Current
Probe
+Out
Load
DC / DC
Converter
-Vin
-Out
Cin
Peak-to-Peak Output Noise Measurement Test
Use a 1μF ceramic capacitor and a 10μF tantalum capacitor. Scope measurement should be made by using a BNC socket, measurement bandwidth is 0-20 MHz.
Position the load between 50 mm and 75 mm from the DC/DC Converter.
+Vin
Single Output
DC / DC
Converter
-Vin
-Out
+Out
Copper Strip
Cout
Copper Strip
Resistive
Scope
Load
+Vin
Dual Output
DC / DC
Converter
-Vin
+Out
Com.
-Out
Copper Strip
Cout
Copper Strip
Cout
Copper Strip
Scope
Scope
Resistive
Load
Technical Notes
Remote On/Off
Positive logic remote on/off turns the module on during a logic high voltage on the remote on/off pin, and off during a logic low. To turn the power module on and off,
the user must supply a switch to control the voltage between the on/off terminal and the -Vin terminal. The switch can be an open collector or equivalent.
A logic low is -1V to 1.0V. A logic high is 2.5V to 100V.
The maximum sink current at the on/off terminal (Pin 4) during a logic low is -100
μA.
The maximum allowable leakage current of a switch connected to the on/off
terminal (Pin 4) at logic hight (2.5V to 100V) is 5μA.
Output Voltage Trim
Output voltage trim allows the user to increase or decrease the output voltage set point of a module. The output voltage can be adjusted by placing an external
resistor (Radj) between the Trim and +Vout or -Vout terminals. By adjusting Radj, the output voltage can be change by ±10% of the nominal output voltage.
+Vin
-Vin
Enable
+Out
Trim Down
-Out
Trim Up
Trim
Trim
Up/Down
10K
A 10K, 1 or 10 Turn trimpot is usually specified for continuous trimming. Trim pin may be safely left floating if it is not used.
Connecting the external resistor (Radj-up) between the Trim and -Vout pins increases the output voltage to set the point as defined in the following equation:
Radj - up =
(
33 × Vout
)
-
(
30 × Vadj
)
Vadj - Vout
Connecting the external resistor (Radj-down) between the Trim and +Vout pins decreases the output voltage set point as defined in the following equation:
Radj - down =
(
36.667 × Vadj
)
-
(
33 × Vout
)
Vout - Vadj
Vout: Nominal Output Voltage
Vadj: Adjusted Output Voltage
Units: VDC/KΩ
Overcurrent Protection
To provide protection in a fault (output overload) condition, the unit is equipped with internal current limiting circuitry and can endure current limiting for an unlimited
duration. At the point of current-limit inception, the unit shifts from voltage control to current control. The unit operates normally once the output current is brought back
into its specified range.
Overvoltage Protection
The output overvoltage clamp consists of control circuitry, which is independent of the primary regulation loop, that monitors the voltage on the output terminals.
The control loop of the clamp has a higher voltage set point than the primary loop. This provides a redundant voltage control that reduces the risk of output
overvoltage. The OVP level can be found in the output data.
