D3Z2V4BF – D3Z36BF
0.4W SURFACE MOUNT PRECISION ZENER DIODE
Features
•
•
•
•
•
400mW Power Dissipation on FR-4 PCB
Very Tight Tolerance on V
Z
Ideally Suited for Automated Assembly Processes
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Mechanical Data
•
•
•
•
•
•
Case: SOD323F
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminal Connections: Cathode Band
Terminals: Finish - Matte Tin annealed over Copper Alloy
leadframe. Solderable per MIL-STD-202, Method 208
Weight: 0.01 grams (approximate)
NEW PRODUCT
SOD323F
Top View
Ordering Information
(Note 4)
Part Number
(Type Number)-7*
* Example: The part number for the 3.6 Volt device would be D3Z3V6BF-7.
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com.
Case
SOD323F
Packaging
3000/Tape & Reel
Marking Information
XX
xx = Product Type Marking Code
(See Electrical Characteristics Table)
YM = Date Code Marking
Y = Year (ex: X = 2010)
M = Month (ex: 9 = September)
Date Code Key
Year
Code
Month
Code
2010
X
Jan
1
Feb
2
2011
Y
Mar
3
Apr
4
YM
2012
Z
May
5
2013
A
Jun
6
Jul
7
2014
B
Aug
8
Sep
9
2015
C
Oct
O
Nov
N
2016
D
Dec
D
D3Z2V4BF – D3Z36BF
Document number: DS35437 Rev. 7 - 2
1 of 5
www.diodes.com
October 2012
© Diodes Incorporated
D3Z2V4BF – D3Z36BF
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Forward Voltage
@ I
F
= 10mA
@ I
F
= 100mA
Symbol
V
F
Value
0.9
1.1
Unit
V
NEW PRODUCT
Thermal Characteristics
Characteristic
Power Dissipation (Note 5)
Thermal Resistance, Junction to Ambient Air (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
T
J,
T
STG
Value
400
312.5
-65 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Type
Number
Marking
Code
Zener Voltage Range
(Note 6)
V
Z
@ I
ZT
Min (V)
2.43
2.69
2.85
3.32
3.60
3.89
4.17
4.55
4.96
5.48
6.06
6.65
7.28
8.02
8.85
9.77
10.78
11.74
12.91
14.34
15.85
17.56
19.52
21.54
23.72
26.19
29.19
32.15
35.07
Max (V)
2.63
2.91
3.07
3.53
3.85
4.16
4.48
4.75
5.20
5.73
6.33
6.93
7.60
8.36
9.23
10.21
11.22
12.24
13.49
14.98
16.51
18.35
20.39
22.47
24.78
27.53
30.69
33.79
36.87
I
ZT
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
Maximum Zener Impedance
f = 1kHz
Z
ZT
@ I
ZT
Ω
100
100
95
95
90
90
90
90
60
50
50
40
10
10
10
10
10
10
10
15
20
20
20
25
30
40
40
40
60
1000
1000
1000
1000
500
500
600
600
250
100
80
60
60
60
60
60
60
80
80
80
80
80
100
100
120
150
200
250
300
Z
ZK
@ I
ZK
I
ZK
mA
0.5
0.5
0.5
0.5
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Maximum Reverse
Current (Note 7)
I
R
μA
50
20
10
5
5
3
3
2
2
1
0.5
0.5
0.5
0.5
0.5
0.1
0.1
0.1
0.1
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
@ V
R
V
1
1
1
1
1
1
1
1
1.5
2.5
3
3.5
4
5
6
7
8
9
10
11
12
13
15
17
19
21
23
25
27
Typical
Temperature
Coefficient
@ I
ZT
= 5mA
mV/°C
-1.6
-1.7
-1.7
-1.9
-2.4
-2.5
-2.5
-1.1
0.3
1.7
2.5
3.4
4.0
4.6
5.0
6.1
7.4
8.2
9.4
12.1
13.7
15.8
16.4
18.4
20.4
18.0
28.6
32.2
34.9
Typical Total
Capacitance
@ V
R
= 0V,
f=1MHz
pF
215
205
195
145
185
175
165
150
145
20
95
82
70
57
50
45
41
36
33
28
25
24
22
20
18
17
17
15
14
D3Z2V4BF
D3Z2V7BF
D3Z3V0BF
D3Z3V3BF
D3Z3V6BF
D3Z3V9BF
D3Z4V3BF
D3Z4V7BF
D3Z5V1BF
D3Z5V6BF
D3Z6V2BF
D3Z6V8BF
D3Z7V5BF
D3Z8V2BF
D3Z9V1BF
D3Z10BF
D3Z11BF
D3Z12BF
D3Z13BF
D3Z15BF
D3Z16BF
D3Z18BF
D3Z20BF
D3Z22BF
D3Z24BF
D3Z27BF
D3Z30BF
D3Z33BF
D3Z36BF
Notes:
L0
L1
L2
L3
L4
L5
L6
L7
GM, L8
L9
LA
LB
LC
LD
LE
LF
LG
LH
LJ
LK
LL
LM
LN
LP
LQ
LR
LS
LT
LU
5. Device mounted on FR-4 PCB with suggested pad layout, board size 35mm * 25mm.
6. The Zener voltage is measured 40ms after power is supplied.
7. Short duration pulse test used to minimize self-heating effect.
