ZSG56W

Description
Single Color LED, Green, Water Clear, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN
CategoryLED optoelectronic/LED    photoelectric
File Size71KB,4 Pages
ManufacturerSUNLED
Websitehttp://www.sunled.com/
Environmental Compliance
Download Datasheet Parametric View All

ZSG56W Overview

Single Color LED, Green, Water Clear, 2mm, 3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN

ZSG56W Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerSUNLED
package instruction3 X 1 MM, 2 MM HEIGHT, SMD, 3 PIN
Reach Compliance Codecompliant
ECCN codeEAR99
colorGREEN
ConfigurationSINGLE
Maximum forward current0.03 A
Lens typeWATER CLEAR
Nominal luminous intensity48.0 mcd
Installation featuresSURFACE MOUNT
Number of functions1
Number of terminals3
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Optoelectronic device typesSINGLE COLOR LED
total height2 mm
method of packingTAPE AND REEL
peak wavelength574 nm
shapeRECTANGULAR
size2 mm
surface mountYES
perspective120 deg
3.0x1.0mm SMD CHIP LED LAMP
ZSG56W
SUN LED
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.15(0.006")
unless otherwise noted.
Ab s o l u t e m a x i m u m r a t i n g s
C)
( T
A
=25
°
C)
Reverse Voltage
Forward Current
Forward Current (Peak)
1/10Duty cycle
0.1ms pulse width
Power dissipation
Operation Temperature
Storage Temperature
V
R
I
F
i
FS
P
T
T
A
Tstg
SG
SG
( In Ga Al P )
5
25
200
105
-40 ~ +85
Un i t
Op e r a t i n g Ch a r a c t e r i s t i c s
( T
A
=25
°
C)
C)
Forward voltage (typ.)
(I F=20mA)
Forward voltage (max.)
(I F=20mA)
Reverse current
(VR=5V)
Wavelength at peak
emission
(I F=20mA)
Spectral Line half-width
(I F=20mA)
Capacitance
(VF=0, f=1MHz)
SG
SG
( In Ga Al P )
Un i t
V
mA
mA
mW
°+
V
F
V
F
I
R
2.25
2.5
10
V
V
uA
λ
peak
565
nm
∆λ
C
25
20
nm
pF
Part
Number
Emitting
Color
Emitting
Material
Lens-color
Luminous
I ntensity
(I F=20mA)
mcd
min.
typ.
20
50
Wavelength
nm
Viewing
Angle
ZSG56W
green
I nGaAlP
water clear
565
120°
1-1
