ZAG45W datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> ZAG45W

Preview

ZAG45W: DescriptionSingle Color LED, Green, Water Clear, 2.4mm, 3.50 X 2.80 MM, SMD, 2 PIN; CategoryLED optoelectronic/LED photoelectric; File Size73KB，4 Pages; ManufacturerSUNLED; Websitehttp://www.sunled.com/

Download Datasheet Parametric View All

ZAG45W Overview

Single Color LED, Green, Water Clear, 2.4mm, 3.50 X 2.80 MM, SMD, 2 PIN

ZAG45W Parametric

Parameter Name	Attribute value
Maker	SUNLED
package instruction	3.50 X 2.80 MM, SMD, 2 PIN
Reach Compliance Code	compliant
ECCN code	EAR99
color	GREEN
Configuration	SEPARATE, 2 ELEMENTS
Maximum forward current	0.03 A
Lens type	WATER CLEAR
Nominal luminous intensity	157.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	1.8 mm
method of packing	TAPE AND REEL
peak wavelength	500 nm
shape	ROUND
size	2.4 mm
surface mount	YES
Terminal pitch	3.1 mm
perspective	120 deg

Preview

Download Datasheet

View All

3.5x2.8mm SMD CHIP LED LAMP

ZAG45W

SUN LED

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is

±0.1(0.004")

unless otherwise noted.

Ab s o l u t e m a x i m u m r a t i n g s

C)

( T

A

=25

°

C)

Reverse voltage

Forward current

Forward current (peak)

1/10Duty cycle

0.1ms pulse width

Power dissipation

Operation temperature

Storage temperature

V

R

I

F

i

FS

P

T

A

Tstg

AG

( I n G a N)

5

30

100

135

-20 ~ +80

-30 ~ +85

Un i t

Op e r a t i n g Ch a r a c t e r i s t i c s

( T

A

=25

°

C)

Forward voltage (typ.)

(I F=20mA)

Forward voltage (max.)

(I F=20mA)

Reverse current

(VR=5V)

Wavelength at peak

emission

(I F=20mA)

Spectral Line half-width

(I F=20mA)

Capacitance

(VF=0, f=1MHz)

AG

( I n G a N)

Un i t

V

mA

mW

°+

V

F

V

F

I

R

3.5

4.0

10

V

uA

λ

peak

502

nm

∆λ

C

30

90

nm

pF

P art

Nu m b e r

Em i t t i n g

Co l o r

Em i t t i n g

Ma te ria l

L e n s -c o l o r

L u min o u s

In t e n si t y

( I F = 20m A )

mc d

min .

ma x .

80

200

Wa v e l e n g t h

nm

Vi e w i n g

An g l e

ZAG45W

green

I nGaN

water clear

502

120°

1-1
