ZDUW10C2: DescriptionSmart/Normal 7 Seg Numeric LED Display, White, 10.16mm, SMD, 20 PIN; CategoryLED optoelectronic/LED photoelectric; File Size55KB，1 Pages; ManufacturerSUNLED; Websitehttp://www.sunled.com/

Download Datasheet Parametric Compare View All

ZDUW10C2 Overview

Smart/Normal 7 Seg Numeric LED Display, White, 10.16mm, SMD, 20 PIN

ZDUW10C2 Parametric

Parameter Name	Attribute value
Maker	SUNLED
package instruction	SMD, 20 PIN
Reach Compliance Code	compliant
ECCN code	EAR99
color	WHITE
Configuration	COMMON CATHODE, 2 DIGITS WITH DECIMAL POINT
Display height	10.16 mm
Maximum forward current	0.03 A
Number of functions	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SMART/NORMAL 7 SEG NUMERIC LED DISPLAY

Preview

Download Datasheet

View All

SMD LED Displays

Part No.

S h ap e

Common

Anode

Common

Cathode

Material

(Emitted Color)

P eak

Wave

Length

(nm)

Electrical/Optical Data

Vf

(V)

If=10mA *20mA

Typ.

Max.

Iv

(ucd)

If=10mA *20mA

Min.

Typ.

Figure

N o.

0.4"(10.16mm)

XZDUR10A2

XZDMDK10A2

XZDMR10A2

XZDMOK10A2

XZDMG10A2

XZDVG10A2

XZDUY10A2

XZDMYK10A2

XZDUB10A2

XZDBB10A2

XZDUW10A2

XZDBW10A2

XZDUR10C2

XZDMDK10C2

XZDMR10C2

XZDMOK10C2

XZDMG10C2

XZDVG10C2

XZDUY10C2

XZDMYK10C2

XZDUB10C2

XZDBB10C2

XZDUW10C2

XZDBW10C2

GaAsP/GaP(Red)

InGaAIP(Red)

GaAIAs(Red)

InGaAIP(Orange)

GaP(Green)

InGaAIP(Green)

GaAsP/GaP(Yellow)

InGaAIP(Yellow)

GaN(Blue)

InGaN(Blue)

GaN(White)

InGaN(White)

627

650

660

610

565

574

590

430

468

-

1.9

1.85

1.8

2.0

1.95

3.6

3.3

*3.8

*3.65

2.5

4.5

4.2

*4.5

*4.2

1200

8000

12000

1900

4700

480

4700

800

3000

*4000

*18000

4900

25900

27400

41100

6500

16400

2400

21900

3500

12100

*16100

*77900

2

X=0.33,Y=0.34

2

XZDxx10A2

XZDxx10C2

Recommended Soldering Pattern

29

1.Soldering Pattern Dimension Unit : mm Tolerance :

±0.25mm

Dimension Unit : mm(inches) Tolerance :

±0.25mm

(0.01")

2.We reserve the right to make changes at any time to enhance the design and / or performance of the product.
