Datasheet> All Categories > LED optoelectronic/LED> photoelectric> XZUYMG62W-1

Preview

XZUYMG62W-1: DescriptionDual Color LED, Yellow/green, Water Clear, 1.25mm, 1.60 X 1.20 MM, 0.65 MM HEIGHT, SMD, 4 PIN; CategoryLED optoelectronic/LED photoelectric; File Size93KB，3 Pages; ManufacturerSUNLED; Websitehttp://www.sunled.com/

Download Datasheet Parametric View All

XZUYMG62W-1 Overview

Dual Color LED, Yellow/green, Water Clear, 1.25mm, 1.60 X 1.20 MM, 0.65 MM HEIGHT, SMD, 4 PIN

XZUYMG62W-1 Parametric

Parameter Name	Attribute value
Maker	SUNLED
package instruction	1.60 X 1.20 MM, 0.65 MM HEIGHT, SMD, 4 PIN
Reach Compliance Code	compliant
ECCN code	EAR99
color	YELLOW/GREEN
Configuration	SEPARATE, 2 ELEMENTS
Maximum forward current	0.03 A
Lens type	WATER CLEAR
Nominal luminous intensity	7.0/11.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	4
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	DUAL COLOR LED
total height	0.65 mm
method of packing	BULK
peak wavelength	590/565 nm
shape	RECTANGULAR
size	1.25 mm
surface mount	YES
Terminal pitch	1.65 mm
perspective	120 deg

Preview

Download Datasheet

View All

1.6x1.2mm BI-COLOR SMD CHIP LED LAMP

XZUYMG62W-1

SUN LED

Email

: sales@us.sunled.com

Web Site : www.sunled.com

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is

±

0.2(0.0079

")

unless otherwise noted.

Absolute maximum ratings

(T

A

=25

°

C)

Reverse voltage

Forward current

Forward current (peak)

1/10Duty cycle

0.1ms pulse width

Power dissipation

Operating temperature

Storage temperature

V

R

I

F

i

FS

P

T

A

Tstg

UY

(GaAsP/GaP)

5

30

140

105

-40 ~ +85

MG

(GaP)

5

25

140

105

-40 ~ +85

Unit

Op e r a t i n g Ch a r a c t e r i s t i c s

C)

( T

A

=25

°

C)

Forward voltage (typ.)

(I F=20mA)

Forward voltage (max.)

(I F=20mA)

Reverse current

(VR=5V)

Wavelength at peak

emission

(I F=20mA)

Wavelength at Dominate

emission

(I F=20mA)

Spectral Line half-width

(I F=20mA)

Capacitance

(V

F

=0V, f=1MHz)

UY

( G a As P /G a P )

MG

( G a P ) Un i t

V

mA

mW

°C

V

F

V

F

I

R

2.1

2.5

10

2.2

2.5

10

V

uA

λ

peak

590

565

nm

λD

588

568

nm

∆λ

C

35

20

30

15

nm

pF

P art

Nu m b e r

Em i t t i n g

Co l o r

Em i t t i n g

Ma te ria l

L e n s -c o l o r

L u min o u s

In t e n si t y

( I F = 20m A )

mc d

min .

ty p .

2.6

7

11

Wa v e l e n g t h

nm

λ

P

590

565

Vi e w i n g

An g l e

2θ1/2

θ

XZUYMG62W-1

Yellow

Green

GaAsP/GaP

GaP

Water Clear

120°

Published Date : OCT 22,2002

Drawing No: XDSA1529

V2

Checked : B.L.LIU

3-1
