SURFACE MOUNT
Cylindrical leadless type for surface mounting
Very low impedance and high ripple current at 100K Hz
Suitable for DC-DC converter, DC-AC inverter, etc.
New expanded CV range, up to 1500µF
Anti-solvent (2 minutes)
Designed for automatic mounting and reflow soldering
SMD - 105˚C LOW IMPEDANCE DVJL
SECTION 1
SPECIFICATION
Item
Tolerance of Rated Capacity (%)
Leakage Current (µA)
Tangent of Loss Angle (tan∂)
Characteristics at high and low
temperature
Performance
± 20
Less than 0.01CV or 3 whichever is larger (after 2min) C: rated capacitance (µF)
Rated Voltage (V)
tan∂ (max)
Rated Voltage (V)
Impedance
Ratio (max)
Test Time
Leakage Current
Percentage of Capacitance Change
Tangent of Loss Angle
Shelf Life (105°C)
Applicable Standards
Z–25°C / Z+20°C
Z–55°C / Z+20°C
6.3
0.28
6.3
4
8
10
0.24
10
3
5
16
0.20
16
2
4
25
0.16
25
2
3
35
0.14
35
2
3
50
0.10
50
2
3
Category Temperature Range (°C) –50 to +105
Endurance (105°C)
(Applied Ripple Current)
2000 hours (8 x 6.5 or less: 1000 hours)
The initial specified value or less
Within ± 25% of initial value
200% or less of the initial specified value
Test Time: 1000 hours: other items are the same as those for endurance. JIS C5101-1
JIS C1501-1, –18 1998 (IEC600384-1 1992, -18 1993)
COEFFICIENT OF FREQUENCY FOR RATED RIPPLE CURRENT
Frequency (Hz)/Rated Voltage
6.3 to 50
50-60
0.64
120
0.5
1k
0.75
10k - 100k
1
OUTLINE DRAWING
DØ
DØ
+
-
L
L
0.3 Ma x
0.3 Ma x
W
W
A
A
+
B
-
B
D
Ø
4
5
6.3
6.3
8
L
5.8 +/- 0.3
5.8 +/- 0.3
5.8 +/- 0.3
7.7 +/- 0.3
10.5 +/- 0.5
10.5 +/- 0.5
A
4.3
5.3
6.6
6.6
8.4
10.4
B
4.3
5.3
6.6
6.6
8.4
10.4
I
2.0
2.3
2.7
2.7
3.0
3.3
W
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.7 to 1.1
0.7 to 1.1
P
1.0
1.5
2.0
2.0
3.1
4.7
I
P
I
I
10
Dimensions in mm
I
P
ORDERING INFORMATION
DVJL
Range
47
Capacitance
µF
6.3
Voltage
LF
Lead Free
79
www.dubilier.co.uk
