Multilayer Ceramic Capacitors
(
For
General
)
Multilayer Ceramic Chip Capacitors
(For General Electronic Equipment)
Series:
ECJ
n
Recommended Applications
n
Features
l
Small in size and wide capacitance range
l
Superior humidity characteristic and long life thanks
to the monolithic construction
l
Excellent solderability and resistance to soldering
heat thanks to terminals with three layers of cop-
per, nickel and solder
l
Low self-inductance and excellent frequency
characteristics
l
Class 1 (T.C. Type)
Temperature compensations, tuned circuits and filter
circuits, where low loss and high stability of
capacitance and high insulation resistance are
required
l
Class 2 (Hi-K Type)
Coupling and By-pass, where low and high stability
of capacitance are not so important
n
Precautions for Handling
See Page 51 to 57
n
Packaging method
See Page 96
n
Discontinued / Revise Part Numbers
See Page 58
n
Explanation of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
C
J
Z
E
B
1
A
1
0
3
K
Tolerance
(Example)
Product Code
(ECJ: Multilayer Ceramic
Chip Capacitors)
!
Packaging
#
Rated Voltage
Styles Code
"
Temperature
Size Code
Characteristics Code
No
1
!
"
$
Nominal Capacitance
%
Capacitance
n
Construction
Name
Ceramic dielectric
Internal electrode
Terminal
electrode
Substrate electrode
Intermediate electrode
External electrode
Unit : mm
2
#
3
4
5
n
Dimensions in mm (not to scale)
Code
Z
L
0
W
1
Size Code
(EIA)
Type“06”
0201
Type“10”
0402
Type“11”
0603
Type“12”
0805
L
0.60±0.03
1.00±0.05
1.6±0.1
2.0±0.1
2.00±0.15
3.20±0.15
3.2±0.2
W
0.30±0.03
0.50±0.05
0.8±0.1
1.25±0.10
1.25±0.15
1.60±0.15
1.6±0.2
T
0.30±0.03
0.50±0.05
0.8±0.1
0.6±0.1
0.85±0.10
1.25±0.10
1.25±0.15
0.6±0.1
0.85±0.10
1.15±0.10
1.6±0.2
L1, L2
0.15±0.05
0.2±0.1
0.3±0.2
T
L
1
L
2
2
0.50±0.25
3
Type“13”
1206
0.6±0.3
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Multilayer Ceramic Capacitors
(
For
General
)
n
Packaging Styles and Standard Packaging Quantity
Code
E
V
F
Y
W
Z
C
f180
reel
Packaging Styles
Paper taping
(Pitch: 2 mm)
Paper taping
(Pitch: 4 mm)
T: Thickness (mm)
TypeÒ06Ó TypeÒ10Ó TypeÒ11Ó
TypeÒ12Ó
TypeÒ13Ó
Quantity (0201) (0402) (0603)
(0805)
(1206)
T=0.3 T=0.5 T=0.8 T=0.6 T=0.85 T=1.25 T=0.6 T=0.85 T=1.15 T=1.6
15,000 10,000
Ñ
Ñ
Ñ
Ñ
Ñ
pcs./reel
Ñ
Ñ
Ñ
Ñ
50,000
Ñ
Ñ
4,000
Ñ
Ñ
Ñ
Ñ
5,000
Ñ
Ñ
Ñ
Ñ
4,000
Ñ
Ñ
Ñ
Ñ
Ñ
3,000
Ñ
Ñ
Ñ
Ñ
Ñ
5,000
Ñ
Ñ
Ñ
Ñ
4,000
Ñ
Ñ
Ñ
Ñ
Ñ
3,000
Ñ
Ñ
Ñ
Ñ
Ñ
Ñ
Ñ
2,000
Ñ
Ñ
Ñ
Embossed taping pcs./
(Pitch: 4 mm)
reel
Paper taping
f330
(Pitch: 2 mm)
reel
*
Paper taping
(Pitch: 4 mm)
Bulk case
10,000 20,000 10,000
Ñ
20,000 10,000
Ñ
Ñ
50,000 15,000 10,000
For Part Number applicable to
f330
reel, please contact us.
n
Temperature Characteristics
l
Class 1 Capacitors
Temp. Char.
Code
Code
C
CD
G
SL
Temp. Coeff. (1)
(ppm/ûC)
0± 30
0± 60
0±120
0±250
+350 to Ð1000
Temp. Coeff.
<2
pF
3 pF
>4
pF
>10
pF
CK(0±250 ppm/ûC) CJ(0±120 ppm/ûC) CH(0±60 ppm/ûC) CG(0±30 ppm/ûC)
*
+350 to Ð1000
*
It is not opplying to the Type Ò06Ó
Note:Measurement of capacitance at 20 ûC and 85 ûC shall be made to calculate temperature characteristic
Temp. Char.
CG
CH
CJ
CK
SL
Rate of Capacitance change at each Temperature (%)
Ð25 ûC
85 ûC
Max.
Min.
Max.
0.33
Ð0.14
0.20
0.49
Ð0.27
0.39
0.82
Ð0.54
0.78
1.54
Ð1.13
1.63
Ñ
Ñ
2.28
Min.
Ð0.20
Ð0.39
Ð0.78
Ð1.63
Ð6.50
(1) These temperature coefficient are calculated between 20 ûC and 85 ûC
For applicable Òtemperature characteristicsÓ, see the lists of standard products on page 16 to 23.
l
Class 2 Capacitors
Code
B
F
Temp. Char.
B
X7R
X5R
F
Y5V
Capacitance Change
±10
%
±15
%
±15
%
+30, Ð80 %
+22, Ð82 %
Measurement Temperature Range
Ð25 to 85 ûC
Ð55 to 125 ûC
Ð55 to 85 ûC
Ð25 to 85 ûC
Ð30 to 85 ûC
Reference Temperature
20 ûC
25 ûC
25 ûC
20 ûC
25 ûC
For applicable Òtemperature characteristicsÓ, see the lists of standard products on page 16 to 23.
n
Rated Voltage
Code
Rated Voltage
1H
DC 50 V
0R5
0.5 pF
1E
DC 25 V
010
1 pF
1C
DC 16 V
100
10 pF
1A
DC 10 V
0J
DC 6.3 V
104
100,000 pF
(0.1µF)
n
Nominal Capacitance
Ex
Nominal
Capacitance
n
Capacitance Tolerance
Class
1
Temp. Char.
CD, SL
Tol. Code
C
D
F
J
K
K
M
Z
Capacitance Tolerance
C
<
5 pF
±0.25
pF
C
<10
pF
±0.5
pF
pF
C =10 pF
±1
±5
%
C
>10
pF
±10
%
±10
%
±20
%
+80, Ð20 %
2
B, X7R, X5R
F, Y5V
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Multilayer Ceramic Capacitors
(
For
General
)
n
Specification and Test Method
Item
Operating
Temperature
Range
Specification
Class 1
Temp. Char. CD
:Ð55 to 125 ûC
Ð25 to 85 ûC
(TypeÒ13Ó, 5600 to 10000 pF)
Temp. Char. SL
:Ð55 to 125 ûC
No break down
Class 2
Temp. Char. B, X7R
: Ð55 to 125 ûC
Temp. Char. B, X5R
:Ð55 to 85 ûC
Temp. Char. F, Y5V
: Ð30 to 85 ûC
Test voltage:
Class 1:Rated voltage
´300
%
Class 2:Rated voltage
´250
%
Duration:1 to 5s
Charge/discharge current:within 50 mA
Measuring voltage:Rated voltage
Duration: 60±5s
Charge/discharge current:within 50 mA
Reference temperature: 20±2 ûC
Class 1:
Nominal capacitance C
<
1000 pF C > 1000 pF
Measuring frequency 1 MHz ± 10% 1 kHz ± 10%
Measuring voltage 0.5 to 5 Vrms 0.5 to 5 Vrms
Class 2:
Pretreatment: The capacitors shall be
kept in a temperature of 150+0/Ð10 ûC
for 1 hour and then shall be stored in
standard condition
*
for 48
±
4 hours,
befor initial measurement.
Nominal capacitance
C
<
1 µF
Measuring frequency 1 kHz
±
10%
Measuring voltage
1.0
±
0.2 Vrms
Temperature
Temp. Char.
Characteristics
CG: 0
±
30 ppm/ ûC
CH: 0
±
60 ppm/ ûC
CJ : 0
±
120 ppm/ ûC
CK: 0
±
250 ppm/ ûC
SL : +350 to Ð1000 ppm/ ûC
Temp. Char.
B :
X7R:
X5R:
F :
Y5V:
±10 %(Ð25 to 85 ûC)
±15 %(Ð55 to 125 ûC)
±15 %(Ð55 to 85 ûC)
+30, Ð80 %(Ð25 to 85 ûC)
+22, Ð82 %(Ð30 to 85 ûC)
Maximum capacitance change at stage 1 to 5
(Unit:¡C)
Stage
1
2
3
(Reference Temp.)
4
5
CD, SL
X7R
B, F
20
25
Ð25
Ð55
20
85
20
25
125
25
Temp. Char.
X5R
25
Ð55
25
85
25
Y5V
25
Ð30
25
85
25
Test Method
Dielectric
Withstanding
Voltage
Insulation
Resistance
(I R)
Cpacitance
Q Factor or
Dissipation
Factor
(tan
d)
10000 MW or 500/C (MW) whichever is less.
Note:DC10V, DC6.3V:100/C(MW)min.
(C:Nominal Cap. in µF)
within the specified tolerance
Q:
C<30 pF: Q>400+20C
30 pF<C<1000 pF:Q>1000
tan
d:
C>1000 pF: tan
d<0.002
(C:Nominal Cap. in pF)
tan
d:0.2
max.
Please confirmation to the
technical reports for details.
]ECJZEB0J104M(0210/X5R/6.3
V/0.1 µF)
ECJ01B0J4741(0402/X5R/6.3 V/0.47 µF)
of 0.50±0.05 Vrms measurement voltage.
*Standard
condition : Temperature 15 to 35 ûC, Relative humidity 45 to 75 %
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Multilayer Ceramic Capacitors
(
For
General
)
Item
Adhesion
Specification
Class 1
Class 2
The terminal electrode shall be free from peeling or signs
of peeling.
Test Method
Applied force: 2 N(Type Ò06Ó)
5 N(Type Ò10Ó, Ò11Ó,
Ò12Ó and Ò13Ó)
Arrow direction for 10 seconds.
Test of Type Ò06Ó and Ò10Ó
1.0
0.5R
0.3(Ò06ÓType)
0.5(Ò10ÓType)
Sample
PC board
Unit : mm
Test of Type Ò11Ó,Ò12Ó and Ò13Ó
1.0
Sample
Bending
Strength
45
±
2
45
±
2
Unit : mm
Vibration
Proof
Appearance: There shall be no cracks and other
mechanical damage.
Capacitance:Shall be within the specifiedtolerance
Q.tand:initial value
Apply a variable vibration of 1.5mm total
amplitude in the 10 to 55 to 10Hz
vibration frequency range swept in 1 min.
in 3 mutually perpendicular directions for
2 hours each, a total of 6 hours.
Solderability More than 95 % of the soldered area of both terminal
electrodes shall be covered with fresh solder.
Solder bath method
Solder temperature:230±5 ûC
Dipping period:4±1 s
Solder:H63A (JISÐZÐ3282)
Preconditioning:Heat treatment
(150 ûC, 1h)/Class 2
Solder temperature:270±5 ûC
Dipping period:3.0±0.5 s
Preheat condition:
Order
Time(s)
Temp.
Type
Type
(¡C)
06,10,11,12
13
1 80 to 100 120 to 180 300 to 360
2 150 to 200 120 to 80 300 to 360
Recovery (Standard condition)
Class 1:24±2 h
Class 2:48±4 h
Preconditioning:Heat treatment
(150 ûC, 1h) /Class 2
Condition of one cycle
Step 1:Minimum operation temp.
30±3
Step 2:Room temp.
±
3
Step 3:Maximum operation temp.
30±3
Step 4:Room temp.
±
3
Number of cycles:5 cycles
Recovery (Standard condition)
Class 1:24±2 h
Class 2:48±4 h
Resistance
to Solder
Heat
Appearance: no mechanical
damage
Capacitance change:
Within
±2.5
%
or
±0.25
pF
whichever is larger.
Q.tan
d:initial
value
IR:initial value
With-stand voltage:
no dielectric breakdown
or damage
Appearance: no mechanical
damage
Capacitance change:
Temp. Char.
B, X7R, X5R : within
±7.5
%
F, Y5V
: within
±20
%
tan
d
initial value
IR:initial value
With-stand voltage:
no dielectric breakdown
or damage
Temperature Appearance: no mechanical
Cycle
damage
Capacitance change:
Within
±2.5
%
or
±0.25
pF
whichever is larger.
Q.tan
d:initial
value
IR:initial value
With-stand voltage:
no dielectric breakdown
or damage
Appearance: no mechanical
damage
Capacitance change:
Temp. Char.
B, X7R, X5R : within
±7.5
%
F, Y5V
: within
±20
%
tan
d
initial value
IR:initial value
With-stand voltage:
no dielectric breakdown
or damage
Bending Value
Appearance: no mechanical
damage
Capacitance change:
Within
±5
%
or
±0.5
pF
whichever is larger.
Bending value:1 mm
Appearance:no mechanical
Bending speed:1 mm/s
damage
Capacitance change:
Temp. Char.
20
B, X7R, X5R : within
±12.5
%
R340
F ,Y5V
: within
±30
%
min.
min.
min.
min.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Multilayer Ceramic Capacitors
(
For
General
)
Item
Damp Heat
(Steady state)
Specification
Class 1
Appearance: no mechanical
damage
Capacitance change:
Within
±5
%
or
±0.5
pF
whichever is larger.
Q:
C<10 pF:Q>200+10C
10 pF<C<30 pF:Q>275+5C/2
30 pF<C<1000 pF:Q>350
Class 2
Appearance: no mechanical
damage
Capacitance change:
Temp. Char.
B, X7R, X5R: Within
±12.5%
Note:ECJ01B0J4741
(0402/X5R/6.3 V/0.47 µF),
Within
±20%
F, Y5V: Within
±30%
tand
0.3 max.
Please confirmation to the
technical reports for details.
IR:
1000 MW or 50/C (MW)
Whichever is less.
Note:DC10 V:10/C(MW) min.
(C:Nominal capacitance in µF)
Appearance: no mechanical
damage
Preconditioning:Voltage treatment
(150ûC, 1h)/Class 2
Temperature:40±2 ûC
Relative humidity:90 to 95%
Applied voltage:Rated voltage
Charge/discharge current: within 50mA
Test period:500+24/0 h
Recovery (Standard condition)
Class 1:24±2 h
Class 2:48±4 h
Test Method
Preconditioning:Heat treatment
(150ûC, 1h)/Class 2
Temperature:40±2 ûC
Relative humidity:90 to 95%
Test period:500+24/0 h
Recovery (Standard condition)
Class 1:24±2 h
Class 2:48±4 h
tand
C>1000 pF:tan
d<0.004
(C:Nominal capacitance in pF)
IR:
1000 MW or 50/C (MW)
Whichever is less.
(C:Nominal capacitance in µF)
Loading
Under Damp
Heat
Appearance: no mechanical
damage
Capacitance change:
Capacitance change:
Within
±7.5
%
or
±0.75
pF Temp. Char.
B, X7R, X5R: Within
±12.5%
whichever is larger.
Note:ECJ01B0J4741
(0402/X5R/6.3 V/0.47 µF),
Q tan
d:
Within
±20%
C<30 pF:Q>100+10C/3
30 pF<C<1000 pF:Q>200
F, Y5V: Within
±30%
tand
tand
C>1000 pF:tan
d<0.004
(C:Nominal capacitance in pF) 0.3 max.
Please confirmation to the
IR:
technical reports for details.
500 MW or 25/C (MW)
Whichever is less.
IR:
(C:Nominal capacitance in µF) 500 MW or 25/C (MW)
Whichever is less.
Note:DC10 V:5/C(MW) min.
(C:Nominal capacitance in µF)
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
京公网安备 11010802033920号
EEWORLD
