UGB10FCT AND UGB10GCT
ULTRAFAST SOFT RECOVERY RECTIFIER
Reverse Voltage - 300-400 Volts Forward Current - 10.0 Amperes
TO-263AB
FEATURES
♦
Plastic package has Underwriters Laboratories
Flammability Classification 94V-0
♦
Ideally suited for free wheeling diode power factor
correction applications
♦
Soft recovery characteristics
♦
Excellent high temperature switching
♦
Optimized to reduce switching losses
♦
High temperature soldering in accordance with
CECC 802 / Reflow guaranteed
♦
Glass passivated chip junction
MECHANICAL DATA
Case: JEDEC TO-263AB molded plastic body
Terminals: Plated leads, solderable per MIL-STD-750,
Method 2026
Polarity: As marked
Mounting Position: Any
Mounting Torque: 5 in. - lbs. max.
Weight: 0.08 ounce, 2.24 grams
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
SYMBOLS
UGB10FCT
UGB10GCT
UNITS
Maximum repetitive peak reverse voltage
Working peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current at T
C
=100°C
Peak forward surge current
8.3ms single half sine-wave superimposed
on rated load (JEDEC Method) per leg
Maximum instantaneous forward voltage per leg
I
F
= 5A
Maximum reverse leakage current
at working peak reverse voltage
Maximum Reverse recovery time per leg at
I
F
=1.0A, di/dt=100A/µs, V
R
=30V, I
rr
=0.1 I
RM
Maximum reverse recovery time per leg at I
F
=0.5A, I
R
=1.0A, I
rr
=0.25A
Maximum reverse recovery current per leg at
I
F
=5A, di/dt=50A/µs,V
R
=30V
T
C
=100°C
Maximum stored charge per leg
I
F
=2A, di/dt=20A/µs, V
R
=30V, I
rr
=0.1 I
RM
Typical thermal resistance from junction to case per leg
Operating junction and storage temperature range
NOTE: (1) Pulse test: 300µs pulse width, 1% duty cycle
NOTICE: Advanced product information is subject to change without notice
V
RRM
V
RWM
V
RMS
V
DC
I
(AV)
I
FSM
T
J
=25°C
T
J
=150°C
T
J
=25°C
T
J
=100°C
300
225
210
300
10
60A
1.30
1.05
10
200
50
35
3.0
50
400
300
280
400
Volts
Volts
Volts
Volts
Amps
Amps
V
F
I
R
t
rr
t
rr
I
RM
Q
rr
R
ΘJC
T
J
, T
STG
Volts
µA
ns
ns
Amps
nC
°C/W
°C
4.5
-40 to +150
4/98
RATINGS AND CHARACTERISTIC CURVES UGB10FCT AND UGB10GCT
001
PEAK FORWARD SURGE CURRENT,
AMPERES
INSTANTANEOUS REVERSE LEAKAGE CURRENT,
MICROAMPERES
CAPACITANCE, pF
FIG. 1 -FORWARD CURRENT DERATING CURVE
RESISTIVE OR INDUCTIVE LOAD
FIG. 2 - MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT PER LEG
8.3ms SINGLE HALF SINE-WAVE
(JEDEC Method)
T
C
=105°C
AVERAGE FORWARD CURRENT, AMPERES
CASE TEMPERATURE, °C
NUMBER OF CYCLES AT 60 H
Z
FIG. 3 - TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS PER LEG
T
J
=25°C
PULSE WIDTH=300µs
1% DUTY CYCLE
FIG. 4 - TYPICAL REVERSE CHARACTERISTICS
PER LEG
INSTANTANEOUS FORWARD CURRENT,
AMPERES
T
J
=125°C
T
J
=100°C
T
J
=125°C
T
J
=100°C
T
J
=25°C
T
J
=25°C
INSTANTANEOUS FORWARD VOLTAGE,
VOLTS
FIG. 5 - REVERSE SWITCHING CHARACTERISTICS
PER LEG
@5A, 50A/µs
PERCENT OF RATED PEAK REVERSE
VOLTAGE, %
FIG. 6 - TYPICAL JUNCTION CAPACITANCE PER LEG
T
J
=125°C
f=1.0 MHz
Vsig=50MVp-p
STORED CHARGE/REVERSE RECOVERY TIME,
nC/ns
@5A, 50A/µs
@2A, 20A/µs
JUNCTION TEMPERATURE, °C
REVERSE VOLTAGE, VOLTS
000,1
001
01
1
521
001
@1A, 100A/µs
1.0
1
t
rr
Q
rr
01
@2A, 20A/µs
001
001
08
06
01
04
02
1
01
1.0
001
000,1
1
001
1
01
6.1
051
4.1
521
2.1
001
1
57
57
8.0
05
6.0
05
4.0
52
52
0
2.0
001
051
002
052
003
05
1
0
01
1.0
001
10.0
5
0
51
01
