UGB10ACT THRU UGB10DCT
ULTRAFAST SOFT RECOVERY RECTIFIER
Reverse Voltage -
50 to 200 Volts
Forward Current -
10.0 Amperes
TO-263AB
0.380 (9.65)
0.420 (10.67)
0.245 (6.22)
MIN
K
0.047 (1.19)
0.055 (1.40)
0.160 (4.06)
0.190 (4.83)
0.045 (1.14)
0.055 (1.40)
FEATURES
♦
Plastic package has Underwriters Laboratories
Flammability Classification 94V-0
♦
Ideally suited for free wheeling diode power factor
correction applications
♦
Soft recovery characteristics
♦
Excellent high temperature switching
♦
Optimized to reduce switching losses
♦
High temperature soldering in accordance with
CECC 802 / Reflow guaranteed
♦
Glass passivated chip junction
0.320 (8.13)
0.360 (9.14)
1
K
2
0.575 (14.60)
0.625 (15.88)
SEATING
PLATE
-T-
0.090 (2.29)
0.110 (2.79)
0.018 (0.46)
0.025 (0.64)
0.027 (0.686)
0.037 (0.940)
0.080 (2.03)
0.110 (2.79)
0.095 (2.41)
0.100 (2.54)
MECHANICAL DATA
Case:
JEDEC TO-263AB molded plastic body
Terminals:
Plated leads, solderable per MIL-STD-750,
Method 2026
Polarity:
As marked
Mounting Position:
Any
Mounting Torque:
5 in. - lbs. max.
Weight:
0.08 ounce, 2.24 grams
PIN 1
K - HEATSINK
PIN 2
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
SYMBOLS UGB10ACT UGB10BCT UGB10CCT UGB10DCT UNITS
Maximum repetitive peak reverse voltage
Working peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current at T
C
=100°C
Peak forward surge current
8.3ms single half sine-wave superimposed
on rated load (JEDEC Method) per leg
Maximum instantaneous forward voltage per leg at I
F
=10A,
I
F
=5A,
I
F
=5A,
Maximum reverse leakage current per leg
at working peak reverse voltage
Maximum reverse recovery time per leg at
I
F
=1.0A, di/dt=100A/µs, V
R
=30V, I
rr
=0.1 I
RM
Maximum reverse recovery time per leg at
I
F
=0.5A, I
R
=1.0A, I
rr
=0.25A
Maximum reverse recovery current per leg at
I
F
=5A, di/dt=50A/µs,V
R
=30V
Maximum stored charge per leg
I
F
=2A, di/dt=20A/µs, V
R
=30V I
rr
=0.1 I
RM
Typical thermal resistance from junction to case per leg
Operating junction and storage temperature range
Maximum
Typical
Maximum
Typical
T
J
=25°C
T
J
=25°C
T
J
=150°C
T
J
=25°C
T
J
=100°C
V
RRM
V
RWM
V
RMS
V
DC
I
(AV)
I
FSM
50
50
35
50
100
100
70
100
10
60
1.25
1.10
0.895
10
200
25
25
15
0.7
5.5
4.5
4.5
150
150
105
150
200
200
140
200
Volts
Volts
Volts
Volts
Amps
Amps
V
F
Volts
µA
ns
ns
Amps
nC
°C/W
°C
I
R
t
rr
t
rr
I
RM
Q
rr
R
ΘJC
T
J
, T
STG
-40 to +150
4/98
RATINGS AND CHARACTERISTIC CURVES UGB10ACT THRU UGB10DCT
FIG. 1 -FORWARD CURRENT DERATING CURVE
AVERAGE FORWARD CURRENT, AMPERES
FIG. 2 - MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT PER LEG
15
10
PEAK FORWARD SURGE CURRENT,
AMPERES
RESISTIVE OR INDUCTIVE LOAD
100
8.3ms SINGLE HALF SINE-WAVE
(JEDEC Method)
T
C
=105°C
10
5
0
1
0
25
50
75
100
125
CASE TEMPERATURE, °C
150
1
10
NUMBER OF CYCLES AT 60 H
Z
100
FIG. 3 - TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS PER LEG
100
INSTANTANEOUS REVERSE LEAKAGE CURRENT,
MICROAMPERES
T
J
=25°C
PULSE WIDTH=300µs
1% DUTY CYCLE
FIG. 4 - TYPICAL REVERSE CHARACTERISTICS
PER LEG
1,000
T
J
=125°C
INSTANTANEOUS FORWARD CURRENT,
AMPERES
10
T
J
=125°C
T
J
=100°C
T
J
=100°C
100
1
10
T
J
=25°C
1
T
J
=25°C
0.1
0.1
0.01
0.2
0.4
0.6
0.8
1.0
1.2
INSTANTANEOUS FORWARD VOLTAGE,
VOLTS
1.4
20
40
60
80
100
PERCENT OF RATED PEAK REVERSE
VOLTAGE, %
STORED CHARGE/REVERSE RECOVERY TIME,
nC/ns
FIG. 5 - REVERSE SWITCHING CHARACTERISTICS
PER LEG
FIG. 6 - TYPICAL JUNCTION CAPACITANCE PER LEG
50
@2A, 20A/µs
100
T
J
=125°C
f=1.0 MHz
Vsig=50MVp-p
40
CAPACITANCE, pF
t
rr
Q
rr
@5A, 50A/µs
30
@1A, 100A/µs
10
20
@5A, 50A/µs
10
@1A, 100A/µs
@2A, 20A/µs
0
25
50
75
100
JUNCTION TEMPERATURE, °C
125
1
0.1
1
10
REVERSE VOLTAGE, VOLTS
100
