254016MA006G300ZL: DescriptionPCMCIA Connector, 6 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Surface Mount Terminal, Black Insulator, Receptacle; CategoryThe connector The connector; File Size74KB，1 Pages; ManufacturerSUYIN-USA; Websitehttp://www.suyinusa.com

Download Datasheet Parametric Compare View All

254016MA006G300ZL Overview

PCMCIA Connector, 6 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Surface Mount Terminal, Black Insulator, Receptacle

254016MA006G300ZL Parametric

Parameter Name	Attribute value
Maker	SUYIN-USA
Reach Compliance Code	unknown
Other features	HIGH TEMPERATURE PLASTIC
Board mount options	LOCATING POSTS
body width	0.102 inch
subject depth	1.108 inch
body length	0.707 inch
Body/casing type	RECEPTACLE
Connector type	PCMCIA CONNECTOR
Contact to complete cooperation	AU
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact style	COMPRESSION
Insulator color	BLACK
Manufacturer's serial number	254016
Plug contact pitch	0.1 inch
Match contact row spacing	0.1 inch
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of ports	1
Number of rows loaded	2
PCB contact pattern	RECTANGULAR
PCB contact row spacing	19.7866 mm
Plating thickness	10u inch
Guideline	UL
reliability	COMMERCIAL
Terminal pitch	2.54 mm
Termination type	SURFACE MOUNT
Total number of contacts	6

Preview

Download Datasheet

View All

254016MA006G300ZL Related Products

	254016MA006G300ZL	254016MA006G100ZL	254016MA006G600ZL	254016MA006G500ZL	254016MA006G200ZL
Description	PCMCIA Connector, 6 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Surface Mount Terminal, Black Insulator, Receptacle	PCMCIA Connector, 6 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Surface Mount Terminal, Black Insulator, Receptacle	PCMCIA Connector, 6 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Surface Mount Terminal, Black Insulator, Receptacle	PCMCIA Connector, 6 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Surface Mount Terminal, Black Insulator, Receptacle	PCMCIA Connector, 6 Contact(s), 2 Row(s), Male, Right Angle, 0.1 inch Pitch, Surface Mount Terminal, Black Insulator, Receptacle
Maker	SUYIN-USA	SUYIN-USA	SUYIN-USA	SUYIN-USA	SUYIN-USA
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown
Other features	HIGH TEMPERATURE PLASTIC	HIGH TEMPERATURE PLASTIC	HIGH TEMPERATURE PLASTIC	HIGH TEMPERATURE PLASTIC	HIGH TEMPERATURE PLASTIC
Board mount options	LOCATING POSTS	LOCATING POSTS	LOCATING POSTS	LOCATING POSTS	LOCATING POSTS
body width	0.102 inch	0.102 inch	0.102 inch	0.102 inch	0.102 inch
subject depth	1.108 inch	1.108 inch	1.108 inch	1.108 inch	1.108 inch
body length	0.707 inch	0.707 inch	0.707 inch	0.707 inch	0.707 inch
Body/casing type	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE
Connector type	PCMCIA CONNECTOR	PCMCIA CONNECTOR	PCMCIA CONNECTOR	PCMCIA CONNECTOR	PCMCIA CONNECTOR
Contact to complete cooperation	AU	AU	AU	AU	AU
Contact point gender	MALE	MALE	MALE	MALE	MALE
Contact material	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE
contact mode	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Contact style	COMPRESSION	COMPRESSION	COMPRESSION	COMPRESSION	COMPRESSION
Insulator color	BLACK	BLACK	BLACK	BLACK	BLACK
Manufacturer's serial number	254016	254016	254016	254016	254016
Plug contact pitch	0.1 inch	0.1 inch	0.1 inch	0.1 inch	0.1 inch
Match contact row spacing	0.1 inch	0.1 inch	0.1 inch	0.1 inch	0.1 inch
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD
Number of connectors	ONE	ONE	ONE	ONE	ONE
PCB row number	2	2	2	2	2
Number of ports	1	1	1	1	1
Number of rows loaded	2	2	2	2	2
PCB contact pattern	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
PCB contact row spacing	19.7866 mm	19.7866 mm	19.7866 mm	19.7866 mm	19.7866 mm
Plating thickness	10u inch	5u inch	50u inch	30u inch	FLASH inch
Guideline	UL	UL	UL	UL	UL
reliability	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Termination type	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Total number of contacts	6	6	6	6	6
