NEW
BCA Series
Medium Gain Sector Antennas
®
For Broadband Wireless Systems
Frequency: 24.25-26.725 GHz
A
ndrew Broadband Communication Antennas
(BCA) offer an ideal solution to the complex and
difficult problem of providing optimum, cost effective
coverage for broadband communications.
Covering the 24.25-26.725 GHz band, this medium
gain 90° sector antenna delivers 18 dBi of gain.
The integration-ready design incorporates a side
entry waveguide flange and three mounting posts
to accommodate integration of radio equipment.
Custom configurations can be engineered to meet
specific customer requirements. Contact your
Andrew representative for details.
Features:
•
Gain Performance: 18 dBi @ 90° sector
•
Optional mount supports mounting to standard
pipe sizes (60-114 mm)
•
Equivalent pattern performance in both
horizontal and vertical polarizations
•
Pattern enhancement - provides continuous
coverage below the horizon
•
Complete band coverage: 24.25-26.725 GHz
•
WR42 cover flange waveguide interface
Broadband Communication Antennas
an ideal solution to providing optimum
cost-effective coverage
P
r
o
d
u
c
t
A
n
n
o
u
n
c
e
m
e
n
t
NEW
BCA Series for Broadband Wireless Systems
Electrical Specifications
Frequency Band
Polarization
Polarization discrim., dB
Input power rating, Watts
VSWR max. (R. L., dB)
Input Connector
Gain, dBi
Low:
Mid:
High:
Ordering Information
BCAM090-242B(*)
385870-3014-001
385870-3021-001
Sector Antenna, 90 degree,
Medium Gain, 24.25-26.725 GHz
Mount Kit, Single Antenna
Mount Kit, Dual Antenna
24.25-26.725 GHz
Horizontal or Vertical
(specify at time of order)
Mechanical Specifications
Survival Wind Velocity,
mph (kph)
Operating Temperature
Size, nominal, inch (mm)
Color
Weight, lb (kg)
125 (200)
-40 to +140°F
(-40 to +60°C)
14.5 x 3.5 x 10.25
(368 x 89 x 260)
Gray
7.94 (3.6)
>30
50
1.5:1 (14)
WR42 Cover Flange
17.8
18.0
18.5
* = H for horizontal or V for vertical polarization
Typical Patterns
Azimuth Pattern
0
0
Elevation Pattern
-10
-10
Relative Gain, dB
-20
Relative Gain, dB
-20
-30
-30
-40
-50
-180
-40
-150
-120
-90
-60
-30
0
30
60
90
120
150
180
80
90
100
110
120
130
Azimuth Angle, degrees
Elevation Angle, degrees
(90 deg = horizontal)
Andrew Corporation
10500 W. 153rd Street
Orland Park, IL 60462 USA
From North America:
Telephone: 1-800-255-1479
Fax: 1-800-349-5444
International:
Telephone: +1-708-873-2307
Fax: +1-708-349-5444
Customer Support Center
From North America:
Telephone: 1-800-255-1479
Fax: 1-800-349-5444
International:
Telephone: +1-708-873-2307
Fax: +1-708-349-5444
On-Line Document Center
• view • e-mail • fax • print
One e-source for information
http://www.andrew.com
Fax-On-Demand
From North America:
1-800-861-1700
International:
+1-708-873-3614
Internet
http://www.andrew.com
All designs, specifications and availabilities of products and services presented in this bulletin are subject to change without notice.
Bulletin 10558 (11/00) Copyright © 2000 Andrew Corporation, Orland Park, IL 60462 USA
Printed in USA
