PKV SERIES
The Piconics PKV series is a surface mount slide core tunable inductor. The PKV provides a rectangular shape easily handled by
automatic equipment for assembly into thick or thin film circuitry. Unique features offered by this series include, an edge plating
provided for forming a solder fillet. The ceramic substrate is interlocked into the molded epoxy case and the internal connectors are
welded. The overall design and materials are carefully selected to withstand several attachments and removals using reflow
techniques without damage or degradation in performance.
Piconics
part
number
PKV160-8I
PKV250-8I
PKV510-8I
PKV760-8I
PKV101-8I
PKV131-8I
PKV151-8I
PKV181-8I
PKV221-8I
PKV271-8I
PKV331-8I
PKV371-8I
PKV471-8I
PKV561-8I
PKV681-8I
PKV761-8I
PKV821-8I
PKV951-8I
PKV102-6I
PKV152-6I
PKV222-6I
PKV272-6I
PKV332-6I
PKV472-6I
PKV582-6I
PKV682-6I
PKV822-6I
PKV103-3F
PKV133-3F
PKV163-3F
PKV203-3F
PKV223-3F
PKV303-3F
PKV363-3F
PKV473-3F
PKV563-3F
PKV683-3F
PKV753-3F
PKV863-3F
PKV104-3F
PKV124-3F
PKV154-1F
PKV474-1F
PKV684-1F
PKV105-1F
L L Low Q min
High uH
at
uH
Lmax
.016 .012
50
.025 .020
50
.051 .036
40
.076 .054
40
.10 .071
30
.13 .093
30
.15 .107
30
.18 .128
30
.22 .157
30
.27 .193
30
.33 .236
30
.37
.27
30
.47 .336
30
.56
.40
30
.68 .485
30
.76 .565
30
.82 .586
30
.95 .678
30
1.0 .666
25
1.5
1.0
25
2.2 1.47
25
2.7
1.8
25
3.3
2.2
25
4.7 3.13
25
5.8 3.87
25
6.8 4.53
25
8.2 5.47
25
10
6.0
25
13
6.5
25
16
8.0
25
20
10
25
22
11
25
30
15
25
36
18
25
47
24
25
56
28
25
68
34
25
75
38
25
86
43
25
100
50
20
120
60
20
150
75
20
470 235
40
680 340
20
1000 500
20
Test
Freq
MHz
200
200
100
100
25
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.25
SRF Min DCR @
MHz
25 c Max
Ohms
1200
.05
1050
.10
740
.19
600
.30
530
.48
525
.51
500
.52
470
.61
400
.67
350
.75
320
.90
275
.93
255
.97
230
1.1
190
1.2
170
1.3
150
1.3
145
1.4
140
1.5
110
1.5
100
2.1
89
2.4
77
2.7
49
3.3
38
4.2
36
4.5
21
4.5
20
4.5
19
4.5
16
5.1
14
5.3
12
6.0
11
6.7
10
7.5
6.5
8.5
6.3
10
6.2
12
5.9
13
5.6
15
5.3
18
4.4
21
4.0
27
2.0
45
2.1
52
1.0
112
Idc Max
ma
250
250
250
250
250
200
200
180
180
180
140
140
100
100
100
100
100
100
100
100
80
75
65
60
58
55
55
55
53
50
43
43
40
40
39
35
30
30
28
27
25
22
16
15
11
FEATURES:
•
Edge Plating
•
Metallization on Contact Area
•
Interlocked Ceramic Substrate
•
Welded Internal Connections
•
Reflow Compatibility
•
Slide Core Tunable
ABSOLUTE MAXIMUM RATINGS:
•
Operating temperature: -55° C to
+ 125° C
•
Storage temperature: -55° C to
+ 125° C
•
Dielectric withstanding voltage: Method 301
of MIL-STD-202, test voltage 200 volts rms.
•
Altitude: 70,000 Feet
Piconics Inc.
www.Piconics.com
26 Cummings Rd Tyngsboro, MA 01879
E-Mail:
Sales@Piconics.com
Tel: 978-649-7501
Fax: 978-649-9643
