IMC-0402
Vishay Dale
High Frequency, Surface Mount, Laser Spiral, Coated Inductors
FEATURES
• Very small size
• High self-resonant frequency values
• High Q values relative to size at higher
frequencies
• Coated coil provides protection and moisture resistance
• Compatible with vapor phase and infrared reflow soldering
• Tape and reel packaging for automatic handling,
10 000/reel, EIA-481
• L and Q value not affected by mounting orientation
• Compliant to RoHS directive 2002/95/EC
STANDARD ELECTRICAL SPECIFICATIONS
IND.
(nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
TEST
RATED
FREQ.
DC
SRF DCR
(MHz)
MIN. MAX. CURRENT
(1)
Q
L
Q MIN. (MHz) (Ω)
(mA)
100 800 21
6000 0.05
400
100 800 21
6000 0.06
400
100 800 21
6000 0.07
400
100 800 21
6000 0.08
400
100 800 21
6000 0.09
400
100 800 21
5500 0.10
400
100 800 21
5500 0.12
400
100 800 20
5200 0.15
360
100 800 20
4800 0.17
360
100 800 20
4600 0.19
340
100 800 19
4000 0.30
320
100 800 19
3500 0.35
320
100 800 19
2800 0.41
320
100 800 19
2800 0.45
320
100 800 19
2500 0.60
240
100 800 19
2200 0.70
240
100 800 19
2000 0.80
200
100 800 19
1800 1.20
200
100 800 18
1800 1.40
170
100 800 18
1800 1.70
150
100 800 17
1800 2.10
140
100 800 17
1500 2.50
130
100 800 15
1500 4.00
120
100 800 15
1400 4.50
110
100 800 14
1200 5.50
90
ELECTRICAL SPECIFICATIONS
Inductance Range:
1.0 nH to 100 nH
Inductance and Tolerance:
± 0.3 nH for 1.0 nH to 5.6 nH,
± 5 % for 6.8 nH to 100 nH
Operating Temperature:
- 40 °C to + 100 °C
Core Material:
Ceramic
TOL.
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
5%
5%
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
TEST EQUIPMENT
• Inductance and Q measured on HP4291B
• SRF measured on HP8753E
• DCR measured on HP4338B
DIMENSIONS
in inches [millimeters]
0.008 [0.2]
0.020 ± 0.004
[0.5 ± 0.1]
0.039 ± 0.004
[1.0 ± 0.1]
0.020 ± 0.004
[0.5 ± 0.1]
Solder Pad Layout
0.02 [0.50]
0.020 [0.50]
0.063 [1.60]
Note
(1)
Value obtained when current flows and temperature has risen 15 °C
DESCRIPTION
IMC-0402
MODEL
10 nH
INDUCTANCE VALUE
±5%
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e4
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
M
PRODUCT
FAMILY
C
0
4
SIZE
0
2
E
R
1
0
INDUCTANCE
VALUE
N
J
TOL.
PACKAGE
CODE
Document Number: 34038
Revision: 10-Aug-06
For technical questions, contact:
magnetics@vishay.com
www.vishay.com
1
