FEATURES
Small size
–
Safety Agency approved
–
85°C, 85% RH
operating humidity range
EMI filters
–
Line bypass
–
Across the line
–
Antenna
coupling
-40°C to +110°C
+10% at 1 kHz, 20°C
CSA
250/310
ENEC
305
CQC
275
UL
250/310
APPLICATIONS
Operating Temperature Range
Capacitance Tolerance
AC voltage
(50/60 Hz)
Dissipation Factor
at 1 kHz and 20°C
Capacitance
Insulation Resistance
@20°C (<70% RH)for 1 minute at
100VDC applied
Self Inductance
<0.33uF
Tan
δ
.1% Max
Terminal to Terminal
15000
MΩ
Terminal to Case
Dielectric Strength
>30000
MΩ
at 100VDC
>5000
MΩ
at 500VDC
>30000
MΩ
at 100VDC
5000
MΩxuF
>0.33uF
>5000
MΩ
at 500VDC
<1 nano-Henry per mm of lead spacing and lead length
C<.0068uF, 1500 VAC or 2121 VDC applied for 60 Seconds
C>.0068uF, 1000 VAC or 1768 VDC applied for 60 seconds
Terminal to Terminal
Cut-off current: 2A ac or 10mAdc
Current limiting resistance: 1Ω/V
2050VDC applied between the terminals and case for 60 Seconds and 20°C
Terminal to case
Capacitance change
Dissipation Factor change
Insulation resistance change
1000 Hours at 85% RH, 85°C and 240VAC applied.
<10% of initially measured value
<1.0% at 1kHz
>50% of initially specified value (T-T)
-200ppm/°C, +100ppm/°C
Metallized Polypropylene film
Vacuum deposited Metal layers
Flame retardant Solvent resistant plastic case with epoxy end fill (UL94V-0)
Lead free tinned copper leads
Humidity test
Capacitance temperature
coefficient
Construction
Electrodes
Coating
Lead terminations
All dimensions in (mm)
* 17mm lead length available upon request
X capacitors are used to suppress electrical noise by reducing the input impedance of
the device incorporating the capacitor.
X capacitors are connected across the supply line where failure of the capacitor will
not result in personal exposure to electrical shock.
X2 capacitors are to be used in applications where the peak voltage is <1200V.
Safety agency
UL
Standard
UL 1414(.0047 to 1uF)
UL 1283 (.0047 to 10uF)
Voltage
310
310
310
250
305
275
Class
FOWX2*
FOWX8*
FOKY2^
FOKY8^
EMI
Audio/video equipment
X2
X2
Certificate number
E317135
E317132
241565
SE/07119
CSA
ENEC
(SEMKO)
CQC
Class 2221 02 (.0047 to 10uF)
Class 2221 51 (.0047 to 1.0uF)
IEC 60384-14/ SE/0252-3
GB/T14472-1998
CQC07001021654
CQC07001021577
*Antenna coupling, Line bypass, across the line
^Electromagnetic interference filter
