K7P401823B-H65000 datasheet, PDF

Datasheet> All Categories > storage> storage> K7P401823B-H65000

K7P401823B-H65000: DescriptionStandard SRAM, 256KX18, 6.5ns, CMOS, PBGA119, 14 X 22 MM, BGA-119; Categorystorage storage; File Size411KB，13 Pages; ManufacturerSAMSUNG; Websitehttp://www.samsung.com/Products/Semiconductor/

Download Datasheet Parametric Compare View All

K7P401823B-H65000 Overview

Standard SRAM, 256KX18, 6.5ns, CMOS, PBGA119, 14 X 22 MM, BGA-119

K7P401823B-H65000 Parametric

Parameter Name	Attribute value
Maker	SAMSUNG
Objectid	1976775912
Parts packaging code	BGA
package instruction	BGA,
Contacts	119
Reach Compliance Code	unknown
ECCN code	3A991.B.2.A
compound_id	9914356
Maximum access time	6.5 ns
Other features	PIPELINED ARCHITECTURE
JESD-30 code	R-PBGA-B119
length	22 mm
memory density	4718592 bit
Memory IC Type	STANDARD SRAM
memory width	18
Number of functions	1
Number of terminals	119
word count	262144 words
character code	256000
Operating mode	SYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	256KX18
Package body material	PLASTIC/EPOXY
encapsulated code	BGA
Package shape	RECTANGULAR
Package form	GRID ARRAY
Parallel/Serial	PARALLEL
Certification status	Not Qualified
Maximum supply voltage (Vsup)	3.45 V
Minimum supply voltage (Vsup)	3.15 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	BALL
Terminal pitch	1.27 mm
Terminal location	BOTTOM
width	14 mm

Preview

Download Datasheet

View All

K7P403623B

K7P401823B

Document Title

128Kx36 & 256Kx18 Synchronous Pipelined SRAM

Preliminary

128Kx36 & 256Kx18 SRAM

Revision History

Rev. No.

Rev. 0.0

Rev. 0.1

History

- Preliminary specification release

- Update DC CHARACTERISTICS

x36 : I

DD6

: TBD -> 300, I

DD65

-> 290, I

DD7

-> 280.

x18 : I

DD6

: TBD -> 290, I

DD65

-> 280, I

DD7

-> 270.

- Change simbol in DC CHARACTERISTICS

DD6

, I

DD65

, I

DD7

-> I

DD65

, I

DD70

, I

DD75

Draft Date

Oct. 2002

Jan. 2003

Remark

Preliminary

Feb. 2003

Rev. 0.2

Preliminary

The attached data sheets are prepared and approved by SAMSUNG Electronics. SAMSUNG Electronics CO., LTD. reserve the right to change the

specifications. SAMSUNG Electronics will evaluate and reply to your requests and questions on the parameters of this device. If you have any ques-

tions, please contact the SAMSUNG branch office near your office, call or cortact Headquarters.

-1-

Feb. 2003

Rev 0.2
