High Intensity Single and Multi Color Arrays
15 LED Circular & Linear Bargraphs
Features
Applications
Options
•
Choice of Single and
Multi Color in Same
Bargraph
Special Colors
•
Uniform LED Appearance
•
Fast Turn On/Off Time
•
Solid-State, High Shock/
•
High On/Off Contrast
Vibration Resistant
•
Linear Bargraphs are Dip
•
Segment Size 1.8 x 5mm Socket Compatible
15 LED Circular Bargraph
CBG1500X3
•
Long Life / 100,000+ Hours
•
Instrumentation
•
Available in Standard and
•
Process Controller
Gages
•
Level Indicators
•
Audio Level Indicators
•
Temperature Indicators
•
Speed Indicators
Part Selection
Part Number
CBG1500R6B
.118
.440
[11.18]
•
Optional Colors:
Orange,
Pure Green, Blue
•
Sunlight Visible LEDs
•
Low Current 2mA LEDs
•
Surface Mount
•
Bi-Color/Tri-Color LEDs
Electrical-Optical
Characteristics (Ta = 25˚C)
typ
typ/max
λP
nm
Color
UL RED
HE RED
Lens Type/
If = mA Iv mcd Vf = V
Color
typ
10
10
DIFFUSED
10
10
8.0
5.0
4.5
5.0
1.7/2.5 660
1.9/2.5 635
2.0/2.5 585
2.1/2.5 565
CBG1500R3B
CBG1500Y3B YELLOW
CBG1500G3B HE GREEN
R.700
[17.8]
Custom Mixed Color
Part Number Example: CBG1500T3-9G5Y1R
1) Black face bargraphs are illustrated and listed as Part Numbers.
2) Grey face bargraphs are available. When ordering grey , remove the last "B" from
the Part Number in this table's left column.
1
10
11
12
13
14
15
16
9
8
7
6
5
4
R.618
3
2
R.400
COMMON
CATHODE (–)
REAR VIEW
1
2
3
4
5
6
7
8
9
10
11 12
13 14 15 16
Note: Segment color is white when off
15 LED Low Profile Linear Bargraph
LBG1500X3
1.50
[38.1]
Part Selection
Electrical-Optical
Part Number
LBG1500R6B
LBG1500R3B
Color
UL RED
HE RED
YELLOW
Lens Type/
Characteristics (Ta = 25˚C)
If = mA Iv mcd Vf = V
Color
λP
typ
typ
typ/max
nm
10
10
DIFFUSED
10
8.0
5.0
4.5
5.0
1.7/2.5 660
1.9/2.5 635
2.0/2.5 585
.400
[10.16]
.245
[6.22]
Pin 1
LBG1500Y3B
2.1/2.5 565
10
LBG1500G3B HE GREEN
Custom Mixed Color
Part Number Example: LBG1500T3-9G5Y1R
.010
[0.25]
.118
[3.0]
.308
[7.82]
.100 x 14 + 1.400
[35.56]
.020
[0.5]
1) Black face bargraphs are illustrated and listed as Part Numbers.
2) Grey face bargraphs are available. When ordering grey , remove the last "B" from
the Part Number in this table's left column.
30
29 28
27 26
25 24
23 22
21 20
19 18
17 16
Note: Segment color is white when off
1
2
3
4
5
6
7
8
9
10
11 12
13 14 15
23105 Kashiwa Court, Torrance, CA 90505
Phone: (800) 579-4875 or (310) 534-1505 Fax: (310) 534-1424
E-mail: webmaster@ledtronics.com
Website: http://www.ledtronics.com
Log # 075 Rev 8-99
