STF
Features
Standard case sizes
Low Profile
+105°C, 5mm Height Low Profile
Radial Lead Aluminum Electrolytic
Capacitors
Lead free leads
Applications
Bypass
Coupling
Filtering
De-coupling
Specifications
Operating Temperature
Range
Capacitance Tolerance
WVDC
Surge
voltage
SVDC
Dissipation
WVDC
Tan
δ
Factor
Leakage current
Low
temperature
stability
Impedance ratio
(120 Hz)
-55°C to +105°C
6.3
7.9
6.3
.28
10
13
10
.24
16
20
16
.2
25
32
25
.16
+20% at 120 Hz, 20°C
35
50
44
63
35
50
.13
.12
2 Minutes
.01CV or 3uA,Whichever is greater
WVDC
-25°C to +20°C
-40°C to +20°C
6.3
3
6
10
3
5
16
2
4
25
2
3
35
2
3
50
2
3
Load Life
Shelf Life
Ripple Current Multipliers
1000 hours at 105°C with rated WVDC and ripple current applied
Capacitance change
<20% of initial measured value
Dissipation factor
<150% of maximum specified value
Leakage current
>100% of maximum specified value
1000 hours at 105°C with no voltage applied
Capacitance change
<20% initial measured value
Dissipation factor
<200% of maximum specified value
Leakage current
>100% of maximum specified value
Frequency (Hz)
Temperature (°C)
50
120
400
1k
10k
100k
+105
+85
+60
.8
1.0
1.3
1.45
1.65
1.7
1.0
1.4
1.75
D+0.5
4
5
S
1.5
2.0
d
.45
0.5
L
1
=L+1.5mm Max.
D
1
=D+0.5mm Max.
S
1
=S+0.5 mm
6.3
2.5
0.5
mm
