TK70728SCL

Description
Fixed Positive LDO Regulator, 2.8V, 0.16V Dropout, PDSO5, SOT-23, 5 PIN
CategoryPower/power management    The power supply circuit
File Size426KB,25 Pages
ManufacturerTOKO, INC.
Websitehttps://www.murata.com/
Download Datasheet Parametric View All

TK70728SCL Overview

Fixed Positive LDO Regulator, 2.8V, 0.16V Dropout, PDSO5, SOT-23, 5 PIN

TK70728SCL Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerTOKO, INC.
package instructionLSSOP,
Reach Compliance Codeunknown
ECCN codeEAR99
Maximum drop-back voltage 10.16 V
JESD-30 codeR-PDSO-G5
length2.9 mm
Number of functions1
Number of terminals5
Maximum output current 10.1 A
Maximum output voltage 12.85 V
Minimum output voltage 12.75 V
Nominal output voltage 12.8 V
Package body materialPLASTIC/EPOXY
encapsulated codeLSSOP
Package shapeRECTANGULAR
Package formSMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Regulator typeFIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Maximum seat height1.3 mm
surface mountYES
Terminal formGULL WING
Terminal pitch0.95 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
width1.6 mm
APPLICATION MANUAL
LDO Regulator IC
TK705xxS/TK707xxS,TK706xxH/TK708xxH
CONTENTS
1 . DESCRIPTION
2 . FEATURES
3 . APPLICATIONS
4 . PIN CONFIGURATION
5 . PACKAGE OUTLINE
6 . BLOCK DIAGRAM
7 . ABSOLUTE MAXIMUM RATINGS
8 . ELECTRICAL CHARACTERISTICS
9 . TEST CIRCUIT
10 . TYPICAL CHARACTERISTICS
11 . PIN DESCRIPTION
12 . APPLICATIONS INFORMATION
13 . NOTES
14. OFFICES
2
2
2
2
3
5
5
6
9
10
20
21
25
25
