Preface
Thank you very much for making use of Toshiba microcomputer LSI.
Before using this LSI, refer to section “Points of Note and Restrictions”.
Especially, take care below cautions.
**CAUTION**
How to release the HALT mode
Usually, interrupts can release all halts stats. However, the interrupts
=
(
NMI
,
INT0, INTRTC), which can release the HALT mode may not be able to do so if
they are input during the period CPU is shifting to the HALT mode (for about 5
clocks of f
FPH
) with IDLE1 or STOP mode (IDLE2 is not applicable to this case).
(In this case, an interupt request is kept on hold internally.)
If another interupt is generated after it has shifted to HALT mode completely,
halt status can be released without difficultly. The priority of this interrupt is
compare with that of the interrupt kept on hold internally, and the interrupt with
higher priority is handled first followed by the other interrupt.
TMP91FW27
CMOS 16-Bit Microcontrollers
TMP91FW27UG / TMP91FW27FG
1.
Outline and Features
TMP91FW27 is a high-speed 16-bit microcontroller designed for the control of various mid-to
large-scale equipment.
TMP91FW27UG and TMP91FW27FG come in a 64-pin flat package. Listed below are the
features.
(1) High-speed 16-bit CPU (900/L1 CPU)
•
•
•
•
•
Instruction mnemonics are upward-compatible with TLCS-90/900
16 Mbytes of linear address space
General-purpose registers and register banks
16-bit multiplication and division instructions; bit transfer and arithmetic instructions
Micro DMA: 4 channels (593 ns /2 bytes at 27 MHz)
(2) Minimum instruction execution time: 148 ns (at 27 MHz)
(3) Built-in RAM: 12 Kbytes
Built-in ROM: 128-Kbyte Flash memory
4-Kbyte mask ROM (used for booting)
RESTRICTIONS ON PRODUCT USE
•
The information contained herein is subject to change without notice.
20070701-EN
•
TOSHIBA is continually working to improve the quality and reliability of its products. Nevertheless, semiconductor
devices in general can malfunction or fail due to their inherent electrical sensitivity and vulnerability to physical
stress. It is the responsibility of the buyer, when utilizing TOSHIBA products, to comply with the standards of safety
in making a safe design for the entire system, and to avoid situations in which a malfunction or failure of such
TOSHIBA products could cause loss of human life, bodily injury or damage to property.
In developing your designs, please ensure that TOSHIBA products are used within specified operating ranges as
set forth in the most recent TOSHIBA products specifications. Also, please keep in mind the precautions and
conditions set forth in the “Handling Guide for Semiconductor Devices,” or “TOSHIBA Semiconductor Reliability
Handbook” etc.
•
The TOSHIBA products listed in this document are intended for usage in general electronics applications (computer,
personal equipment, office equipment, measuring equipment, industrial robotics, domestic appliances, etc.).These
TOSHIBA products are neither intended nor warranted for usage in equipment that requires extraordinarily high
quality and/or reliability or a malfunction or failure of which may cause loss of human life or bodily injury
(“Unintended Usage”). Unintended Usage include atomic energy control instruments, airplane or spaceship
instruments, transportation instruments, traffic signal instruments, combustion control instruments, medical
instruments, all types of safety devices, etc.. Unintended Usage of TOSHIBA products listed in his document shall
be made at the customer’s own risk.
•
The products described in this document shall not be used or embedded to any downstream products of which
manufacture, use and/or sale are prohibited under any applicable laws and regulations.
•
The information contained herein is presented only as a guide for the applications of our products. No responsibility
is assumed by TOSHIBA for any infringements of patents or other rights of the third parties which may result from its
use. No license is granted by implication or otherwise under any patents or other rights of TOSHIBA or the third
parties.
•
Please contact your sales representative for product-by-product details in this document regarding RoHS
compatibility. Please use these products in this document in compliance with all applicable laws and regulations that
regulate the inclusion or use of controlled substances. Toshiba assumes no liability for damage or losses occurring
as a result of noncompliance with applicable laws and regulations.
This product uses the Super Flash® technology under the license of Silicon Storage Technology,Inc.
Super Flash® is a registered trademark of Silicon Storage Technology,Inc.
91FW27-1
2007-11-02
TMP91FW27
(4) External memory expansion
•
•
Expandable up to 16 Mbytes (shared program/data area)
Can simultaneously support 8-/16-bit width external data bus (Dynamic data bus sizing)
(5) 8-bit timers: 6 channels
(6) 16-bit timers: 1 channel
(7) General-purpose serial interface: 2 channels
•
•
•
UART/Synchronous mode: 2 channels
IrDA Ver.1.0 (115.2 kbps) mode selectable: 1 channel
I
2
C bus mode/clock synchronous mode selectable
(8) Serial bus interface: 1 channel
(9) 10-bit AD converter (sample hold circuit is inside): 4 channels
(10) Watchdog timer
(11) Special timer for CLOCK
(12) Chip select/Wait controller: 4 blocks
(13) Interrupts: 34 interrupts
•
•
•
9 CPU interrupts:
Software interrupt instruction and illegal instruction
21 internal interrupts: 7 priority levels are selectable
4 external interrupts: 7 priority levels are selectable
(among 3 interrupts are selectable edge mode)
(14) Input/output ports: 53 pins
(15) Stand-by function
Three Halt modes: IDLE2 (programmable), IDLE1 and STOP
(16) Clock controller
•
•
•
•
•
•
•
Clock gear function: Select a High-frequency clock fc to fc/16
Special timer for CLOCK (fs
=
32.768 kHz)
Vcc
=
2.7 V to 3.6 V (fc max
=
27 MHz, flash memory read operation)
Vcc
=
2.2 V to 3.6 V (fc max
=
16 MHz, flash memory read operation)
Vcc
=
2.7 V to 3.6 V (fc max
=
27 MHz, flash memory erase/program operations)
LQFP64-P-1010-0.50D (TMP91FW27UG)
QFP64-P-1414-0.80A (TMP91FW27FG)
(17) Operating voltage
(18)Package
91FW27-2
2007-11-02
