SM Crystal for Bluetooth / Wireless
Specifications
GSX-533
Product
GSX-533
Option
Codes
Parameters
Frequency range:
12.0 ~ 44.0MHz
Calibration tolerance:
±10ppm
±15ppm
±20ppm
Other values (±7.5 ~ ±100ppm)
±10ppm
±15ppm
±20ppm
±30ppm
Other values (±7.5 ~ ±100ppm)
1
P
2
specify
1
P
2
3
specify
1
2
3
specify
Temperature stability:
5.10
(max)
3.30
(max)
0.90
(max)
ACTUAL SIZE
SOLDER PAD LAYOUT
Operating temperature range:
-10 to +60°C
-20 to +70°C
-30 to +80°C
Other values
1.30
1.00
1.30
1
4
2
3
4
1.40
1
3
2
Storage temperature range:
-40 to +85°C
Circuit condition:
9pF
12pF
16pF
18pF
20pF
Other values
Fundamental
N
B
D
E
F
specify
F
2.40
PAD
1
2
3
4
CONNECTION
Crystal
Ground & lid
Crystal
Ground & lid
1.60 2.20 1.60
TOP VIEW
Oscillation mode:
Equivalent series resistance:
40 max
Scale 3:1
Frequency perturbation:
±1ppm max
Ageing:
±1ppm max first year
10µW
Features
«
«
«
«
«
Good frequency perturbation
Metal lid can be grounded to minimise EMI
Seam sealed for excellent long-term stability
Ultra-miniature for maximum space saving
Ideal for Bluetooth / Wireless applications
Test drive level:
Soldering condition:
260°C, 10 sec x2 max
Standard.
Optional - Please specify required code(s) when ordering
Ordering Information
Product name + option codes + frequency
eg:
GSX-533/111NF 16.0MHz
10/10/10/9-F
GSX-533/1P3AF 26.0MHz
10/15/30/10-F
Option code X (eg GSX-533/X) denotes a custom specification.
±10ppm temperature stability may not be available over -30+80°C.
Check with our sales office before ordering.
Available on T&R - 1k pcs per reel.
Refer to our website for T&R and soldering details.
Bluetooth Applications
Frequency
12.0MHz
12.0MHz
15.360MHz
16.0MHz
32.0MHz
Specification
9pF, C
1
= 4fF ±20%
18pF, C
1
= 4fF ±20%
18pF, 6.5ppm/pF typ pullability
9pF, 20ppm/pF min pullability
12pF, 20ppm/pF typ pullability
IC
Philips
Philips
CSR
S. Wave
Part No
MA06096
MA06097
MA06098
MA05625*
MA06099
GPS / Mobile Applications
Frequency
13.0MHz
13.0MHz
13.0MHz
13.0MHz
16.367667MHz
24.5535MHz
26.0MHz
26.0MHz
Specification
8pF, 22.5ppm/pF ±15%
8pF, 29.5ppm/pF ±10%
8.5pF, 25.5ppm/pF ±10%
11.5pF, C
1
= 4.9fF ±20%
20pF, C
1
= 6.0fF ±15%
32pF, C
1
= 8.5fF ±15%
10pF, 18~25ppm/pF
9.5pF, 20ppm/pF min
IC / Appln Part No
Silicon Labs
Silicon Labs
Silicon Labs
Infineon
SiRF GPS
Infineon
Hitachi
MA06106
MA06118
MA06119
MA06107
MA06105
MA05925
MA06108
MA06122
* Qualified for use with CSR chipset solutions. Golledge is a global supply partner for CSR
Tel:
+44 1460 256 100
08 Oct 2004
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
Product Information
Construction
GSX-533
«
«
Ceramic body with gold-plated pads
Metal lid, seam sealed
Composition
RoHS
2002/95/EC
This product is lead-free, and is fully compliant with
the RoHS directive 2002/95/EC
Pb
LeadFree
Packaging & Handling
Production quantities supplied on T & R, 1k or 3k pcs per reel.
Small quantities may be supplied on tape (no reel), or in bulk.
Soldering Profile
°C
260
10s max
Marking
NNN
T DC
Year
Code
Marking type: Laser
NNN = Part ID code
DC = Date code in YW, as shown below
Example: “zd” = 2004 week 30
Week codes:
A ~ Z: weeks 1 to 26
a ~ z: weeks 27 to 52
200
2001 2002 2003 2004
2005 2006 2007 2008
Z
z
Z
z
100
5°C/s max
5°C/s max
Tape & Reel Specification
3.7
±0.05
Preheat
140~160°C
1.50Ø
1.75
0
60~90s max
Heat
> 200°C
50~60s max
Slow
cooldown
Time
4.0
2.0
0.3
Solder resistance: 260°C x 10 secs x 2.
5°
±0.05
MARK
5.5
5.5
12.0
±0.3
1.2
8.0
3.0
120°
FEED
12.4
+2.0
-0.0
1.50
20.2Ø
330Ø
13Ø
100Ø
Not to scale. Dimensional tolerances ±0.1mm unless otherwise stated
Tel:
+44 1460 256 100
08 Oct 2004
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
