SMA5J5.0A thru SMA5J40CA
www.vishay.com
Vishay General Semiconductor
High Power Density Surface Mount T
RANS
Z
ORB®
Transient Voltage Suppressors
FEATURES
Low profile package
Ideal for automated placement
Glass passivated chip junction
Available in uni-directional and bi-directional
Excellent clamping capability
Very fast response time
Low incremental surge resistance
Meets MSL level 1, per J-STD-020, LF maximum peak of
260 °C
• AEC-Q101 qualified
• Compliant to RoHS Directive 2002/95/EC and in
accordance to WEEE 2002/96/EC
5.0 V to 40 V
500 W
40 A
150 °C
•
•
•
•
•
•
•
•
DO-214AC (SMA)
PRIMARY CHARACTERISTICS
V
WM
P
PPM
I
FSM
(uni-directional only)
T
J
max.
TYPICAL APPLICATIONS
Use in sensitive electronics protection against voltage
transients induced by inductive load switching and lighting
on ICs, MOSFET, signal lines of sensor units for consumer,
computer, industrial, automotive, and telecommunication.
MECHANICAL DATA
Case:
DO-214AC (SMA)
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E3 - RoHS compliant, commercial grade
Base P/NHE3 - RoHS compliant, AEC-Q101 qualified
Terminals:
Matte tin plated leads, solderable per
J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 1A whisker test, HE3 suffix
meets JESD 201 class 2 whisker test
Polarity:
For uni-directional types the band denotes
cathode end, no marking on bi-directional types
DEVICES FOR BI-DIRECTION APPLICATIONS
For bi-directional devices use CA suffix (e.g. SMA5J40CA).
Electrical characteristics apply in both directions.
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Peak pulse power dissipation with a 10/1000 μs waveform
(1)(2)
(fig. 1)
Peak pulse current with a 10/1000 μs waveform
(1)
Peak forward surge current 8.3 ms single half sine-wave uni-directional only
(2)
Operating junction and storage temperature range
Notes
(1)
Non-repetitive current pulse, per fig. 3 and derated above T = 25 °C per fig. 2.
A
(2)
Mounted on 0.2" x 0.2" (5.0 mm x 5.0 mm) copper pads to each terminal
SYMBOL
P
PPM
I
PPM
I
FSM
T
J
, T
STG
VALUE
500
See next table
40
- 55 to + 150
UNIT
W
A
A
°C
Revision: 26-Jan-12
Document Number: 88875
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
SMA5J5.0A thru SMA5J40CA
www.vishay.com
Vishay General Semiconductor
BREAKDOWN
VOLTAGE
V
BR
(V)
(1)
MIN.
6.40
6.67
7.22
7.78
8.33
8.89
9.44
10.0
11.1
12.2
13.3
14.4
15.6
16.7
17.8
18.9
20.0
22.2
24.4
26.7
28.9
31.1
33.3
36.7
40.0
44.4
MAX.
7.07
7.37
7.98
8.60
9.21
9.83
10.4
11.1
12.3
13.5
14.7
15.9
17.2
18.5
19.7
20.9
22.1
24.5
26.9
29.5
31.9
34.4
36.8
40.6
44.2
49.1
MAXIMUM
REVERSE
LEAKAGE
AT V
WM
I
D
(μA)
(3)
800
800
500
200
100
50
10
5.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
MAXIMUM
PEAK PULSE
SURGE
CURRENT
I
PPM
(A)
(2)
54.3
48.5
44.6
41.7
38.8
36.8
34.7
32.5
29.4
27.5
25.1
23.3
21.6
20.5
19.2
18.1
17.1
15.4
14.1
12.9
11.9
11.0
10.3
9.4
8.6
7.8
MAXIMUM
CLAMPING
VOLTAGE AT
I
PPM
V
C
(V)
9.2
10.3
11.2
12.0
12.9
13.6
14.4
15.4
17.0
18.2
19.9
21.5
23.2
24.4
26.0
27.6
29.2
32.4
35.5
38.9
42.1
45.4
48.4
53.3
58.1
64.5
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
DEVICE TYPE
DEVICE MARKING
CODE
UNI
SMA5J5.0A
(5)
SMA5J6.0A
SMA5J6.5A
SMA5J7.0A
SMA5J7.5A
SMA5J8.0A
SMA5J8.5A
SMA5J9.0A
SMA5J10A
SMA5J11A
SMA5J12A
SMA5J13A
SMA5J14A
SMA5J15A
SMA5J16A
SMA5J17A
SMA5J18A
SMA5J20A
SMA5J22A
SMA5J24A
SMA5J26A
SMA5J28A
SMA5J30A
SMA5J33A
SMA5J36A
SMA5J40A
5AE
5AG
5AK
5AM
5AP
5AR
5AT
5AV
5AX
5AZ
5BE
5BG
5BK
5BM
5BP
5BR
5BT
5BV
5BX
5BZ
5CE
5CG
5CK
5CM
5CP
5CR
BI
5AE
5AG
5AK
5AM
5AP
5AR
5AT
5AV
5AX
5AZ
5BE
5BG
5BK
5BM
5BP
5BR
5BT
5BV
5BX
5BZ
5CE
5CG
5CK
5CM
5CP
5CR
TEST
CURRENT
I
T
(mA)
10
10
10
10
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
STAND-OFF
VOLTAGE
V
WM
(V)
5.0
6.0
6.5
7.0
7.5
8.0
8.5
9.0
10
11
12
13
14
15
16
17
18
20
22
24
26
28
30
33
36
40
Notes
(1)
Pulse test: t
50 ms
p
(2)
Surge current waveform per fig. 3 and derate per fig. 2
(3)
For bi-directional types having V
WM
of 10 V and less, the I
D
limit is doubled
(4)
All terms and symbols are consistent with ANSI/IEEE C62.35
(5)
For the bi-directional SMA5J5.0CA, the maximum V
BR
is 7.25 V
(6)
V = 3.5 V at I = 25 A (uni-directional only)
F
F
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance, junction to ambient
(1)
Typical thermal resistance, junction to lead
(1)
SYMBOL
R
JA
R
JL
VALUE
80
25
UNIT
°C/ W
Note
Mounted on minimum recommended pad layout
ORDERING INFORMATION
(Example)
PREFERRED P/N
SMA5J5.0A-E3/61
SMA5J5.0A-E3/5A
SMA5J5.0AHE3/61
(1)
SMA5J5.0AHE3/5A
(1)
(1)
UNIT WEIGHT (g)
0.064
0.064
0.064
0.064
PREFERRED PACKAGE CODE
61
5A
61
5A
BASE QUANTITY
1800
7500
1800
7500
DELIVERY MODE
7" diameter plastic tape and reel
13" diameter plastic tape and reel
7" diameter plastic tape and reel
13" diameter plastic tape and reel
Note
AEC-Q101 qualified
Document Number: 88875
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Revision: 26-Jan-12
SMA5J5.0A thru SMA5J40CA
www.vishay.com
Vishay General Semiconductor
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
100
10 000
Non-Repetitive
Pulse
Waveform
shown in Fig. 3
T
A
= 25 °C
10
Uni-Directional
Bi-Directional
Measured at
Zero Bias
1000
T
J
= 25 °C
f = 1.0 MHz
P
PPM
- Peak Pulse Power (kW)
1
C
J
- Junction Capacitance (pF)
100
Measured at Stand-Off
Voltage V
WM
10
1
10
100
200
0.1
0.1 µs
1.0 µs
10 µs
100 µs
1.0 ms
10 ms
t
d
- Pulse
Width
(s)
V
WM
- Reverse Stand-Off Voltage (V)
Fig. 1 - Peak Pulse Power Rating Curve
Fig. 4 -
Typical Junction Capacitance
Peak Pulse Power (P
PP
) or Current (I
PP
)
Derating in Percentage, %
100
100
75
Transient Thermal Impedance (°C/W)
50
10
25
0
0
25
50
75
100
125
150
175
200
1
0.01
0.1
1
10
100
1000
T
J
- Initial Temperature (°C)
t
p
- Pulse Duration (s)
Fig. 2 -
Pulse Power or Current vs. Initial Junction Temperature
Fig. 5 -
Typical Transient Thermal Impedance
150
I
PPM
- Peak Pulse Current, % I
RSM
100
Peak Value
I
PPM
Peak Forward Surge Current (A)
t
r
= 10 µs
T
J
= 25 °C
Pulse
Width
(t
d
)
is defined as the Point
where
the Peak Current
decays to 50 % of I
PPM
200
T
J
= T
J
max.
8.3 ms Single Half Sine-Wave
100
Half Value - I
PP
I
PPM
2
50
10/1000 µs
Waveform
as defined by R.E.A.
t
d
0
0
1.0
2.0
3.0
4.0
50
10
1
5
10
50
100
t - Time (ms)
Number
of Cycles at 60 Hz
Fig. 3 -
Pulse Waveform
Fig. 6 -
Maximum Non-Repetitive Peak Forward Surge Current
Uni-Directional Use Only
Revision: 26-Jan-12
Document Number: 88875
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
SMA5J5.0A thru SMA5J40CA
www.vishay.com
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
DO-214AC (SMA)
Cathode Band
Vishay General Semiconductor
Mounting Pad Layout
0.066 (1.68)
MIN.
0.074 (1.88)
MAX.
0.065 (1.65)
0.049 (1.25)
0.110 (2.79)
0.100 (2.54)
0.177 (4.50)
0.157 (3.99)
0.012 (0.305)
0.006 (0.152)
0.060 (1.52)
MIN.
0.208 (5.28)
REF.
0.090 (2.29)
0.078 (1.98)
0.060 (1.52)
0.030 (0.76)
0.008 (0.203)
0 (0)
0.208 (5.28)
0.194 (4.93)
Revision: 26-Jan-12
Document Number: 88875
4
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Legal Disclaimer Notice
www.vishay.com
Vishay
Disclaimer
ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively,
“Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other
disclosure relating to any product.
Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or
the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all
liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special,
consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular
purpose, non-infringement and merchantability.
Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of typical
requirements that are often placed on Vishay products in generic applications. Such statements are not binding statements
about the suitability of products for a particular application. It is the customer’s responsibility to validate that a particular
product with the properties described in the product specification is suitable for use in a particular application. Parameters
provided in datasheets and/or specifications may vary in different applications and performance may vary over time. All
operating parameters, including typical parameters, must be validated for each customer application by the customer’s
technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase,
including but not limited to the warranty expressed therein.
Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining
applications or for any other application in which the failure of the Vishay product could result in personal injury or death.
Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk and agree
to fully indemnify and hold Vishay and its distributors harmless from and against any and all claims, liabilities, expenses and
damages arising or resulting in connection with such use or sale, including attorneys fees, even if such claim alleges that Vishay
or its distributor was negligent regarding the design or manufacture of the part. Please contact authorized Vishay personnel to
obtain written terms and conditions regarding products designed for such applications.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by
any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners.
Material Category Policy
Vishay Intertechnology, Inc. hereby certifies that all its products that are identified as RoHS-Compliant fulfill the
definitions and restrictions defined under Directive 2011/65/EU of The European Parliament and of the Council
of June 8, 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment
(EEE) - recast, unless otherwise specified as non-compliant.
Please note that some Vishay documentation may still make reference to RoHS Directive 2002/95/EC. We confirm that
all the products identified as being compliant to Directive 2002/95/EC conform to Directive 2011/65/EU.
Revision: 12-Mar-12
1
Document Number: 91000
京公网安备 11010802033920号
EEWORLD
