(1/4)
DC to DC Converters
Distributed Power Supplies for Systems, Non-insulation Type
POL Converters iAA/iBA Series
Power supply systems for infrastructure devices used in communi-
cation networks primarily are expected to provide multi output, low
output voltage, higher efficiencies, and lower noise levels.
To meet these demands, the lineup did non-insulation type POL
(Point of Load) converter.
FEATURES
• Input voltage range (DC.3 to5.5V)
• The output voltage is a fixed type of 3.3V and 2.5V, and change-
able types of 0.75 to 3.63V.
• Heat sink is not required.
•
•
•
•
High efficiency: 93 to 95%
Remote ON-OFF function
Output voltage external variable function
Various protective functions
PART NUMBERS AND RATINGS
(5)
Output voltage(V)
3.3
2.5
0.75 to 3.63
0.75 to 3.63
Current(A)
15
15
15
8
Part No.
iAA05015A033V
iAA05015A025V
iAA05015A008V
iBA05008A008V
PRODUCT IDENTIFICATION
iAA
(1)
05 015A
(2)
(3)
033V
(4)
-
(1) Type name
Point of Load-brick type
iAA: 33×13.5mm
iBA: 20×11mm
(2) Rated input voltage
(3) Output current
(4) Output voltage
(5) Option code
00: Standard Positive on/off logic)
(
01: Negative on/off logic
• All specifications are subject to change without notice.
001-02 / 20040525 / ea33_br_iaaba.fm
(2/4)
SPECIFICATIONS AND STANDARDS
Part No.
Rated output voltage and current
∗1
Maximum output power
W
Input conditions
Input voltage Edc
V
Transient input voltage
V
Input current
A
Efficiency
%
Output characteristics
Output voltage Edc
V
Voltage adjustment range
%
Maximum output current
A
Minimum output current
A
Output voltage initial setting
%
Overcurrent protection
A
Line regulation
mV
Load regulation
mV
Voltage
Temperature
stability
mV
regulation
Dynamic response
∗2
mV
Ripple noise Ep-p
mV
Start up time
∗3
ms
ms
Rise time
∗4
Auxiliary functions
Overvoltage protection
Overcurrent protection
Alarm output
Over-temperature protection
Remote ON-OFF
Remote sensing
Parallel operation
Output voltage adjustment
Master slave operation
Standards
Safety standards
Constructions
External dimensions
mm
Weight
g
Mounting method
Oscillating method
Oscillating frequency
kHz
∗1
∗2
iAA05015A033V
3.3V • 15A
50
3 to 5.5[Continuation]
6[100ms]
16max.
89typ.
3.3
±10
15
0
±2max.
35typ.
5max.(2typ.)
10max.(3typ.)
60max.(15typ.)
±185typ.
75max.
14
10
No
Yes(Automatic recovery)
No
Yes(Automatic recovery)
Yes
Yes(Only +)
Impossible
Yes
No
iAA05015A025V
2.5V • 15A
37.5
3 to 5.5[Continuation]
6[100ms]
16max.
88typ.
2.5
±10
15
0
±2max.
35typ.
5max.(2typ.)
10max.(3typ.)
60max.(15typ.)
±185typ.
75max.
14
10
iAA05015A008V
0.75 to 3.63V • 15A
54.5
3 to 5.5[Continuation]
6[100ms]
16max.
86typ.
0.75 to 3.63
—
15
0.02
±2max.
35typ.
5max.(2typ.)
10max.(3typ.)
60max.(15typ.)
±185typ.
75max.
14
10
iBA05008A008V
0.75 to 3.63V • 8A
54.5
3 to 5.5[Continuation]
6[100ms]
8max.
82typ.
0.75 to 3.63
—
8
0.02
±2max.
17typ.
5max.(1typ.)
10max.(1typ.)
60max.(15typ.)
±200typ.
75max.
14
10
UL60950 and VDE0805 approved. EN60950 approved.
[
8.0×13.5×33.2 H×W×L½
12
Surface mounting method
Fixed frequency
350
[
8.4×11.4×20.3 H×W×L½
7
12
12
400
350
350
Verify the rated current (maximum output current) because this involves derating.
Load step from 50 to 100% of Io max. with at least one 0.1µF and 47µF ceramic capacitors across the output terminals.
∗3
Time to reaching to 90% by output voltage after input applies (t: Vin=0 to Vout=0.9Vo, nom. Tc=25°C, Io=Io, max.)
∗4
Time to reaching to 10 to 90% by output voltage (t: Co=0.1 to 0.9 Vo, nom.)
• All specifications are subject to change without notice.
001-02 / 20040525 / ea33_br_iaaba.fm
(3/4)
iAA TYPE
SHAPES AND DIMENSIONS
iBA TYPE
SHAPES AND DIMENSIONS
Top view
33.02±0.38
13.46±0.38
Top view
20.3
8.00±0.50
2.54
8.38±0.38
29.90
22.35
17.53
11.4
Bottom view
Bottom view
17.53
12.95
8.89
4.83
12.70
7.87
10.92
0.64
2.29
0.51
8.89
2.54
0.76
1.52
0.51
0.38
TERMINAL DESIGNATIONS AND FUNCTIONS
TERMINAL DESIGNATIONS AND FUNCTIONS
Top view
29.90
22.35
17.53
12.70
7.87
Top view
17.53
12.70
8.64
4.57
10.92
5
4
3
2
2.54
6
1
3.81
Dimensions in mm
1
2
3
4
5
6
Vin
GND
Vout
Trim
Sense
ON/OFF
8.64
4
5
3
2
1
0.25
3.30
Dimensions in mm
1
2
3
4
5
6
Vin
GND
Vout
Trim
Sense
ON/OFF
0.64
• All specifications are subject to change without notice.
001-02 / 20040525 / ea33_br_iaaba.fm
0.25
2.54
(4/4)
OUTPUT POWER-AMBIENT TEMPERATURE (DERATING)
MAXIMUM OUTPUT CURRENT vs. AMBIENT TEMPERATURE(Ta)
iAA05015A033V
iAA05015A008V
16
14
Output current (A)
Output current (A)
12
10
8
6
4
2
0
60
70
80
90
100
110
Temperature (˚C)
120
130
8
7
6
5
4
3
2
1
0
70
80
90
100
110
Temperature (˚C)
120
130
NC
0.5m/s(100LFM)
1.0m/s(200LFM)
1.5m/s(300LFM)
2.0m/s(400LFM)
Q1 limit
NC
0.5m/s(100LFM)
1.0m/s(200LFM)
1.5m/s(300LFM)
Q2 limit
Tc TEMPERATURE MEASUREMENT POINT AND WIND DIRECTION
Thermal measurement location
on critical component
Best orientation
Worst orientation
iBA05008A008V
16
14
12
Output current (A)
10
8
6
4
2
0
50
60
70
80
90
100
Temperature (˚C)
110
120
130
Tc TEMPERATURE MEASUREMENT POINT
Thermal measurement location
on critical component
NC
0.5m/s(100LFM)
1.0m/s(200LFM)
2.0m/s(400LFM)
Q1 limit
COMMON SPECIFICATIONS
Temperature and humidity
Operating(°C)
Temperature range
Storage(°C)
Operating(%)RH
Humidity range
Storage(%)RH
Vibration and shock
5 to 50Hz
Vibration
50 to 500Hz
Acceleration
Shock
Pulse duration
–40 to +117 [Temperature at the measurement point in the above drawing]
–55 to +125[Ambient temperature of the power supply]
10 to 85[Without dewing]
Acceleration: 0.5G
Acceleration: 1.5G
50G[Half sine wave, 3 directions]
6ms
