ROITHNER LASERTECHNIK
A-1040 WIEN, FLEISCHMANNGASSE 9
TEL: +43 -1- 586 52 43 FAX: +43 -1- 586 41 43
e-mail: office@roithner-laser.com
http://www.roithner-laser.com
RLT9005MG
Infrared Laserdiode
TECHNICAL DATA
Structure:
index guided single transverse mode
Lasing wavelength:
900 nm typ.
Output power:
5 mW cw
Package:
5.6 mm, TO-18
PIN CONNECTION:
LASERDIODE
MUST BE COOLED!
NOTE!
1) Laser diode cathode
2) Laser diode anode and photodiode cathode
3) Photodiode anode
Maximum Ratings (Tc = 25°C)
CHARACTERISTIC
SYMBOL
Optical Output Power
P
o
LD Reverse Voltage
V
R(LD)
PD Reverse Voltage
V
R(PD)
Operation Case Temperature
T
C
Storage Temperature
T
STG
RATING
7
2
30
-10 .. +60
-40 .. +85
UNIT
mW
V
V
°C
°C
Optical-Electrical Characteristics (Tc = 25°C)
CHARACTERISTIC SYMBOL TEST CONDITION
Threshold Current
I
th
cw
Operation Current
I
op
P
o
= 5 mW
Operating Voltage
V
op
P
o
= 5 mW
Lasing Wavelength
P
o
= 5 mW
λ
p
Beam Divergence
P
o
= 5 mW
θ
//
Beam Divergence
P
o
= 5 mW
θ
⊥
Slope Efficiency
cw
η
Monitor Current
I
m
P
o
= 5 mW
MIN
895
7
30
0.5
600
TYP
30
40
1.6
900
8
33
0.7
1200
MAX
40
60
1.8
910
12
38
1
2000
UNIT
mA
mA
V
nm
°
°
mW/mA
µA
