2-Line Filters
for Converters in Traction Systems
Power line filters for dc systems
Rated voltage 750 to 2000 V–
Rated current 250 to 1000 A
Construction
s
Two-line filter
s
Metal case
B84142-A*-S2
... B84142-A*-S18
Features
s
Easy to install
s
Space-saving design
s
Design based on
EN 133 200, UL 1283, CSA 22.2 No.8 1986
s
Optimized for long motor cables and
operation under full load
Applications
s
Trams, light rails
s
Subways
Terminals
s
Busbars, tin-plated
Marking
Marking on component:
Manufacturer’s logo, ordering code,
rated voltage, rated current,
date code
Minimum marking on packaging:
Manufacturer’s logo, ordering code
Typical circuit diagram
L+
L
_
LINE
L+’
L
_
’
LOAD
Traction side
Bahnseite
Inverter
Umrichter
SSB1309-8
183
03/01
2-Line Filters
for Converters in Traction Systems
Technical data
Rated voltage
V
R
750 V
−
(Type -S2)
1000 V
−
(Type -S3)
2000 V
−
(Type -S18)
B84142-A*-S2
... B84142-A*-S18
Rated current
I
R
Test voltage
V
P
Referred to 60
°
C ambient temperature
For 750 V
−
filters:
2000 V
−
, 60 s (L+/L
−
)
4900 V
−
, 60 s (L+||L
−
/case)
6000 V
−
, 2 s (L+||L
−
/case)
For 1000 V
−
filters: 2500 V
−
, 60 s (L+/L
−
)
4900 V
−
, 60 s (L+||L
−
/case)
6000 V
−
, 2 s (L+||L
−
/case)
For 2000 V
−
filters: 4000 V
−
, 60 s (L+/L
−
)
4900 V
−
, 60 s (L+||L
−
/case)
6000 V
−
, 2 s (L+||L
−
/case)
Overload capability
Climatic category
1,6 ·
I
R
for 20 s or
2,0 ·
I
R
for 10 s
40/100/21 (– 40
°
C/+ 100
°
C/21 days damp heat test)
in accordance with EN 60068-1
Characteristics and ordering codes
V
R
V
−
750
I
R
A
250
500
1000
1000
250
500
1000
2000
250
500
1000
Terminal
P
V
cross section
mm
2
W
125
150
320
125
150
320
125
150
320
8
34
66
8
34
66
8
34
66
R
typ
Approx.
weight
kg
12
13
26
12
13
26
12
13
26
Ordering code
µΩ
63
57
33
63
57
33
63
57
33
B84142-A250-S2
B84142-A500-S2
B84142-A1000-S2
B84142-A250-S3
B84142-A500-S3
B84142-A1000-S3
B84142-A250-S18
B84142-A500-S18
B84142-A1000-S18
184
03/01
2-Line Filters
for Converters in Traction Systems
Dimensional drawing B84142-A250-S**
B84142-A*-S2
... B84142-A*-S18
PE
M10 × 30
ø11
PE
M10 × 30
25
5
40±1
15
360±2
5
40±1
15
91
36
60
120±0,5
300
120±0,5
60
+
+
110±0,5
5
140
_
ø12
LINE
LOAD
_
2
2xM6;depth of
tief
2 × M6; 6 mm
engagement 6 mm
an beiden
on both filter sides
Stirnseiten
91
116
SSB1587-R
185
03/01
190
80
Marking
165±1
30
2-Line Filters
for Converters in Traction Systems
Dimensional drawing B84142-A500-S**
PE
M10 × 30
ø11
B84142-A*-S2
... B84142-A*-S18
PE
M10 × 30
30
5
40±1
15
360±2
5
40±1
15
91
36
60
120±0,5
300
120±0,5
60
+
+
110±0,5
5
140
_
ø12
LINE
LOAD
_
2
2xM6;depth of
tief
2 × M6; 6 mm
engagement 6 mm
an beiden
on both filter sides
Stirnseiten
91
116
SSB1588-Z
186
03/01
190
80
Marking
165±1
30
2-Line Filters
for Converters in Traction Systems
B84142-A1000-S**
B84142-A*-S2
... B84142-A*-S18
ø14
86±3
86±3
ø14
40
20
40
410±2,5
40
20
350
60
61
PE
M6 × 25
290±1
220
60
+
+
LINE
LOAD
180±0,8
8
210
_
ø12
_
2
4xM6;depth
mm tief
4 × M6; 6
of
engagement 6 mm
an beiden
on both filter sides
Stirnseiten
95±0,8
126
16
SSB1589-8
187
03/01
260
80
Marking
235±1
