Features
•
Industry-standard Architecture
– Emulates Many 20-pin PALs
®
– Low-cost Easy-to-use Software Tools
•
High-speed Electrically-erasable Programmable Logic Devices
– 10 ns Maximum Pin-to-pin Delay
•
Several Power Saving Options
Device
ATF16V8B
ATF16V8BQ
ATF16V8BQL
I
CC
, Standby
50 mA
35 mA
5 mA
I
CC
, Active
55 mA
40 mA
20 mA
•
CMOS and TTL Compatible Inputs and Outputs
•
– Input and I/O Pull-up Resistors
Advanced Flash Technology
– Reprogrammable
– 100% Tested
High-reliability CMOS Process
– 20 Year Data Retention
– 100 Erase/Write Cycles
– 2,000V ESD Protection
– 200 mA Latchup Immunity
Commercial, and Industrial Temperature Ranges
Dual-in-line and Surface Mount Packages in Standard Pinouts
PCI-compliant
Green Package Options (Pb/Halide-free/RoHS Compliant) Available
High-
performance
EE PLD
ATF16V8B
ATF16V8BQ
ATF16V8BQL
•
•
•
•
•
1. Description
The ATF16V8B is a high-performance CMOS (electricallyerasable) programmable
logic device (PLD) that utilizes Atmel’s proven electrically-erasable Flash memory
technology. All speed ranges are specified over the full 5V
±
10% range for industrial
temperature ranges, and 5V
±
5% for commercial temperature ranges.
Several low-power options allow selection of the best solution for various types of
power-limited applications. Each of these options significantly reduces total system
power and enhances system reliability.
The ATF16V8Bs incorporate a superset of the generic architectures, which allows
direct replacement of the 16R8 family and most 20-pin combinatorial PLDs. Eight out-
puts are each allocated eight product terms. Three different modes of operation,
configured automatically with software, allow highly complex logic functions to be
realized.
0364J–PLD–7/05
ATF16V8B/BQ/BQL
3. Absolute Maximum Ratings*
Temperature Under Bias.................................-55
o
C to +125
o
C
Storage Temperature ......................................-65
o
C to +150
o
C
Voltage on Any Pin with
Respect to Ground .......................................-2.0 V to +7.0 V
(1)
Voltage on Input Pins
with Respect to Ground
During Programming...................................-2.0 V to +14.0 V
(1)
Programming Voltage with
Respect to Ground .....................................-2.0 V to +14.0 V
(1)
*NOTICE:
Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or any
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect device
reliability.
Note:
1. Minimum voltage is -0.6V DC, which may under-
shoot to -2.0V for pulses of less than 20 ns.
Maximum output pin voltage is V
CC
+ 0.75V DC,
which may overshoot to 7.0V for pulses of less
than 20 ns.
4. DC and AC Operating Conditions
Commercial
Operating Temperature (Ambient)
V
CC
Power Supply
0
o
C - 70
o
C
5V
±
5%
Industrial
-40
o
C - 85
o
C
5V
±
10%
3
0364J–PLD–7/05
ATF16V8B/BQ/BQL
4.2
AC Waveforms
(1)
Note:
1. Timing measurement reference is 1.5V. Input AC driving levels are 0.0V 3.0V, unless otherwise
specified.
4.3
AC Characteristics
(1)
-10
-15
Max
10
Min
3
Max
15
ns
6
2
7.5
0
12
6
68
74
83
3
2
2
1.5
10
10
10
10
3
2
2
1.5
7
2
12
0
16
8
45
50
62
15
15
15
15
8
10
ns
ns
ns
ns
ns
ns
MHz
MHz
MHz
ns
ns
ns
ns
Units
Parameter
Input or Feedback to
Non-Registered Output
Clock to Feedback
Clock to Output
Input or Feedback
Setup Time
Hold Time
Clock Period
Clock Width
External Feedback 1/(t
S
+ t
CO
)
8 outputs switching
Min
3
Symbol
t
PD
t
CF
t
CO
t
S
t
H
t
P
t
W
f
MAX
Internal Feedback 1/(t
S
+ t
CF
)
No Feedback 1/(t
P
)
t
EA
t
ER
t
PZX
t
PXZ
Note:
Input to Output Enable — Product Term
Input to Output Disable — Product Term
OE pin to Output Enable
OE pin to Output Disable
1. See ordering information for valid part numbers and speed grades.
