BC817-25-TP-HF Overview

Small Signal Bipolar Transistor,

BC817-25-TP-HF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Micro Commercial Components (MCC)
Objectid	1288128581
package instruction	SMALL OUTLINE, R-PDSO-G3
Reach Compliance Code	compliant
ECCN code	EAR99
compound_id	151980314
Maximum collector current (IC)	0.5 A
Collector-emitter maximum voltage	45 V
Configuration	SINGLE
Minimum DC current gain (hFE)	160
JESD-30 code	R-PDSO-G3
Humidity sensitivity level	1
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Polarity/channel type	NPN
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	10
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	100 MHz

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

BC817-16

THRU

BC817-40

NPN Small

Signal Transistor

310mW

SOT-23

Features

•

Halogen

free available upon request by adding suffix "-HF"

Lead Free Finish/RoHS Compliant ("P" Suffix designates

RoHS Compliant. See ordering information)

Epoxy meets UL 94 V-0 flammability rating

Moisure Sensitivity Level 1

Ideally Suited for Automatic Insertion

150 C Junction Temperature

For Switching and AF Amplifier Applications

Epitaxial Planar Die Construction

Mechanical Data

•

Case: SOT-23, Molded Plastic

Terminals: Solderable per MIL-STD-202, Method 208

Polarity: See Diagram

Weight: 0.008 grams ( approx.)

Marking:

BC817-16

BC817-25

BC817-40

Maximum Ratings @ 25

C Unless Otherwise Specified

Charateristic

Collector-Emitter Voltage

Emitter-Base Voltage

Collector Current

Peak Collector Current

Peak Emitter Current

Power Dissipation@T

=50

C(Note1)

Operating & Storage Temperature

Symbol Value

CEO

EBO

Unit

DIM

DIMENSIONS

INCHES

MIN

MAX

.110

.120

.083

.104

.047

.055

.035

.041

.070

.081

.018

.024

.0005

.0039

.035

.044

.003

.007

.015

.020

MIN

2.80

2.10

1.20

.89

1.78

.45

.013

.89

.085

.37

MAX

3.04

2.64

1.40

1.03

2.05

.60

.100

1.12

.180

.51

NOTE

500

1000

300

, T

STG

-55~150

Suggested Solder

Pad Layout

.031

.800

.035

.900

.079

2.000

inches

Note:

Device mounted on Ceramic Substrate 0.7mm X 2.5cm area

.037

.950

.037

.950

www.mccsemi.com

Revision:

1 of 4

2013/06/04

BC817-25-TP-HF Related Products

	BC817-25-TP-HF	BC817-40-TP-HF	BC817-16-TP-HF
Description	Small Signal Bipolar Transistor,	Small Signal Bipolar Transistor,	Small Signal Bipolar Transistor,
Is it Rohs certified?	conform to	conform to	conform to
package instruction	SMALL OUTLINE, R-PDSO-G3	SMALL OUTLINE, R-PDSO-G3	SMALL OUTLINE, R-PDSO-G3
Reach Compliance Code	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99
Maximum collector current (IC)	0.5 A	0.5 A	0.5 A
Collector-emitter maximum voltage	45 V	45 V	45 V
Configuration	SINGLE	SINGLE	SINGLE
Minimum DC current gain (hFE)	160	250	100
JESD-30 code	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3
Humidity sensitivity level	1	1	1
Number of components	1	1	1
Number of terminals	3	3	3
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260	260	260
Polarity/channel type	NPN	NPN	NPN
surface mount	YES	YES	YES
Terminal form	GULL WING	GULL WING	GULL WING
Terminal location	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	10	10	10
transistor applications	SWITCHING	SWITCHING	SWITCHING
Transistor component materials	SILICON	SILICON	SILICON
Nominal transition frequency (fT)	100 MHz	100 MHz	100 MHz
Maker	Micro Commercial Components (MCC)	-	Micro Commercial Components (MCC)
