Automotive Splashproof Connectors
Series 9215 – Branch Connectors
Housing
Contact
ORDERING CODE
60
0 = 0.85sq (white)
1 = 0.5sq (black)
6 = 0.3sq (blue)
ORDERING CODE
001
010
00X
0 = 0.5sq
1 = 0.85sq
2 = 0.3sq
9215
70
9215
999
00X
825
VARIATION CODE
VARIATION CODE (IDC)
AVS 0.5 (Crimping side area)
Series 9515 Connectors
Plug
Receptacle
PLUG HOUSING ORDERING CODE
61 9515 004 000 001
RECEPTACLE HOUSING ORDERING CODE
62 9515 004 010 001
HARD SEAL (B) ORDERING CODE
92 9515 004 XXX XXX
NUMBER OF POSITIONS - Color
012 002 = (2P/Blue), 013 003 = (3P/Yellow), 014 004 = (4P/Red)
CAP ORDERING CODE
62 9515 004 020 001
HARD SEAL (A) ORDERING CODE
92 9515 004 000 003
TOOLING
Auto Crimping Machine
Press Machine
Applicator
Press Capacity
Dimension
Weight
Power
36 1004 001
36 1000 044
2 (tons)
W550xH700xD380
85kg
AC100V 50/60Hz
HARD SEAL (C) ORDERING CODE
92 9515 004 XXX XXX
NUMBER OF POSITIONS
002 002 = (2P)
003 003 = (3P)
004 004 = (4P)
Contact Plug
Receptacle
PLUG CONTACT ORDERING CODE
71 9515 999 010 808
RECEPTACLE CONTACT ORDERING CODE
72 9515 999 020 808
Additional information on this product is available from AVX’s catalog or AVX’s FAX Service.
Call 1-800-879-1613 and request document
#346.
Visit our website http://www.avxcorp.com
346
