MAX4684-MAX4685

Description
DUAL 1-CHANNEL, SGL POLE DOUBLE THROW SWITCH, PDSO10
Categorysemiconductor    Analog mixed-signal IC
File Size152KB,10 Pages
ManufacturerMaxim
Websitehttps://www.maximintegrated.com/en.html
Download Datasheet Parametric Compare View All

MAX4684-MAX4685 Overview

DUAL 1-CHANNEL, SGL POLE DOUBLE THROW SWITCH, PDSO10

MAX4684-MAX4685 Parametric

Parameter NameAttribute value
Number of functions2
Number of terminals10
Maximum operating temperature85 Cel
Minimum operating temperature-40 Cel
Maximum supply/operating voltage5.5 V
Minimum supply/operating voltage1.8 V
Rated supply voltage3 V
Processing package descriptionMICRO, SOP-10
stateACTIVE
packaging shapeSQUARE
Package SizeSMALL OUTLINE, VERY THIN PROFILE
surface mountYes
Terminal formNO LEAD
Terminal spacing0.5000 mm
terminal coatingTIN LEAD
Terminal locationDUAL
Packaging MaterialsPLASTIC/EPOXY
Temperature levelINDUSTRIAL
Number of inputs1
Maximum on-time50 ns
Maximum off time30 ns
Analog IC other typesSGL POLE DOUBLE THROW SWITCH
Isolation Rating in Off State64 dB
Maximum limit analog input voltage3 V
Forward conduction resistance matching rating0.0600 ohm
Maximum on-state resistance0.8000 ohm
19-1977; Rev 4; 1/09
0.5
Ω
/0.8
Ω
Low-Voltage, Dual SPDT
Analog Switches in UCSP
General Description
The MAX4684/MAX4685 low on-resistance (R
ON
), low-
voltage, dual single-pole/double-throw (SPDT) analog
switches operate from a single +1.8V to +5.5V supply.
The MAX4684 features a 0.5Ω (max) R
ON
for its NC
switch and a 0.8Ω (max) R
ON
for its NO switch at a
+2.7V supply. The MAX4685 features a 0.8Ω max on-
resistance for both NO and NC switches at a +2.7V
supply.
Both parts feature break-before-make switching action
(2ns) with t
ON
= 50ns and t
OFF
= 40ns at +3V. The digi-
tal logic inputs are 1.8V logic-compatible with a +2.7V to
+3.3V supply.
The MAX4684/MAX4685 are packaged in the chipscale
package (UCSP)™, significantly reducing the required
PC board area. The chip occupies only a 2.0mm
1.50mm area. The 4
3 array of solder bumps are
spaced with a 0.5mm bump pitch.
Features
12-Bump, 0.5mm-Pitch UCSP
NC Switch R
ON
0.5Ω max (+2.7V Supply) (MAX4684)
0.8Ω max (+2.7V Supply) (MAX4685)
NO Switch R
ON
0.8Ω max (+2.7V Supply)
R
ON
Match Between Channels
0.06Ω (max)
R
ON
Flatness Over Signal Range
0.15Ω (max)
+1.8V to +5.5V Single-Supply Operation
Rail-to-Rail Signal Handling
1.8V Logic Compatibility
Low Crosstalk: -68dB (100kHz)
High Off-Isolation: -64dB (100kHz)
THD: 0.03%
50nA (max) Supply Current
Low Leakage Currents
1nA (max) at T
A
= +25°C
MAX4684/MAX4685
________________________Applications
Speaker Headset Switching
MP3 Players
Power Routing
Battery-Operated Equipment
Relay Replacement
Audio and Video Signal Routing
Communications Circuits
PCMCIA Cards
Cellular Phones
Modems
UCSP is a trademark of Maxim Integrated Products, Inc.
µMAX is a registered trademark of Maxim Integrated Products,
Inc.
PART
MAX4684
EBC+T
MAX4684ETB+T
MAX4684EUB+T
MAX4685
EBC+T
MAX4685ETB+T
MAX4685EUB+T
Ordering Information
TEMP RANGE
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
PIN/BUMP-
PACKAGE
12 UCSP*
10 TDFN-EP**
10 µMAX
®
12 UCSP*
10 TDFN-EP**
10 µMAX
TOP
MARK
AAF
AAG
AAG
AAH
+Denotes
a lead(Pb)-free/RoHS-compliant package.
Note:
Requires special solder temperature profile described in
the Absolute Maximum Ratings section.
*UCSP
reliability is integrally linked to the user’s assembly
methods, circuit board material, and environment. Refer to the
UCSP Reliability Notice in the UCSP Reliability section of this
data sheet for more information.
**EP
= Exposed Pad
T = Tape and reel.
Pin Configurations/Functional Diagrams/Truth Table
TOP VIEW
MAX4684/MAX4685
GND
NC1
IN1
COM1
NO1
C1
C2
C3
B1
A1
A2
A3
NC2
IN2
MAX4684/MAX4685
COM2
NO2
IN_
0
C4
B4
V+
UCSP
A4
1
NO_
OFF
ON
NC_
ON
OFF
IN1 4
NC1 5
µMAX
7
6
NC2
GND
V+ 1
NO1 2
COM1 3
MAX4684/MAX4685
10 NO2
9
8
COM2
IN2
SWITCHES SHOWN FOR LOGIC "0" INPUT
Continued at end of data sheet.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.

MAX4684-MAX4685 Related Products

MAX4684-MAX4685 MAX4685ETB MAX4685EBC MAX4684ETB MAX4684EBC
Description DUAL 1-CHANNEL, SGL POLE DOUBLE THROW SWITCH, PDSO10 DUAL 1-CHANNEL, SGL POLE DOUBLE THROW SWITCH, PDSO10 DUAL 1-CHANNEL, SGL POLE DOUBLE THROW SWITCH, PDSO10 DUAL 1-CHANNEL, SGL POLE DOUBLE THROW SWITCH, PDSO10 DUAL 1-CHANNEL, SGL POLE DOUBLE THROW SWITCH, PBGA12
Number of functions 2 2 2 2 2
Number of terminals 10 10 12 10 12
Maximum operating temperature 85 Cel 85 °C 85 °C 85 °C 85 °C
Minimum operating temperature -40 Cel -40 °C -40 °C -40 °C -40 °C
surface mount Yes YES YES YES YES
Terminal form NO LEAD NO LEAD BALL NO LEAD BALL
Terminal location DUAL DUAL BOTTOM DUAL BOTTOM
Temperature level INDUSTRIAL INDUSTRIAL INDUSTRIAL INDUSTRIAL INDUSTRIAL
Is it lead-free? - Contains lead Contains lead Contains lead Contains lead
Is it Rohs certified? - incompatible incompatible incompatible incompatible
Maker - Maxim Maxim Maxim Maxim
Parts packaging code - QFN BGA QFN BGA
package instruction - VSON, SOLCC10,.12,20 0.50 MM PITCH, UCSP-12 VSON, SOLCC10,.12,20 0.50 MM PITCH, UCSP-12
Contacts - 10 12 10 12
Reach Compliance Code - _compli _compli _compli _compli
Analog Integrated Circuits - Other Types - SPDT SPDT SPDT SPDT
JESD-30 code - S-PDSO-N10 R-PBGA-B12 S-PDSO-N10 R-PBGA-B12
JESD-609 code - e0 e0 e0 e0
length - 3 mm 2.02 mm 3 mm 2.02 mm
Humidity sensitivity level - 1 1 1 1
Number of channels - 1 1 1 1
Nominal off-state isolation - 64 dB 64 dB 64 dB 64 dB
On-state resistance matching specifications - 0.06 Ω 0.06 Ω 0.06 Ω 0.06 Ω
Maximum on-state resistance (Ron) - 0.8 Ω 0.8 Ω 0.8 Ω 0.8 Ω
output - SEPARATE OUTPUT SEPARATE OUTPUT SEPARATE OUTPUT SEPARATE OUTPUT
Package body material - PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
encapsulated code - VSON VFBGA VSON VFBGA
Encapsulate equivalent code - SOLCC10,.12,20 BGA12,3X4,20 SOLCC10,.12,20 BGA12,3X4,20
Package shape - SQUARE RECTANGULAR SQUARE RECTANGULAR
Package form - SMALL OUTLINE, VERY THIN PROFILE GRID ARRAY, VERY THIN PROFILE, FINE PITCH SMALL OUTLINE, VERY THIN PROFILE GRID ARRAY, VERY THIN PROFILE, FINE PITCH
Peak Reflow Temperature (Celsius) - 245 240 240 240
power supply - 3 V 3 V 3 V 3 V
Certification status - Not Qualified Not Qualified Not Qualified Not Qualified
Maximum seat height - 0.8 mm 0.67 mm 0.8 mm 0.67 mm
Maximum supply voltage (Vsup) - 5.5 V 5.5 V 5.5 V 5.5 V
Minimum supply voltage (Vsup) - 1.8 V 1.8 V 1.8 V 1.8 V
Nominal supply voltage (Vsup) - 3 V 3 V 3 V 3 V
Maximum disconnect time - 30 ns 30 ns 30 ns 30 ns
Maximum connection time - 50 ns 50 ns 50 ns 50 ns
switch - BREAK-BEFORE-MAKE BREAK-BEFORE-MAKE BREAK-BEFORE-MAKE BREAK-BEFORE-MAKE
Terminal surface - Tin/Lead (Sn85Pb15) Tin/Lead (Sn/Pb) Tin/Lead (Sn85Pb15) Tin/Lead (Sn/Pb)
Terminal pitch - 0.5 mm 0.5 mm 0.5 mm 0.5 mm
Maximum time at peak reflow temperature - NOT SPECIFIED 20 20 20
width - 3 mm 1.54 mm 3 mm 1.54 mm
