2981
THRU
2984
UDN2981A thru UDN2984A
1
18
8-CHANNEL SOURCE DRIVERS
Recommended for high-side switching applications that benefit from
separate logic and load grounds, these devices encompass load supply
voltages to 80 V and output currents to -500 mA. These 8-channel source
drivers are useful for interfacing between low-level logic and high-current
loads. Typical loads include relays, solenoids, lamps, stepper and/or servo
motors, print hammers, and LEDs.
Note that the UDN2980A series (dual in-line
package) and UDN2980LW series (small-outline
IC package) are electrically identical and share a
common terminal number assignment.
ABSOLUTE MAXIMUM RATINGS
at 25°C Free-Air Temperature
Output Voltage Range, V
CE
(UDN2981A, UDN2982A,
UDN2982LW, and A2982SLW) . .
5 V to 50 V
(UDN2983A, UDN2984A,
UDN2984LW, and A2984SLW) .
35 V to 80 V
Input Voltage, V
IN
(UDN2981A and UDN2983A) . . . . . . . . .
15 V
(UDN2982A, UDN2984A,
UDN2982LW, UDN2984LW,
A2982SLW, and A2984SLW) . . . . . . . . .
20 V
Output Current, I
OUT
. . . . . . . . . . . . . .
-500 mA
Package Power Dissipation,
P
D
. . . . . . . . . . . . . . . . . . . . . . .
See Graph
Operating Temperature Range,
T
A
. . . . . . . . . . . . . . . . . . . .
-20
°
C to +85
°
C
Storage Temperature Range,
T
S
. . . . . . . . . . . . . . . . . . .
-55
°
C to +150
°
C
UD
N2
Th
ac 98
eA
ce 3A
di
pt is
sc 29
ed L
on 84
un AS
tin SL
til T-
ue W,
Oc TIM
d. UD
to E
Sh N2
be B
ow 98
r 2 UY
4A
n
9, w
,&
fo
20 ith
rr U
04 or
ef DN
.
de
er 29
rs
en 8
ce 4LW
on a
ly re
.
2
17
3
16
4
5
6
7
8
15
14
13
12
11
V
S
GND
All devices may be used with 5 V logic systems — TTL, Schottky TTL,
DTL, and 5 V CMOS. The UDN2981A, UDN2982A, UDN2982LW, and
A2982SLW are electrically interchangeable, will withstand a maximum
output off voltage of 50 V, and operate to a minimum of 5 V; the UDN2983A,
UDN2984A, UDN2984LW, and A2984SLW drivers are electrically inter-
changeable, will withstand an output voltage of 80 V, and operate to a
minimum of 35 V. All devices in this series integrate input current limiting
resistors and output transient suppression diodes, and are activated by an
active high input.
The suffix ‘A’ (all devices) indicates an 18-lead plastic dual in-line
package with copper lead frame for optimum power dissipation. Under
normal operating conditions, these devices will sustain 120 mA continuously
for each of the eight outputs at an ambient temperature of +50°C and a supply
of 15 V.
The suffix ‘LW’ (UDN2982LW and UDN2984LW only) indicates an 18-
lead surface-mountable wide-body SOIC package; the A2982SLW and
A2984SLW are provided in a 20-lead wide-body SOIC package with im-
proved thermal characteristics.
The UDN2982A, UDN2982LW, A2982SLW, UDN2984A,
UDN2984LW, and A2984SLW drivers are also available for operation over
an extended temperature range to -40°C. To order, change the prefix ‘UDN’
to ‘UDQ’ or the suffix ‘SLW’ to ‘ELW’.
Data Sheet
29310E
Dwg. No. A-10, 243
FEATURES
s
s
s
s
s
TTL, DTL, PMOS, or CMOS Compatible Inputs
500 mA Output Source Current Capability
Transient-Protected Outputs
Output Breakdown Voltage to 80 V
DIP or SOIC Packaging
Th
e
Always order by complete part number, e.g.,
UDN2981A
.
Note that all devices are not available in all package styles.
2981
THRU
2984
8-CHANNEL
SOURCE DRIVERS
ELECTRICAL CHARACTERISTICS at T
A
= +25
°
C (unless otherwise specified).
Characteristic
Output Leakage Current
Symbol
I
CEX
Applicable
Devices
2981/82†
2983/84†
Output Sustaining
Voltage
Collector-Emitter
Saturation Voltage
V
CE(SAT)
All
V
CE(SUS)
2981/82†
2983/84†
Test Conditions
V
IN
= 0.4 V*, V
S
= 50 V, T
A
= +70°C
V
IN
= 0.4 V*, V
S
= 80 V, T
A
= +70°C
I
OUT
= -45 mA
I
OUT
= -70 mA
V
IN
= 2.4 V, I
OUT
= -100 mA
V
IN
= 2.4 V, I
OUT
= -225 mA
V
IN
= 2.4 V, I
OUT
= -350 mA
Input Current
I
IN(ON)
2982/84†
2981/83A
V
IN
= 2.4 V
V
IN
= 3.85 V
V
IN
= 2.4 V
V
IN
= 12 V
Output Source Current
(Outputs Open)
Supply Current
Leakage Current
Clamp Diode
Forward Voltage
Clamp Diode
Turn-On Delay
V
F
t
ON
t
OFF
I
R
I
S
l
OUT
2981/83A
2982/84†
2981/82†
2983/84†
2981/82†
2983/84†
All
All
V
IN
= 2.4 V, V
CE
= 2.0 V
V
IN
= 2.4 V, V
CE
= 2.0 V
V
IN
= 2.4 V*, V
S
= 50 V
V
IN
= 2.4 V*, V
S
= 80 V
V
R
= 50 V, V
IN
= 0.4 V*
V
R
= 80 V, V
IN
= 0.4 V*
I
F
= 350 mA
0.5 E
IN
to 0.5 E
OUT
, R
L
= 100Ω,
V
S
= 35 V
0.5 E
IN
to 0.5 E
OUT
, R
L
= 100Ω,
V
S
= 35 V, See Note
Test
Fig.
1
1
—
—
2
2
2
3
3
3
3
2
2
4
4
5
5
6
—
Min.
—
—
35
45
—
—
—
—
—
—
—
-350
-350
—
—
—
—
—
—
Limits
Typ. Max.
—
—
—
—
1.6
1.7
1.8
140
310
140
1.25
—
—
—
—
—
—
1.5
1.0
200
200
—
—
1.8
1.9
2.0
200
450
200
1.93
—
—
10
10
50
50
2.0
2.0
Units
µA
µA
V
V
V
V
V
µA
µA
µA
mA
mA
mA
mA
mA
µA
µA
V
µs
µs
Turn-Off Delay
All
—
—
5.0
10
NOTES: Turn-off delay is influenced by load conditions. Systems applications well below the specified output loading may require
timing considerations for some designs, i.e., multiplexed displays or when used in combination with sink drivers in a totem
pole configuration.
Negative current is defined as coming out of (sourcing) the specified device terminal.
* All inputs simultaneously.
† Complete part number includes a prefix (A or UDN) and a suffix (A or SLW) as follows:
UDN2981A,
UDN2982A, UDN2982LW, or A2982SLW,
The A2984SLW, UDN2984A, & UDN2984LW are
UDN2983A,
UDN2984A, UDN2984LW, or A2984SLW.
Shown for reference only.
discontinued.
www.allegromicro.com
3
