ESQ–110–44–T–D
F-214
ESW–115–12–G–S
(2,54 mm) .100"
ESQ–132–14–G–D
ESW, ESQ SERIES
ELEVATED SOCKET
Mates with:
TSW, MTSW, EW,
MTLW, TSS, ZSS, TSM,
DW, ZW, HW, TSSH, HTSS
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?ESW or
www.samtec.com?ESQ
Insulator Material:
Black Glass Filled Polyester
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27 µm) Ni
Current Rating (ESW/TSW):
5.2 A per pin
(1 pin powered per row)
Current Rating (ESQ/TSW):
5.7 A per pin
(1 pin powered per row)
Voltage Rating:
550 VAC mated with
TSW or ESQ
Operating Temp Range:
-55°C to +125°C with Gold
-55°C to +105°C with Tin
Contact Resistance:
10 mΩ
Insertion Depth:
(3,68 mm) .145" to
(6,35 mm) .250"
Insertion Force:
(Single contact only)
Standard = 6 oz (1,67 N) avg.
((0,64 mm) .025" SQ pin);
ESW Low Inser tion Force=
3 oz (0,83 N) avg.
ESQ Low Insertion Force=
3.3 oz (0,92 N) avg.
Normal Force:
Standard = 125 grams (4,4 N)
Withdrawal Force:
(Single contact only)
Standard = 5 oz (1,39 N) avg.
((0,64 mm) .025" SQ pin);
ESW Low Inser tion Force=
2.6 oz (0,72 N) avg.
ESQ Low Insertion Force=
2.9 oz (0,81 N) avg.
Max Cycles:
100 with 10µ" (0,25 µm) Au
RoHS Compliant:
Yes
Lead-Free Solderable:
Wave only
ESW
= Solder Tail
–S
–L
ALSO AVAILABLE
(MOQ Required)
• Other platings
Contact Samtec.
= 10µ" (0,25 µm)
Gold contact,
Matte Tin on tail
= Single
Row
–LL
= Locking
Lead
ESQ
= Square Tail
–D
= Double
Row
–G
= 20µ" (0.51 µm)
Gold contact,
Gold Flash on Balance
–T
= Triple
Row
(ESQ only)
01 thru 36
(2,54) .100 X No. of Positions + (0,51) .020
–T
= Matte Tin
(N/A w/LIF contact)
Two leads per
strip crimped.
N/A with single
row 1 or 2
positions.
–“XXX”
= Polarized
(2,41)
.095
–S
01
72
(2,54)
.100
36
02
–D
(2,54)
.100
71
(4,95)
.195
(2,54)
.100
01
Specify LEAD STYLE
from chart below.
LOW
STANDARD
INSERTION FORCE INSERTION FORCE
A
(2,29)
.090
(7,36)
.290
(4,83)
.190
(2,29)
.090
(12,19)
.480
(9,65)
.380
(7,11)
.280
(4,57)
.180
B
(11,05)
.435
(13,59)
.535
(16,13)
.635
(11,05)
.435
(13,59)
.535
(16,13)
.635
(18,67)
.735
108
03
– 12
– 13
– 23
– 33
– 14
– 24
– 34
– 44
– 37
– 38
– 48
– 58
– 39
– 49
– 59
– 69
B
(5,08)
.200 (2,54)
.100
(7,49)
.295
(ESQ
only)
–T
106
01
A
APPLICATIONS
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
FILE NO: 090871_0_000
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
(2,54)
.100
TYP
ESW
(0,41) x (0,79)
.016 .031
ESQ
(0,64)
.025
SQ
Self g
Nestints
Socke
(ESQ Series)
PC/104
™
J1/P1 “Stackthrough” Connectors
Standard Insertion Force
ESQ-132-14-G-D
Low Insertion Force
ESQ-132-39-G-D
PC/104
™
J1 “Non-Stackthrough” Connectors
Standard Insertion Force
ESQ-132-12-G-D
Low Insertion Force
ESQ-132-37-G-D
PC/104
™
J2/P2 “Stackthrough” Connectors
Standard Insertion Force
ESQ-120-14-G-D
Low Insertion Force
ESQ-120-39-G-D
PC/104 is a trademark of the PC/104 Consortium.
