Phycomp
Product specification
High Frequency
FEATURES
•
Designed for 2.45 GHz ISM-band
•
Simplifies antenna circuitry
•
NiSn lead-free terminations
SMD type antennas
for BT/802.11b/g application 2.45 GHz size 5.3
×
2.0
DESCRIPTION
This 2.45 GHz ceramic multilayer antenna has been
designed to meet the requirements of the Bluetooth
TM(1)
and IEEE 802.11b/g wireless communications protocol. It
consists of a rectangular block of low-dielectric ceramic
material and is fabricated in a water-based non-toxic
process. The antenna is capable of providing good
connectivity using near 50
Ω
microstrip directly onto the
PC board.
Notes
1.
Bluetooth is a trademark owned by
Telefonieaktiebolaget L M Ericsson, Sweden.
•
Suitable for wave and reflow soldering
•
Supplied in tape on reel.
APPLICATIONS
•
Telecommunications
•
Computing (PCs, printers, PDAs)
•
Wireless office data communications including WLAN
•
Consumer electronics (wireless headphones).
QUICK REFERENCE DATA
DESCRIPTION
Centre frequency
Bandwidth
Gain
VSWR
Polarization
Azimuth beam width
Impedance
Power dissipation
Operating temperature
Terminations
Resistance to soldering heat
VALUE
2.45 GHz
0 type/01type/02 type/03 type/Default/04 type/05 type
＞100
MHz
4 dBi max. (depends on the special environment)
2.5 max. (depends on the special environment)
Linear
Omni-directional
50
Ω
1W
−55
to
+85 °C
NiSn
260
°C
for 10 seconds
2004 Oct 12 Rev.4
2
www.yageo.com
Phycomp
Product specification
High Frequency
ELECTRICAL CHARACTERISTICS
SMD type antennas
for BT/802.11b/g application 2.45 GHz size 5.3
×
2.0
DESCRIPTION
Centre frequency
Bandwidth
Gain
VSWR
Polarization
Azimuth beam width
Impedance
Power dissipation
Operating temperature
Terminations
Resistance to soldering heat
Weight
FOOTPRINT DIMENSIONS
2.45 GHz
VALUE
0 type/01type/02 type/03 type/Default/04 type/05 type
＞100
MHz
4 dBi max. (depends on the special environment)
2.5 max. (depends on the special environment)
Linear
Omni-directional
50
Ω
1W
−55
to
+85 °C
NiSn
260
°C
for 10 s
0.05 g/piece
L
C
C
F
Antenna
W
L1
IWA0002
For dimensions see Table 2.
Fig.2. Recommend dimensions of solder
Physical dimensions
Table 2
The dimensions of antenna appearance
SYMBOL
L
W
F
C
L1
2004 Oct 12 Rev.4
−
−
feed pad
−
−
DETAILS
DIMENSIONS (mm)
5.5
±0.2
2.2
±0.2
2.2
±0.2
0.5
±0.25
4.3
±0.5
4
www.yageo.com
Phycomp
Product specification
High Frequency
SMD type antennas
for BT/802.11b/g application 2.45 GHz size 5.3
×
2.0
IWA0004
IWA0005
SWR
10.0
9.0
8.0
7.0
6.0
5.0
4.0
3.0
1
2.0
1.0
2.0 2.1 2.2 2.3 2.4 2.5 2.6 2.7 2.8 2.9 3.0
f (GHz)
2
Γ
(dB)
0
5
10
15
20
25
30
35
40
45
2.0 2.1 2.2 2.3 2.4 2.5 2.6 2.7 2.8 2.9 3.0
f (GHz)
1
2
Marker data:
1: SWR= 2.5; f= 2.30 GHz
2: SWR= 2.5; f= 2.70 GHz
Marker data:
1:
Γ= −10
dB; f= 2.33 GHz
2:
Γ= −10
dB; f= 2.60 GHz
Pre-tuning reference only,after-tuning performance is depending on
customer installation.
Fig.3
The measurements of typical SWR and return loss on the special environment .
2004 Oct 12 Rev.4
5
